TerraMaster D5 Hybrid DAS Network Attached Storage

TerraMaster D5 Hybrid DAS Network Attached Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: TerraMaster
• Model No: TerraMaster D5 Hybrid DAS Storage
• Disk Slot Number: 2
• Compatible Disk Types: 3.5" SATA HDD, 2.5" SATA HDD, 2.5" SATA SSD
• File System: NTFS, APFS, Mac OS,FAT32,EXT4,exFAT
• Maximum Internal Raw Capacity: 68 TB (22 TB drive x 2 + 8 TB drive x 3) (Capacity will vary along with the RAID type)
• RAIDs Supported: SINGLE DISK,JBOD,RAID 0,RAID 1
• Hardware RAID: Yes
• USB: USB3.2 Type-C gen2  10Gbps
• Power Socket: DC IN 12V
• Reading Speed (max.): Read?565MB/s ( HDD*2_RAID0 ); Read?960MB/s ( SSD*2_RAID0 )
• Writing Speed (max.): Write?524MB/s ( HDD*2_RAID0); Write?956MB/s ( SSD*2_RAID0 )
• System fan: 80 mm x 80 mm x25mm (x 1)
• Fan mode: Smart
• Noise Level: 19.0 dB(A)
• Power Supply: 40 W
• AC Input Voltage: 100V to 240V AC
• Current Frequency: 50/60 HZ, Single Phase
• Power Consumption: 30 W(Fully loaded Seagate 22TB ST22000NM001E hard drive(s) and SAMSUNG 980 NVMe M.2 SSD in read/write state ), 8.1 W (Fully loaded Seagate 22TB ST22000NM001E hard drive(s) and SAMSUNG 980 NVMe M.2 SSD  in hibernation)
• Working Temperature: 0°C  ~ 40°C (32°F ~ 104°F)
• Storage Temperature: -20°C ~ 60°C (-5°F ~ 140°F)
• Relative Humidity: 5% ~ 95% RH
• Supported OS: Windows OS?Mac OS?Linux
• Size: 222 x 119 x 154 mm
• Weight: 1.3 Kg
• Warranty: 2 years Warranty

TerraMaster D2 320 DAS Storage

TerraMaster D2 320 DAS Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: TerraMaster
• Model No: TerraMaster D2 320 DAS Storage
• Disk Slot Number: 2
• Compatible Disk Types: 3.5" SATA HDD, 2.5" SATA HDD, 2.5" SATA SSD
• File System: NTFS, APFS, Mac OS,FAT32,EXT4,exFAT
• Maximum Internal Raw Capacity: 44 TB (22 TB drive x 2) (Capacity will vary along with the RAID type)
• RAIDs Supported: SINGLE DISK,JBOD,RAID 0,RAID 1
• Hardware RAID: Yes
• USB: USB3.2 Type-C gen2  10Gbps
• Power Socket: DC IN 12V
• Reading Speed (max.): Read?565MB/s ( SSD* 1 ); Read?1075MB/s ( SSD* 2 )
• Writing Speed (max.): Write?524MB/s ( SSD*1 ); Write?956MB/s ( SSD*2 )
• System fan: 80 mm x 80 mm x25mm (x 1)
• Fan mode: Smart
• Noise Level: 23.8 dB(A)
• Power Supply: 40 W
• AC Input Voltage: 100V to 240V AC
• Current Frequency: 50/60 HZ, Single Phase
• Power Consumption: 19.4 W(Fully loaded Seagate 22TB ST22000NM001E hard drive(s) in read/write state), 5.2 W (Fully loaded Seagate 22TB ST22000NM001E hard drive(s) in hibernation)
• Working Temperature: 0°C  ~ 40°C (32°F ~ 104°F)
• Storage Temperature: -20°C ~ 60°C (-5°F ~ 140°F)
• Relative Humidity: 5% ~ 95% RH
• Supported OS: Windows OS?Mac OS?Linux
• Size: 222 x 119 x 154 mm
• Weight: 1.3 Kg
• Warranty: 2 years Warranty

TerraMaster D4 320 DAS Storage Enclosure

TerraMaster D4 320 DAS Storage Enclosure Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: TerraMaster
• Model No: TerraMaster D4 320 DAS Storage
• Disk Slot Number: 4
• Compatible Disk Types: 3.5" SATA HDD, 2.5" SATA HDD, 2.5" SATA SSD
• File System: NTFS, APFS, Mac OS,FAT32,EXT4,exFAT
• Maximum Internal Raw Capacity: 88 TB (22 TB drive x 4)
• RAIDs Supported: SINGLE DISK
• Hardware RAID: Yes
• USB: USB3.2 Type-C gen2  10Gbps
• Power Socket: DC IN 12V
• Reading Speed (max.): Read?560MB/s ( SSD* 1 ); Read?1016MB/s ( SSD* 4)
• Writing Speed (max.): Write?520MB/s ( SSD*1 ); Write?960MB/s ( SSD*4 )
• System fan: 120 x 120 x 25mm  1PCS
• Fan mode: Smart
• Noise Level: 21.0dB(A)
• Power Supply : 72 W
• AC Input Voltage: 100V to 240V AC
• Current Frequency: 50/60 HZ, Single Phase
• Power Consumption: 40.8 W(Access), 9.8 W (Hibernation)
• Working Temperature: 0°C  ~ 40°C (32°F ~ 104°F)
• Storage Temperature: -20°C ~ 60°C (-5°F ~ 140°F)
• Relative Humidity: 5% ~ 95% RH
• Supported OS: Windows OS?Mac OS?Linux
• Size (H*W*D): 222 x 179 x 154 mm
• Weight: 1.9 Kg
• Warranty: 2 years Warranty

TerraMaster D8 Storage

TerraMaster D8 Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: TerraMaster
• Model No: TerraMaster D8 Hybrid RAID Storage
• Disk Slot Number: 4
• Compatible Disk Types: 3.5" SATA HDD, 2.5" SATA HDD, 2.5" SATA SSD
• M.2 2280 NVMe Slot: 4(PCle3.0/4.0/5.0)
• File System: NTFS, APFS, Mac OS,FAT32,EXT4,exFAT
• Maximum Internal Raw Capacity: 120TB (22 TB drive x 4 + 8 TB drive x 4)
• RAIDs Supported: SINGLE DISK,JBOD,RAID 0,RAID 1?Only HDD1 and HDD2 support RAID array creation?the rest operate in Single mode.?
• Hardware RAID: Yes
• USB: USB3.2 Type-C gen2  10Gbps
• Power Socket: DC IN 12V
• Reading Speed (max.): Read?560MB/s ( SSD* 1 ); Read?1016MB/s ( SSD* 4)
• Writing Speed (max.): Write?520MB/s ( SSD*1 ); Write?960MB/s ( SSD*4 )
• System fan: 120 x 120 x 25mm  1PCS
• Fan mode: Smart
• Noise Level: 21.0dB(A)
• Power Supply: 90 W
• AC Input Voltage: 100V to 240V AC
• Current Frequency: 50/60 HZ, Single Phase
• Power Consumption: 40.8 W(Access), 9.8 W (Hibernation)
• Working Temperature: 0°C  ~ 40°C (32°F ~ 104°F)
• Storage Temperature: -20°C ~ 60°C (-5°F ~ 140°F)
• Relative Humidity: 5% ~ 95% RH
• Supported OS: Windows OS?Mac OS?Linux
• Size (H*W*D): 222 x 179 x 154   mm
• Weight: 1.9 Kg
• Warranty: 2 years Warranty

TerraMaster D4 SSD DAS Protable Enclousure

TerraMaster D4 SSD DAS Protable Enclousure Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: TerraMaster
• Model No: TerraMaster D4 SSD DAS Storage
• Disk Slot Number: 4
• Compatible Disk Types: PCIe NVMe M.2 2280 SSD
• File System: NTFS, APFS, Mac OS, FAT32, EXT4, exFAT
• Maximum Internal Raw Capacity: 32 TB (8TB SSD * 4)
• RAIDs Supported: SINGLE DISK
• USB: USB4 40Gbps
• Reading Speed (max.): 3257 MB/s (Samsung 990 Pro 4TB*4_RAID0); 1600MB/s (Samsung 990 Pro 4TB*1)
• Writing Speed (max.): 3192 MB/s (Samsung 990 Pro 4TB*4_RAID0); 1500MB/s (Samsung 990 Pro 4TB*1)
• System fan: 50 x 50 x 10mm 2PCS
• Fan mode: Smart
• Noise Level: 19.0 dB(A)
• Power Supply: 24 W
• AC Input Voltage: 100V to 240V AC
• Current Frequency: 50/60 Hz, Single Phase
• Power Consumption: 15.0 W (Fully loaded Seagate 2TB M.2 SSDs in read/write state), 6.0 W (Fully loaded Seagate 2TB M.2 SSDs in hibernation)
• Working Temperature: 0°C ~ 40°C (32°F ~ 104°F)
• Storage Temperature: -20°C ~ 60°C (-5°F ~ 140°F)
• Relative Humidity: 5% ~ 95% RH
• Supported OS: Mac OS?Windows 11(24H2 or later version)
• Size (H*W*D): 138 x 60 x 140 mm
• Weight: 392g
• Warranty: 2 years Warranty

TerraMaster D1 SSD Plus DAS Protable Enclousure

TerraMaster D1 SSD Plus DAS Protable Enclousure Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: TerraMaster
• Model No: TerraMaster D1 SSD Plus DAS Storage
• Disk Slot Number: 1
• Compatible Disk Types: PCIe NVMe M.2 2280 SSD
• File System: NTFS, APFS, Mac OS, FAT32, EXT4, exFAT
• Maximum Internal Raw Capacity: 8 TB (8TB SSD * 1)
• RAIDs Supported: SINGLE DISK
• USB: USB4 40Gbps
• Reading Speed (max.): 3641 MB/s (Samsung 990 Pro 4TB M.2 SSD*1)
• Writing Speed (max.): 3498 MB/s (Samsung 990 Pro 4TB M.2 SSD*1)
• Noise Level: Noiseless
• Power Supply: USB 5V
• Power Consumption: 7.5 W (Built-in Samsung 990 Pro 4TB M.2 SSD in read/write state), 5.5 W (Built-in Samsung 990 Pro 4TB M.2 SSD in hibernation)
• Working Temperature: 0°C ~ 40°C (32°F ~ 104°F)
• Storage Temperature: -20°C ~ 60°C (-5°F ~ 140°F)
• Relative Humidity: 5% ~ 95% RH
• Supported OS: Mac OS?Windows 11(24H2 or later version)
• Size (H*W*D): 112.5 x 60.0 x 33.0 mm
• Weight: 246 g
• Warranty: 2 years Warranty

NetApp ASA C250 All Flash SAN Array

NetApp ASA C250 All Flash SAN Array Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: NetApp
• Model No: NetApp ASA C250 All Flash SAN Storage
• Maximum scale-out: 12 nodes(6 HA pairs)
• Maximum SSDs(NVMe): 288
• Raw capacity (per HA pair): Up to 1.5PB
• Maximum effective capacity: 35.4PB
• Controller form factor: 2U; 24 internal SSD slots
• Power consumption(median): 491W
• PCIe expansion slots: 4
• FC target ports(32Gb autoranging): 16
• FC target ports(16Gb autoranging): n/a
• 100GbE ports(40GbE autoranging): 8
• 25GbE ports(10GbE autoranging): n/a
• 10GbE ports: n/a
• 10GBASE-T(1GbE autoranging): 4
• Storage networking supported: NVMe/TCP, NVMe/FC, FC, iSCSI
• Shelves and media: NS224 (2U, 24 drives, NVMe QLC SSDs)
• Host/client OS supported: Windows Server, Linux, Oracle Solaris, AIX, HP-UX, macOS, VMware, ESX

NetApp ASA C400 All Flash SAN Array

NetApp ASA C400 All Flash SAN Array Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: NetApp
• Model No: NetApp ASA C400 All Flash SAN Storage
• Maximum scale-out: 12 nodes(6 HA pairs)
• Maximum SSDs(NVMe): 576
• Raw capacity (per HA pair): Up to 2.9PB
• Maximum effective capacity: 70.7PB
• Controller form factor: 4U
• Power consumption(median): 1240W (with NS224)
• PCIe expansion slots: 10
• FC target ports(32Gb autoranging): 40
• FC target ports(16Gb autoranging): 8 FC bundle option
• 100GbE ports(40GbE autoranging): 20
• 40GbE ports (can be 4x10GbE): n/a
• 25GbE ports(10GbE autoranging): n/a10GbE ports: 32
• 10GBASE-T(1GbE autoranging): 16
• Storage networking supported: NVMe/TCP, NVMe/FC, FC, iSCSI
• Shelves and media: NS224 (2U, 24 drives, NVMe QLC SSDs)
• Host/client OS supported: Windows Server, Linux, Oracle Solaris, AIX, HP-UX, macOS, VMware, ESX

NetApp ASA C800 All Flash SAN Array

NetApp ASA C800 All Flash SAN Array Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: NetApp
• Model No: NetApp ASA C800 All Flash SAN Storage
• Maximum scale-out: 12 nodes(6 HA pairs)
• Maximum SSDs(NVMe): 1440
• Raw capacity (per HA pair): Up to 7.4PB
• Maximum effective capacity: 176.8PB
• Controller form factor: 4U; 48 internal SSD slots
• Power consumption(median): 1463W
• PCIe expansion slots: 8
• FC target ports(32Gb autoranging): 32
• FC target ports(16Gb autoranging): n/a
• 100GbE ports(40GbE autoranging): 32
• 40GbE ports (can be 4x10GbE): n/a
• 25GbE ports(10GbE autoranging): 16
• 10GbE ports: 32
• 10GBASE-T(1GbE autoranging): n/a
• Storage networking supported: NVMe/TCP, NVMe/FC, FC, iSCSI
• Shelves and media: NS224 (2U, 24 drives, NVMe QLC SSDs)
• Host/client OS supported: Windows Server, Linux, Oracle Solaris, AIX, HP-UX, macOS, VMware, ESX

NetApp ASA A150 All Flash SAN Array

NetApp ASA A150 All Flash SAN Array Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: NetApp
• Model No: NetApp ASA A150 All Flash SAN Storage
• Maximum scale-out: 2–12 nodes(6 HA pairs)
• Maximum SSDs(NVMe): 432 SAS SSD
• Raw capacity (per HA pair): Up to 547TB
• Maximum effective capacity: 13PB
• Controller form factor: 2U; 24 internal SSD slots
• Power consumption(median): 300W
• PCIe expansion slots: n/a
• FC target ports(32Gb autoranging): n/a
• FC target ports(16Gb autoranging): n/a
• FCoE target ports, UTA2: 8
• 100GbE ports(40GbE autoranging): n/a
• 25GbE ports(10GbE autoranging): n/a
• 10GbE ports: 4
• 10GBASE-T(1GbE autoranging): 8 (10GBASE-T models only)
• 12Gb/6Gb SAS ports: 4
• Storage networking supported: NVMe/TCP, NVMe/FC, FC, iSCSI
• Shelves and media: NS224 (2U, 24 drives, SFF NVMe); DS224C (2U, 24 drives, 2.5” SFF); DS2246 (2U, 24 drives, 2.5”, SFF)
• Host/client OS supported: Windows Server, Linux, Oracle Solaris, AIX, HP-UX, VMware

NetApp ASA A250 All Flash SAN Array

NetApp ASA A250 All Flash SAN Array Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: NetApp
• Model No: NetApp ASA A250 All Flash SAN Storage
• Maximum scale-out: 2–12 nodes(6 HA pairs)
• Maximum SSDs(NVMe): 288
• Raw capacity (per HA pair): Up to 1.1PB
• Maximum effective capacity: 26PB
• Controller form factor: 2U; 24 internal SSD slots
• Power consumption(median): 491W
• PCIe expansion slots: 4
• FC target ports(32Gb autoranging): 16
• FC target ports(16Gb autoranging): n/a
• FCoE target ports, UTA2: n/a
• 100GbE ports(40GbE autoranging): 8
• 25GbE ports(10GbE autoranging): 16
• 10GbE ports: n/a
• 10GBASE-T(1GbE autoranging): 4
• 12Gb/6Gb SAS ports: n/a
• Storage networking supported: NVMe/TCP, NVMe/FC, FC, iSCSI
• Shelves and media: NS224 (2U, 24 drives, SFF NVMe); DS224C (2U, 24 drives, 2.5” SFF); DS2246 (2U, 24 drives, 2.5”, SFF)
• Host/client OS supported: Windows Server, Linux, Oracle Solaris, AIX, HP-UX, VMware

NetApp ASA A400 All Flash SAN Array

NetApp ASA A400 All Flash SAN Array Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: NetApp
• Model No: NetApp ASA A400 All Flash SAN Storage
• Maximum scale-out: 2–12 nodes(6 HA pairs)
• Maximum SSDs(NVMe): 576
• Raw capacity (per HA pair): Up to 14.7PB
• Maximum effective capacity: 351PB
• Controller form factor: 4U
• Power consumption(median): 890W (with DS224C), 1240W (with NS224)
• PCIe expansion slots: 10
• FC target ports(32Gb autoranging): 24
• FC target ports(16Gb autoranging): 32 (with FC mezzanine card)
• FCoE target ports, UTA2: n/a
• 100GbE ports(40GbE autoranging): 16
• 25GbE ports(10GbE autoranging): 16
• 10GbE ports: 32
• 10GBASE-T(1GbE autoranging): 16
• 12Gb/6Gb SAS ports: 32
• Storage networking supported: NVMe/TCP, NVMe/FC, FC, iSCSI
• Shelves and media: NS224 (2U, 24 drives, SFF NVMe); DS224C (2U, 24 drives, 2.5” SFF); DS2246 (2U, 24 drives, 2.5”, SFF)
• Host/client OS supported: Windows Server, Linux, Oracle Solaris, AIX, HP-UX, VMware

NetApp ASA A800 All Flash SAN Array

NetApp ASA A800 All Flash SAN Array Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: NetApp
• Model No: NetApp ASA A800 All Flash SAN Storage
• Maximum scale-out: 2–12 nodes(6 HA pairs)
• Maximum SSDs(NVMe): 1440
• Raw capacity (per HA pair): Up to 6.6PB
• Maximum effective capacity: 158PB
• Controller form factor: 4U; 48 internal SSD slots
• Power consumption(median): 1463W
• PCIe expansion slots: 10
• FC target ports(32Gb autoranging): 32
• FC target ports(16Gb autoranging): 32
• FCoE target ports, UTA2: n/a
• 100GbE ports(40GbE autoranging): 20
• 25GbE ports(10GbE autoranging): 16
• 10GbE ports: 32
• 10GBASE-T(1GbE autoranging): n/a
• 12Gb/6Gb SAS ports: n/a
• Storage networking supported: NVMe/TCP, NVMe/FC, FC, iSCSI
• Shelves and media: NS224 (2U, 24 drives, SFF NVMe); DS224C (2U, 24 drives, 2.5” SFF); DS2246 (2U, 24 drives, 2.5”, SFF)
• Host/client OS supported: Windows Server, Linux, Oracle Solaris, AIX, HP-UX, VMware

NetApp ASA A900 All Flash Storage

NetApp ASA A900 All Flash Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: NetApp
• Model No: NetApp ASA A900 All Flash SAN Storage
• Maximum scale-out: 2–12 nodes(6 HA pairs)
• Maximum SSDs(NVMe): 1440
• Raw capacity (per HA pair): Up to 14.7PB
• Maximum effective capacity: 351PB
• Controller form factor: 8U
• Power consumption(median): 2450W (with NS224)
• PCIe expansion slots: 20
• FC target ports(32Gb autoranging): 64
• FC target ports(16Gb autoranging): 64
• FCoE target ports, UTA2: 64
• 100GbE ports(40GbE autoranging): 32
• 25GbE ports(10GbE autoranging): 64
• 10GbE ports: 64
• 10GBASE-T(1GbE autoranging): 64
• 12Gb/6Gb SAS ports: 64
• Storage networking supported: NVMe/TCP, NVMe/FC, FC, iSCSI
• Shelves and media: NS224 (2U, 24 drives, SFF NVMe); DS224C (2U, 24 drives, 2.5” SFF); DS2246 (2U, 24 drives, 2.5”, SFF)
• Host/client OS supported: Windows Server, Linux, Oracle Solaris, AIX, HP-UX, VMware

NetApp FAS8300 Hybrid Flash Storage Array

NetApp FAS8300 Hybrid Flash Storage Array Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: NetApp
• Model No: NetApp FAS8300 Hybrid Flash Storage
• Maximum scale-out: up to 24 nodes (12 HA pairs)
• Maximum SSDs: 720
• Maximum effective capacity: 14.7PB
• Controller form factor: 4U
• Power consumption(median): 681W, 846W with DS224C
• PCIe expansion slots: 10
• FC target ports(64Gb autoranging): n/a
• FC target ports(32Gb autoranging): 24
• FC target ports(16Gb autoranging): 32
• FCoE target ports, UTA2: n/a
• 200GbE ports(100GbE/40GbE autoranging): 16
• 100GbE ports(40GbE autoranging): 16
• 25GbE ports(10GbE autoranging): 32
• 10GbE ports: 16
• 10GBASE-T(1GbE autoranging): 16
• 12Gb/6Gb SAS ports: 32
• Storage networking supported: NFSv4/RDMA, NVMe/TCP, NVMe/ FC, FC, iSCSI, NFS, pNFS, CIFS/SMB, Amazon S3
• Shelves and media: DS212C (2U, 12, 12Gbps SATA/SAS), DS224C (2U, 24, 12Gbps SAS), DS460C (4U, 60, 12Gbps SATA/SAS)
• Host/client OS supported: Windows Server, Linux, Oracle Solaris, IBM AIX, HP-UX, macOS, VMware ESX

QSAN XS5312 Hybrid SAN Storage Systems

QSAN XS5312 Hybrid SAN Storage Systems Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: QSAN
• Model No: QSAN XS5312 Hybrid SAN Storage
• Architecture: XS5312D: Dual-active controller, XS5312S: Single-upgradeable controller
• Storage OS: XEVO 2
• Processor: Intel Xeon 64-bit 4-core (8-core processor models are also available)
• Memory Module Pre-installed: 16 GB DDR4 ECC DIMM (per controller)
• Total Memory Slots: 4 (per controller)
• Memory Expandable: 256 GB (per controller)
• Drive Bays: 3.5" Slot x 24
• Maximum Drive Bays with Expansion Unit: 492
• Compatible Drive Type: 3.5" & 2.5" SAS, NL-SAS, SED HDD, 3.5" & 2.5" SATA(*) HDD, 2.5" SAS, SATA(*), SED SSD
• Drive Interface: SAS 12 Gb/s, SATA 6 Gb/s(*)
• Maximum Internal Raw Capacity: 264 TB (calculate 22 TB HDD)
• Maximum Raw Capacity with Expansion Units: 10,824 TB (calculate 22 TB HDD)
• Hot Swappable Drive: Yes
• PCIe Expansion: (Gen 3x8 Slot) x 2
• 1 GbE RJ45 LAN Port: 1 (onboard management port per controller)
• 10 GbE SFP+ LAN Port: 4 (onboard per controller) / 4 (option)
• 10 GbE RJ45 LAN Port: 2 (option) / 4 (option)
• 25 GbE SFP28 LAN Port: 2 (option) / 4 (option)
• 16 Gb SFP+ Fibre Channel: 2 (option) / 4 (option)
• 32 Gb SFP28 Fibre Channel: 2 (option)
• 12 Gb/s SAS Wide Port: 2 (onboard per controller)
• USB Port: 1 (front) / 2 (rear)
• Others: Console Port x 1, Service Port (UPS) x 1
• Memory Protection: Cache-to-Flash (Supercapacitor Module + Flash Module) (option)
• System Fan: 4 pcs
• Power Supply Unit: 850 W x 2 (80 PLUS Platinum)
• Power Consumption: 534 W
• Dimension (H x W x D) (mm): 88 x 438 x 515 mm
• Weight: 16.4 kg
• Warranty: 3 Years Warranty

QSAN XS5316 SAN Systems

QSAN XS5316 SAN Systems Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: QSAN
• Model No: QSAN XS5316 SAN Storage
• Architecture: XS5316D: Dual-active controller, XS5316S: Single-upgradeable controller
• Storage OS: XEVO 2
• Processor: Intel Xeon 64-bit 4-core (8-core processor models are also available)
• Memory Module Pre-installed: 16 GB DDR4 ECC DIMM (per controller)
• Total Memory Slots: 4 (per controller)
• Memory Expandable: 256 GB (per controller)
• Drive Bays: 3.5" Slot x 24
• Maximum Drive Bays with Expansion Unit: 496
• Compatible Drive Type: 3.5" & 2.5" SAS, NL-SAS, SED HDD, 3.5" & 2.5" SATA(*) HDD, 2.5" SAS, SATA(*), SED SSD
• Drive Interface: SAS 12 Gb/s, SATA 6 Gb/s(*)
• Maximum Internal Raw Capacity: 352 TB (calculate 22 TB HDD)
• Maximum Raw Capacity with Expansion Units: 10,912 TB (calculate 22 TB HDD)
• Hot Swappable Drive: Yes
• PCIe Expansion: (Gen 3x8 Slot) x 2
• 1 GbE RJ45 LAN Port: 1 (onboard management port per controller)
• 10 GbE SFP+ LAN Port: 4 (onboard per controller) / 4 (option)
• 10 GbE RJ45 LAN Port: 2 (option) / 4 (option)
• 25 GbE SFP28 LAN Port: 2 (option) / 4 (option)
• 16 Gb SFP+ Fibre Channel: 2 (option) / 4 (option)
• 32 Gb SFP28 Fibre Channel: 2 (option)
• 12 Gb/s SAS Wide Port: 2 (onboard per controller)
• USB Port: 1 (front) / 2 (rear)
• Others: Console Port x 1, Service Port (UPS) x 1
• Memory Protection: Cache-to-Flash (Supercapacitor Module + Flash Module) (option)
• System Fan: 4 pcs
• Power Supply Unit: 850 W x 2 (80 PLUS Platinum)
• Power Consumption: 534 W
• Dimension (H x W x D) (mm): 130.4 x 438 x 515 mm
• Weight: 21.7 kg
• Warranty: 3 Years Warranty

QSAN XS5324 High NAS Storage

QSAN XS5324 High NAS Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: QSAN
• Model No: QSAN XS5324 High Density Storage
• Architecture: XS5324D: Dual-active controller, XS5324S: Single-upgradeable controller
• Storage OS: XEVO 2
• Processor: Intel Xeon 64-bit 4-core (8-core processor models are also available)
• Memory Module Pre-installed: 16 GB DDR4 ECC DIMM (per controller)
• Total Memory Slots: 4 (per controller)
• Memory Expandable: 256 GB (per controller)
• Drive Bays: 3.5" Slot x 24
• Maximum Drive Bays with Expansion Unit: 504
• Compatible Drive Type: 3.5" & 2.5" SAS, NL-SAS, SED HDD, 3.5" & 2.5" SATA(*) HDD, 2.5" SAS, SATA(*), SED SSD
• Drive Interface: SAS 12 Gb/s, SATA 6 Gb/s(*)
• Maximum Internal Raw Capacity: 528 TB (calculate 22 TB HDD)
• Maximum Raw Capacity with Expansion Units: 11,088 TB (calculate 22 TB HDD)
• Hot Swappable Drive: Yes
• PCIe Expansion: (Gen 3x8 Slot) x 2
• 1 GbE RJ45 LAN Port: 1 (onboard management port per controller)
• 10 GbE SFP+ LAN Port: 4 (onboard per controller) / 4 (option)
• 10 GbE RJ45 LAN Port: 2 (option) / 4 (option)
• 25 GbE SFP28 LAN Port: 2 (option) / 4 (option)
• 16 Gb SFP+ Fibre Channel: 2 (option) / 4 (option)
• 32 Gb SFP28 Fibre Channel: 2 (option)
• 12 Gb/s SAS Wide Port: 2 (onboard per controller)
• USB Port: 1 (front) / 2 (rear)
• Others: Console Port x 1, Service Port (UPS) x 1
• Memory Protection: Cache-to-Flash (Supercapacitor Module + Flash Module) (option)
• System Fan: 4 pcs
• Power Supply Unit: 850 W x 2 (80 PLUS Platinum)
• Power Consumption: 648 W
• Dimension (H x W x D) (mm): 170.3 x 438 x 515 mm
• Weight: 25.9 kg
• Warranty: 3 Years Warranty

QSAN XS5326 NAS

QSAN XS5326 NAS Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: QSAN
• Model No: QSAN XS5326 Network Attached Storage
• Architecture: XS5326D: Dual-active controller, XS5326S: Single-upgradeable controller
• Storage OS: XEVO 2
• Processor: Intel Xeon 64-bit 4-core (8-core processor models are also available)
• Memory Module Pre-installed: 16 GB DDR4 ECC DIMM (per controller)
• Total Memory Slots: 4 (per controller)
• Memory Expandable: up to 256 GB (per controller)
• Drive Bays: 2.5" Slot x 26
• Maximum Drive Bays with Expansion Unit: 546
• Compatible Drive Type: 2.5" SAS, NL-SAS, SED HDD, 2.5" SATA(*) HDD, 2.5" SAS, SATA(*), SED SSD
• Drive Interface: SAS 12 Gb/s, SATA 6 Gb/s(*)
• Maximum Internal Raw Capacity: 798 TB (calculate 30.72 TB SSD)
• Maximum Raw Capacity with Expansion Units: 16,773 TB (calculate 30.72 TB SSD)
• Hot Swappable Drive: Yes
• PCIe Expansion: (Gen 3x8 Slot) x 2
• 1 GbE RJ45 LAN Port: 1 (onboard management port per controller)
• 10 GbE SFP+ LAN Port: 4 (onboard per controller) / 4 (option)
• 10 GbE RJ45 LAN Port: 2 (option) / 4 (option)
• 25 GbE SFP28 LAN Port: 2 (option) / 4 (option)
• 16 Gb SFP+ Fibre Channel: 2 (option) / 4 (option)
• 32 Gb SFP28 Fibre Channel: 2 (option)
• 12 Gb/s SAS Wide Port: 2 (onboard per controller)
• USB Port: 1 (front) / 2 (rear)
• Others: Console Port x 1, Service Port (UPS) x 1
• Memory Protection: Cache-to-Flash (Supercapacitor Module + Flash Module) (option)
• System Fan: 4 pcs
• Power Supply Unit: 850 W x 2 (80 PLUS Platinum)
• Power Consumption: 429 W
• Dimension (H x W x D) (mm): 88 x 438 x 491 mm
• Weight: 16.3 kg
• Warranty: 3 Years Warranty

Buffalo LinkStation SoHo 700 Window NAS Storage

Buffalo LinkStation SoHo 700 Window NAS Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Buffalo
• Part Number: LS720D0402B
• Model No: Buffalo LinkStation SoHo 700 Series Storage
• Processor: Hexa-core 1.3GHz CPU
• Memory: 2GB
• Number of drive bays: 2
• Capacity: 4TB
• Drive interface: SATA 6 Gbps
• Supported RAID levels: 0/1/JBOD
• Data transfer rates: 2.5Gbps / 1000 Mbps / 100 Mbps / 10 Mbps
• Number of ports: 1 (2.5GBASE-T)
• Connector type: RJ-45
• Supported protocols: TCP/IP
• Network file services: SMB/CIFS, FTP/FTPS
• Power consumption: Max 48W
• Power supply: Internal AC 100-240V Universal 50/60Hz
• Operating temperature: 41? - 104?F (5? - 40?C)
• Operating humidity: 20 - 80% non-condensing
• Dimensions(L x W x H): 8.1 x 3.4 x 5 in
• Weight: 5.5 lbs

• Brand: Buffalo
• Part Number: LS720D0802B
• Model No: Buffalo LinkStation SoHo 700 Series Storage
• Processor: Hexa-core 1.3GHz CPU
• Memory: 2GB
• Number of drive bays: 2
• Capacity: 8TB
• Drive interface: SATA 6 Gbps
• Supported RAID levels: 0/1/JBOD
• Data transfer rates: 2.5Gbps / 1000 Mbps / 100 Mbps / 10 Mbps
• Number of ports: 1 (2.5GBASE-T)
• Connector type: RJ-45
• Supported protocols: TCP/IP
• Network file services: SMB/CIFS, FTP/FTPS
• Power consumption: Max 48W
• Power supply: Internal AC 100-240V Universal 50/60Hz
• Operating temperature: 41? - 104?F (5? - 40?C)
• Operating humidity: 20 - 80% non-condensing
• Dimensions(L x W x H): 8.1 x 3.4 x 5 in
• Weight: 5.5 lbs

• Brand: Buffalo
• Part Number: LS720D1602B
• Model No: Buffalo LinkStation SoHo 700 Series Storage
• Processor: Hexa-core 1.3GHz CPU
• Memory: 2GB
• Number of drive bays: 2
• Capacity: 16TB
• Drive interface: SATA 6 Gbps
• Supported RAID levels: 0/1/JBOD
• Data transfer rates: 2.5Gbps / 1000 Mbps / 100 Mbps / 10 Mbps
• Number of ports: 1 (2.5GBASE-T)
• Connector type: RJ-45
• Supported protocols: TCP/IP
• Network file services: SMB/CIFS, FTP/FTPS
• Power consumption: Max 48W
• Power supply: Internal AC 100-240V Universal 50/60Hz
• Operating temperature: 41? - 104?F (5? - 40?C)
• Operating humidity: 20 - 80% non-condensing
• Dimensions(L x W x H): 8.1 x 3.4 x 5 in
• Weight: 5.5 lbs

Buffalo TeraStation WS5420DN Window NAS Storage

Buffalo TeraStation WS5420DN Window NAS Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Buffalo
• Model No: Buffalo TeraStation WS5420DN NAS Storage
• Number of Drive Bays: 4
• Number of Included Drives: 4
• Capacity Range: 16, 32, 48TB
• Drive Interface: SATA 6 Gbps
• Operating System: Windows Server IoT 2025 for Storage Workgroup Edition
• Supported RAID: 0/1/5/JBOD (Individual Disks) (Default 5)
• Hot Spares: Yes, with hot swapping supported
• Standards Compliance: USB 3.0
• Connector Type: Type-A
• Number of Ports: 2x USB 3.2 (Gen 1)
• Data Transfer Rates: 5 Gbps
• CPU: Intel Atom C3338
• Memory: 8GB DDR4 with ECC
• Connector Type: RJ-45
• Power Consumption: Max 85W, Data Transfer 30.7W, Idling 25.5W, Standby 6.1W
• Power Supply: Internal AC 100-240V Universal 50/60Hz
• Operating Temperature: 32? - 104?F (0? - 40?C)
• Operating Humidity: 10 - 85% non-condensing
• Dimensions: 9.1 x 6.7 x 8.5 in
• Weight: 11.0 lbs

Buffalo TeraStation WS5220DN Window NAS Storage

Buffalo TeraStation WS5220DN Window NAS Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Buffalo
• Model No: Buffalo TeraStation WS5220DN NAS Storage
• Number of Drive Bays: 2
• Number of Included Drives: 2
• Capacity Range: 4, 8TB
• Drive Interface: SATA 6 Gbps
• Operating System: Windows Server IoT 2025 for Storage Workgroup Edition
• Supported RAID: 0/1/JBOD (Individual Disks) (Default 1)
• Hot Spares: Yes, with hot swapping supported
• Standards Compliance: USB 3.0
• Connector Type: Type-A
• Number of Ports: 2x USB 3.2 (Gen 1)
• Data Transfer Rates: 5 Gbps
• CPU: Intel Atom C3338
• Memory: 8GB DDR4 with ECC
• Connector Type: RJ-45
• Power Consumption: Max 85W, Data Transfer 30.7W, Idling 25.5W, Standby 6.1W
• Power Supply: Internal AC 100-240V Universal 50/60Hz
• Operating Temperature: 32? - 104?F (0? - 40?C)
• Operating Humidity: 10 - 85% non-condensing
• Dimensions: 9.1 x 6.7 x 6.7 in
• Weight: 10.4 lbs

Synology Rackstation RS2825RP Plus Storage

Synology Rackstation RS2825RP Plus Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Synology
• Product: Synology Rackstation RS2825RP+ 16 Bay NAS Storage
• Form Factor(RU): 3U
• CPU Model: AMD Ryzen V1780B
• CPU Quantity: 1
• CPU Core: 4
• CPU Architecture: 64-bit
• CPU Frequency: 3.35 (base) / 3.6 (turbo) GHz
• Memory: 8 GB DDR4 ECC UDIMM
• Memory Module Pre-installed: 8 GB (8 GB x 1)
• Total Memory Slots: 2
• Maximum Memory Capacity: 32 GB (16 GB x 2)
• Drive Bays: 16 Bays
• Maximum Drive Bays with Expansion Unit: 28 (RX1225RP x 1)
• Drive Type (See all supported drives): 3.5 SATA HDD; 2.5 SATA SSD
• RJ-45 1GbE LAN Port: 2
• RJ-45 10GbE LAN Port: 1
• USB 3.2 Gen 1 Port: 2
• Expansion Port: 1
• Expansion Port Type: Mini-SAS HD
• Notes: MTU value of 1GbE LAN port has a limit of 1500.
• PCIe Expansion: 1 x Gen3 x8 slot (x4 link)
• Rack Installation Support: 4-post 19" rack (Synology Rail Kit - RKS-02)
• System Fan: 80 mm x 80 mm x 3 pcs
• Fan Speed Mode: Full-Speed Mode: Cool Mode; Quiet Mode
• Noise Level: 49.6 dB(A)
• Power Supply Unit / Adapter: 550 watts
• Maximum Single Volume Size: 200 TB (32 GB memory required); 108 TB
• Maximum Internal Volume Number: 32
• Size (Height x Width x Depth): 132.3 mm x 482 mm x 656.5 mm
• Weight: 17.3 kg
• Warranty: 3-year hardware warranty, extendable to 5 years

iXsystems TrueNAS M60 Storage Systems

iXsystems TrueNAS M60 Storage Systems Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: iXsystems
• Model No: iXsystems TrueNAS M60 Storage
• Form Factor: 4U-52U
• Max Read Cache: 4x 3.2 TB NVMe
• Max Capacity: 30 PB
• Max Effective Capacity: 50 PB
• Chassis Depth: 27”, 686mm
• Dual Controllers (HA): Optional
• Controller: 32 Cores (64 Threads)
• RAM (Max): 768 GB
• Write Cache: 2x 16 GB TrueCache NVDIMM
• Networking: 2x 10/25/40/100GbE, 2x 10GBase-T
• Fibre Channel (option): 4x 32 GB
• Max Expansion Shelves: 12
• Max Drives Supported: 1248
• Max Throughput: 23 GB/s
• Warranty: 1 Year Warranty

iXsystems TrueNAS M50 Storage Systems

iXsystems TrueNAS M50 Storage Systems Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: iXsystems
• Model No: iXsystems TrueNAS M50 Storage
• Form Factor: 4U-36U
• Max Read Cache: 4x 1.6 TB NVMe
• Max Capacity: 10 PB
• Max Effective Capacity: 20 PB
• Chassis Depth: 27”, 686mm
• Dual Controllers (HA): Optional
• Controller: 20 Cores (40 Threads)
• RAM (Max): 384 GB
• Write Cache: 16 GB TrueCache® NVDIMM
• Networking: 2x 10/25/40/100GbE, 2x 10GBase-T
• Fibre Channel (option): 4x 16 GB or 2x 32 GB
• Max Expansion Shelves: 8
• Max Drives Supported: 504
• Max Throughput: 11 GB/s
• Warranty: 1 Year Warranty

iXsystems TrueNAS M40 Storage Systems

iXsystems TrueNAS M40 Storage Systems Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: iXsystems
• Model No: iXsystems TrueNAS M40 Storage
• Form Factor: 4U-12U
• Max Read Cache: 3x 800 GB SAS SSD or 2 x 1.6TB NVMe (optional)
• Max Capacity: 3 PB
• Max Effective Capacity: 6 PB
• Chassis Depth: 27”, 686mm
• Dual Controllers (HA): Optional
• Controller: 10 Cores (20 Threads)
• RAM (Max): 192 GB
• Write Cache: 16 GB TrueCache® NVDIMM
• Networking: 2x 10/25/40/100GbE, 2x 10GBase-T
• Fibre Channel (option): 4x 16 GB
• Max Expansion Shelves: 2
• Max Drives Supported: 144
• Max Throughput: 7 GB/s
• Warranty: 1 Year Warranty

iXsystems TrueNAS M30 Storage Systems

iXsystems TrueNAS M30 Storage Systems Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: iXsystems
• Model No: iXsystems TrueNAS M30 Storage
• Form Factor: 4U
• Max Read Cache: 800 GB SAS
• Max Capacity: 500 TB
• Max Effective Capacity: 1 PB
• Chassis Depth: 27”, 686mm
• Dual Controllers (HA): Optional
• Controller: 8 Cores (8 Threads)
• RAM (Max): 96 GB
• Write Cache: Optional 16 GB SAS SSD(s)
• Networking: 2x 10/25/40 GbE, 2x 10GBase-T
• Fibre Channel (option): 2x 16 GB
• Max Expansion Shelves: 2 (ES24),1 (ES60)
• Max Drives Supported: 24
• Max Throughput: 3 GB/s
• Warranty: 1 Year Warranty

iXsystems TrueNAS H30 Storage Systems

iXsystems TrueNAS H30 Storage Systems Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: iXsystems
• Model No: iXsystems TrueNAS H30 Storage
• Max Capacity: 2.5 PB
• Max Effective Capacity: 5 PB
• Write Cache: 2x NVMe SSD
• Max Read Cache: 2x 6.4 TB NVMe SSD
• Dual Controllers: Optional
• DRAM Per Controller: 256 GB
• Onboard Networking: 4x 1G Base-T, 2x 10G Base-T
• Additional Networking (Optional): Up to 4x 10/25 GbE or 2x 10/25 GbE + 2x 40/100 GbE
• Fiber Channel: 2 x 32 Gb
• Max Drives Supported: 114
• Max Expansion Shelves: 1x ES24, ES60, or ES102
• Max Throughput: 8 GByte/s
• Dimensions: 26.8” x 19” x 3.5” | 681 x 483 x 89 mm
• Warranty: 1 Year Warranty

Seagate Exos AP 5U84 Storage Systems

Seagate Exos AP 5U84 Storage Systems Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Seagate
• Product: Seagate Exos AP 5U84 Storage
• Form factor: 5U
• Controllers: One or two AP-BV-1 Controllers, redundancy optional
• CPU: AMD SP3 7292P EPYC CPU (12,16 Core)
• Memory: 4 x DDR4 - 3,200 MHz DIMM slots - 32,64,128 GB DIMM support
• Internal Boot Drive: Single or Dual M.2 NVMe SSD for Redundant Boot/Logs
• Onboard I/O: On-board NVidia CX4 Dual Port 10/25GbE I/O, / 2x 1GbE onboard connections (Management/Data)
• PCIe Expansion: One low-profile, half-length PCI Express Gen 4 x16 Host Interface Slot One OCP v2.0 Gen 4x8 host interface slot
• Storage Infrastructure: Gen 4 x8 PCIe Lanes to 12G Broadcom SAS Controller, Dual 12G x4 Mini-SAS HD External Expansion Ports
• Inter-Controller Link: PCI Express Gen 3 x16 NTB Inter-controller Interface
• Redundant Path: Yes (SAS only)
• Host/Expansion I/O Ports: Two ×4 mini-SAS HD Expansion I/O connectors
• Management/Status Reporting: Redfish API + IPMI & SES
• Device Support: 12 Gb/s SAS drives
• Max Drives Per Enclsoure: 84 × 3.5-in LFF drive slots
• Hot-Swappable Components: HDDs and SSDs (in chassis data slots), power supply units (PSU), cooling modules, side-plane expanders, and controllers
• Input Power Requirements: 200VAC-240VAC, 50Hz/60Hz
• Max Power Output per PSU: 2200W
• Power Supply: Power Efficiency 230VAC50/Hz, Power Factor Conditions (PFC)
• Dimension (Height x Width x Depth): 220 mm x 483 mm x 933 mm
• Weight: 135 Kg

Seagate Exos AP 2U24 Storage Systems

Seagate Exos AP 2U24 Storage Systems Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Seagate
• Product: Seagate Exos AP 2U24 Storage
• Form factor: 2U
• Controllers: One or two AP-BV-1 Controllers, redundancy optional
• CPU: AMD SP3 7292P EPYC CPU (12,16 Core)
• Memory: 4 x DDR4 - 3,200 MHz DIMM slots - 32,64,128 GB DIMM support
• Internal Boot Drive: Single or Dual M.2 NVMe SSD for Redundant Boot/Logs
• Onboard I/O: On-board NVidia CX4 Dual Port 10/25GbE I/O, / 2x 1GbE onboard connections (Management/Data)
• PCIe Expansion: One low-profile, half-length PCI Express Gen 4 x16 Host Interface Slot One OCP v2.0 Gen 4x8 host interface slot
• Storage Infrastructure: Gen 4 x8 PCIe Lanes to 12G Broadcom SAS Controller, Dual 12G x4 Mini-SAS HD External Expansion Ports
• Inter-Controller Link: PCI Express Gen 3 x16 NTB Inter-controller Interface
• Redundant Path: Yes (SAS only)
• Management/Status Reporting: Redfish API + IPMI & SES
• Device Support: 12 Gb/s SAS drives and 6 Gb/s SATA drives
• Max Drives Per Enclsoure: up to 24 × 2.5 in SFF drives
• Hot-Swappable Components: SSDs (in chassis data slots), power supply and cooling modules units (PCU), controllers
• Input Power Requirements: 100V-240V AC 60 Hz/50 Hz
• Max Power Output per PSU: 764W
• Power Supply: Power Efficiency 115 VAC/60 Hz | 230 VAC/50 Hz, Power Factor Conditions (PFC)
• Dimension (Height x Width x Depth): 87.9 mm x 443 mm x 630 mm
• Weight: 30 Kg

Seagate Exos AP 2U12 Storage Systems

Seagate Exos AP 2U12 Storage Systems Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Seagate
• Model No: Seagate Exos AP 2U12 Storage
• Form factor: 2U
• Controllers: One or two AP-BV-1 Controllers, redundancy optional
• CPU: AMD SP3 7292P EPYC CPU (12,16 Core)
• Memory: 4 x DDR4 - 3,200 MHz DIMM slots - 32,64,128 GB DIMM support
• Internal Boot Drive: Single or Dual M.2 NVMe SSD for Redundant Boot/Logs
• Onboard I/O: On-board NVidia CX4 Dual Port 10/25GbE I/O, / 2x 1GbE onboard connections (Management/Data)
• PCIe Expansion: One low-profile, half-length PCI Express Gen 4 x16 Host Interface Slot One OCP v2.0 Gen 4x8 host interface slot
• Storage Infrastructure: Gen 4 x8 PCIe Lanes to 12G Broadcom SAS Controller, Dual 12G x4 Mini-SAS HD External Expansion Ports
• Inter-Controller Link: PCI Express Gen 3 x16 NTB Inter-controller Interface
• Redundant Path: Yes (SAS only)
• Management/Status Reporting: Redfish API + IPMI & SES
• Device Support: 12 Gb/s SAS drives and 6 Gb/s SATA drives
• Max Drives Per Enclsoure: up to 12 × 3.5-in LFF or 2.5 in SFF drives
• Hot-Swappable Components: HDDs and SSDs (in chassis data slots), power supply and cooling modules units (PCU), and controllers
• Input Power Requirements: 100V-240V AC 60 Hz/50 Hz
• Max Power Output per PSU: 764W
• Power Supply: Power Efficiency 115 VAC/60 Hz | 230 VAC/50 Hz, Power Factor Conditions (PFC)
• Dimension (Height x Width x Depth): 87.9 mm x 443 mm x 630 mm
• Weight: 32 Kg

TerraMaster T12 423 12 Bay NAS Storage

TerraMaster T12 423 12 Bay NAS Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: TerraMaster
• Model No: TerraMaster T12 423 NAS Storage
• Processor Model: Intel Celeron N5095
• Processor Architecture: X.86 64-bit
• Processor Frequency: Quad Core 2.0 GHz (Max burst up to 2.9 GHz)
• CPU Single-Core Score: Null
• Hardware Encryption Engine: Yes
• System Memory: 8 GB DDR4 non-ECC SODIMM
• Pre-installed Memory module: 8 GB DDR4 non-ECC SODIMM (1x 8GB)
• Total Memory Slot Number: 2 (DDR4 SODIMM)
• Maximum Supported Memory: 32 GB (16 GB+16 GB) DDR4 non-ECC SODIMM
• Disk Slot Number: 12
• Compatible Drive types: 3.5" SATA HDD, 2.5" SATA HDD, 2.5" SATA SSD
• Maximum Internal Raw Storage Capacity: 120TB (20TB x6)
• System Fan: 92 x 92 x 25mm 3PCS
• Fan Mode: Smart, High speed, Middle speed, Low speed
• Noise Level: 31.4 dB(A)
• Power Supply: 500W
• AC Input Voltage: 100V - 240V AC
• Current Frequency: 50/60 Hz, Single frequency
• Power Consumption: 39.2W(Fully loaded Seagate 4TB ST4000VN008 hard drive(s) in read/write state), 16.0 W (Fully loaded Seagate 4TB ST4000VN008 hard drive(s) in hibernation)
• Size (H*W*D): 334 x 163x 295 mm
• Weight: 10.3 kg
• Warranty: 2 years Warranty

TerraMaster T9 423 9 Bay NAS Storage

TerraMaster T9 423 9 Bay NAS Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: TerraMaster
• Model No: TerraMaster T6 423 NAS Storage
• Processor Model: Intel Celeron N5095
• Processor Architecture: X.86 64-bit
• Processor Frequency: Quad Core 2.0 GHz (Max burst up to 2.9 GHz)
• CPU Single-Core Score: Null
• Hardware Encryption Engine: Yes
• System Memory: 8 GB DDR4 non-ECC SODIMM
• Pre-installed Memory module: 8 GB DDR4 non-ECC SODIMM (1x 8GB)
• Total Memory Slot Number: 2 (DDR4 SODIMM)
• Maximum Supported Memory: 32 GB (16 GB+16 GB) DDR4 non-ECC SODIMM
• Disk Slot Number: 9
• Compatible Drive types: 3.5" SATA HDD, 2.5" SATA HDD, 2.5" SATA SSD
• Maximum Internal Raw Storage Capacity: 180TB (20TB x9)
• System Fan: 80 x 80 x 25 mm  3PCS
• Fan Mode: Smart, High speed, Middle speed, Low speed
• Noise Level: 31.2 dB(A)
• Power Supply: 250W
• AC Input Voltage: 100V - 240V AC
• Current Frequency: 50/60 Hz, Single frequency
• Power Consumption: 72W(Fully loaded Seagate 4TB ST4000VN008 hard drive(s) in read/write state), 29 W (Fully loaded Seagate 4TB ST4000VN008 hard drive(s) in hibernation)
• Size (H*W*D): 334 x 135 x 295 mm
• Weight: 8.9 kg
• Warranty: 2 years Warranty

TerraMaster T6 423 NAS Storage

TerraMaster T6 423 NAS Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: TerraMaster
• Model No: TerraMaster T6 423 NAS Storage
• Processor Model: Intel Celeron N5095
• Processor Architecture: X.86 64-bit
• Processor Frequency: Quad Core 2.0 GHz (Max burst up to 2.9 GHz)
• CPU Single-Core Score: Null
• Hardware Encryption Engine: Yes
• System Memory: 4 GB DDR4 non-ECC SODIMM
• Pre-installed Memory module: 4 GB DDR4 non-ECC SODIMM (1x 4GB)
• Total Memory Slot Number: 2 (DDR4 SODIMM)
• Maximum Supported Memory: 32 GB (16 GB+16 GB) DDR4 non-ECC SODIMM
• Disk Slot Number: 6
• Compatible Drive types: 3.5" SATA HDD, 2.5" SATA HDD, 2.5" SATA SSD
• Maximum Internal Raw Storage Capacity: 120TB (20TB x6)
• System Fan: 40 x 40 x 28mm  3PCS
• Fan Mode: Smart, High speed, Middle speed, Low speed
• Noise Level: 34.5 dB(A)
• Power Supply: 120W
• AC Input Voltage: 100V - 240V AC
• Current Frequency: 50/60 Hz, Single frequency
• Power Consumption: 39.2W(Fully loaded Seagate 4TB ST4000VN008 hard drive(s) in read/write state), 16.0 W (Fully loaded Seagate 4TB ST4000VN008 hard drive(s) in hibernation)
• Size (H*W*D): 226 x 130 x 218 mm
• Weight: 3.9 kg
• Warranty: 2 years Warranty

TerraMaster U4 423 NAS Storage

TerraMaster U4 423 NAS Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: TerraMaster
• Model No: TerraMaster U4 423 NAS Storage
• Processor Model: Intel Celeron N5095
• Processor Architecture: X.86 64-bit
• Processor Frequency: Quad Core 2.0 GHz (Max burst up to 2.9 GHz)
• CPU Single-Core Score: Null
• Hardware Encryption Engine: Yes
• System Memory: 4 GB DDR4 non-ECC SODIMM
• Pre-installed Memory module: 4 GB DDR4 non-ECC SODIMM (1x 4GB)
• Total Memory Slot Number: 2 (DDR4 SODIMM)
• Maximum Supported Memory: 32 GB (16 GB+16 GB) DDR4 non-ECC SODIMM
• Disk Slot Number: 4
• Compatible Drive types: 3.5" SATA HDD, 2.5" SATA HDD, 2.5" SATA SSD
• Maximum Internal Raw Storage Capacity: 80TB (20TB x4)
• System Fan: 40 x 40 x 28mm  3PCS
• Fan Mode: Smart, High speed, Middle speed, Low speed
• Noise Level: 34.5 dB(A)
• Power Supply: 90W
• AC Input Voltage: 100V - 240V AC
• Current Frequency: 50/60 Hz, Single frequency
• Power Consumption: 35.2W(Fully loaded Seagate 4TB ST4000VN008 hard drive(s) in read/write state), 13.9 W (Fully loaded Seagate 4TB ST4000VN008 hard drive(s) in hibernation)
• Size (H*W*D): 45*440 *360  mm
• Weight: 6.8 kg
• Warranty: 2 years Warranty

TerraMaster F6 424 NAS Storage

TerraMaster F6 424 NAS Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: TerraMaster
• Model No: TerraMaster F8 SSD 8 Bay NAS Storage
• Processor Model: Intel N95
• Processor Architecture: X.86 64-bit
• Processor Frequency: 4-Core  (Max burst up to 3.4 GHz)
• CPU Single-Core Score: Null
• Hardware Encryption Engine: Yes
• System Memory: 8 GB DDR5 non-ECC SODIMM
• Pre-installed Memory module: 8 GB DDR5 non-ECC SODIMM (1x 8 GB)
• Total Memory Slot Number: 1 (DDR5 SODIMM)
• Maximum Supported Memory: 32 GB DDR5 non-ECC SODIMM
• Disk Slot Number: 6
• Compatible Drive types: 3.5" SATA HDD, 2.5" SATA HDD, 2.5" SATA SSD
• Maximum Internal Raw Storage Capacity: 132 TB (22 TB x6) (Capacity may vary by RAID types)
• Internal Drive: Btrfs, EXT4
• External Drive: EXT3, EXT4, NTFS, FAT32, HFS+, BTRFS
• RJ-45 2.5GbE Network Jack: 2
• USB3.2 Host Port: Type A *1 (10 Gbps) ; Type C *1 (10 Gbps)
• M.2 2280 NVMe Slot: 2 (PCIe 3.0 x1)
• System Fan: 92 x 92 x 25 mm  2PCS
• Fan Mode: Smart, High speed, Middle speed, Low speed
• Noise Level: 22.0 dB(A)
• Power Supply: 150 W
• AC Input Voltage: 100V - 240V AC
• Current Frequency: 50/60 Hz, Single frequency
• Power Consumption: 43.0 W(Fully loaded WD RED WD221KFGX 22TB hard drive(s) in read/write state), 15.0 W (Fully loaded WD RED WD221KFGX 22TB hard drive(s) in hibernation)
• Size (H*W*D): 154x 240 x222 mm
• Weight: 2.7 Kg
• Warranty: 2 years Warranty

iXsystems TrueNAS H20 Storage

iXsystems TrueNAS H20 Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: iXsystems
• Model No: iXsystems TrueNAS H20 Storage
• Max Capacity: 2.5 PB
• Max Effective Capacity: 5 PB
• Write Cache: NVMe SSD
• Max Read Cache: 2x 3.2 TB NVMe SSD
• Dual Controllers: Optional
• DRAM Per Controller: 128 GB - 256 GB
• Onboard Networking: 4x 1G Base-T
• Additional Networking (Optional): Up to 4x 10/25 GbE (SFP28) or 2x 10/25 GbE (SFP28) and 2x 40/100 GbE (QSFP28)
• Fiber Channel: 2 x 16 Gb
• Max Drives Supported: 114
• Max Expansion Shelves: 1x ES24, ES60, or ES102
• Max Throughput: 4 GByte/s
• Dimensions: 26.8” x 19” x 3.5” | 681 x 483 x 89 mm
• Warranty: 1 Year Warranty

iXsystems TrueNAS H10 Storage

iXsystems TrueNAS H10 Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: iXsystems
• Model No: iXsystems TrueNAS H10 Storage
• Max Capacity: 1.5 PB
• Max Effective Capacity: 3 PB
• Write Cache: NVMe SSD
• Max Read Cache: 3.2 TB NVMe SSD
• Dual Controllers: Optional
• DRAM Per Controller: 64 GB - 128 GB
• Onboard Networking: 4x 1G Base-T
• Additional Networking (Optional): Up to 4x 10/25 GbE (SFP28)
• Fiber Channel: 2 x 16 Gb
• Max Drives Supported: 72
• Max Expansion Shelves: 1x ES24 or ES60
• Max Throughput: 2 GByte/s
• Dimensions: 26.8” x 19” x 3.5” | 681 x 483 x 89 mm
• Warranty: 1 Year Warranty

iXsystems TrueNAS R50 48 Bay Storage

iXsystems TrueNAS R50 48 Bay Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: iXsystems
• Model No: iXsystems TrueNAS R50 Storage
• Controller Form factor: 2U–10U
• Chassis Depth: 39”, 990 mm
• Controllers: Single
• Drive Bays: 48 × 3.5", 4 × 2.5" (NVMe)
• CPU per Controller: 6–16 Cores
• DRAM per Controller: 64 GB–192 GB
• Read & Write Cache: 4 × 3.2 TB NVMe SSD
• Networking: 2 × 10/25/40/100 GbE, 2 or 6 × 10GBase-T or SR
• Fibre Channel (option): 2 × 32 Gb
• Max Expansion Shelves: 2
• Max Drives Supported: 252
• Max Throughput: 10 GB/s
• Storage Type: Hybrid
• Max Raw Capacity: 5 PB
• Max Effective Capacity: 10 PB
• Warranty: 1 Year Warranty

iXsystems TrueNAS R30 12 Bay Storage

iXsystems TrueNAS R30 12 Bay Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: iXsystems
• Model No: iXsystems TrueNAS R30 Storage
• Controller Form factor: 1U
• Chassis Depth: 33”, 840 mm
• Controllers: Single
• Drive Bays: 16 × NVMe
• CPU per Controller: 16–64 Cores
• DRAM per Controller: Up to 1024 GB
• Read & Write Cache: 2 × 960 GB SATA SSDs
• Networking: 2 or 4 × 10/25/40/100 GbE, 2 × 10GBase-T
• Fibre Channel (option): Up to 4 x 32Gb
• Max Expansion Shelves: 0
• Max Drives Supported: 16
• Max Throughput: 20 GB/s
• Storage Type: All-NVMe
• Max Raw Capacity: 240 TB
• Max Effective Capacity: 480 TB
• Warranty: 1 Year Warranty

iXsystems TrueNAS R20 12 Bay Storage

iXsystems TrueNAS R20 12 Bay Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: iXsystems
• Model No: iXsystems TrueNAS R20 Storage
• Controller Form factor: 2U–10U
• Chassis Depth: 26”, 660 mm
• Controllers: Single
• Drive Bays: 12 × 3.5", 2 × 2.5"
• CPU per Controller: 6–16 Cores
• DRAM per Controller: 32 GB–192 GB
• Read & Write Cache: 2 × 960 GB SATA SSDs
• Networking: 2 × 10/25/40/100 GbE, 2 or 6 × 10GBase-T or SR
• Fibre Channel (option): 2 × 32 Gb
• Max Expansion Shelves: 2
• Max Drives Supported: 132
• Max Throughput: 8 GB/s
• Storage Type: Hybrid
• Max Raw Capacity: 2.9 PB
• Max Effective Capacity: 6 PB
• Warranty: 1 Year Warranty

NetApp FAS8700 Hybrid Flash Storage

NetApp FAS8700 Hybrid Flash Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: NetApp
• Model No: NetApp FAS8700 Hybrid Flash Storage
• Maximum scale-out: up to 24 nodes (12 HA pairs)
• Maximum SSDs: 1440
• Maximum effective capacity: 14.7PB
• Controller form factor: 4U
• Power consumption(median): 965W, 1130W with DS224C
• PCIe expansion slots: 10
• FC target ports(64Gb autoranging): n/a
• FC target ports(32Gb autoranging): 24
• FC target ports(16Gb autoranging): 32
• FCoE target ports, UTA2: n/a
• 200GbE ports(100GbE/40GbE autoranging): 16
• 100GbE ports(40GbE autoranging): 16
• 25GbE ports(10GbE autoranging): 32
• 10GbE ports: 16
• 10GBASE-T(1GbE autoranging): 16
• 12Gb/6Gb SAS ports: 32
• Storage networking supported: NFSv4/RDMA, NVMe/TCP, NVMe/ FC, FC, iSCSI, NFS, pNFS, CIFS/SMB, Amazon S3
• Shelves and media: DS212C (2U, 12, 12Gbps SATA/SAS), DS224C (2U, 24, 12Gbps SAS), DS460C (4U, 60, 12Gbps SATA/SAS)
• Host/client OS supported: Windows Server, Linux, Oracle Solaris, IBM AIX, HP-UX, macOS, VMware ESX

NetApp FAS9500 Hybrid Flash Storage

NetApp FAS9500 Hybrid Flash Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: NetApp
• Model No: NetApp FAS9500 Hybrid Flash Storage
• Maximum scale-out: up to 24 nodes (12 HA pairs)
• Maximum SSDs: 1440
• Maximum effective capacity: 14.7PB
• Controller form factor: 8U
• Power consumption(median): 1919W, 2084W with DS224C
• PCIe expansion slots: 20
• FC target ports(64Gb autoranging): n/a
• FC target ports(32Gb autoranging): 64
• FC target ports(16Gb autoranging): 64
• FCoE target ports, UTA2: 64
• 200GbE ports(100GbE/40GbE autoranging): n/a
• 100GbE ports(40GbE autoranging): 32
• 25GbE ports(10GbE autoranging): 64
• 10GbE ports: 64
• 10GBASE-T(1GbE autoranging): 64
• 12Gb/6Gb SAS ports: 64
• Storage networking supported: NVMe/TCP, NVMe/FC, FC, iSCSI, NFS, pNFS, CIFS/SMB, Amazon S3
• Shelves and media: DS212C (2U, 12, 12Gbps SATA/SAS), DS224C (2U, 24, 12Gbps SAS), DS460C (4U, 60, 12Gbps SATA/SAS)
• Host/client OS supported: Windows Server, Linux, Oracle Solaris, IBM AIX, HP-UX, macOS, VMware ESX

NetApp AFF C250 All Flash Storage

NetApp AFF C250 All Flash Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: NetApp
• Model No: NetApp AFF C250 All Flash Storage
• Maximum scale-out: 2–24 nodes (12 HA pairs)
• Maximum SSDs: 576
• Maximum effective capacity: 71PB
• Controller form factor: 2U with 24 SSD internal slots
• PCIe expansion slots: 4
• FC target ports(32Gb autoranging): 16
• FC target ports(16Gb autoranging): n/a
• 100GbE ports(40GbE autoranging): 8
• 40GbE ports(can be 4x 10GbE): n/a
• 25GbE ports(10GbE autoranging): 16
• 10GbE ports: n/a
• 10GBASE-T(1GbE autoranging): 4
• Storage networking supported: NVMe/TCP, NVMe/FC, FC, iSCSI, NFS, pNFS, CIFS/SMB, S3
• Shelves and media: NS224 (2U, 24 drives, NVMe QLC SSDs)
• Power consumption(median): 491W
• Host/client OS supported: Windows Server, Linux, Oracle Solaris, IBM AIX, HP-UX, macOS, VMware, ESX

NetApp AFF C400 All Flash Storage

NetApp AFF C400 All Flash Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: NetApp
• Model No: NetApp AFF C400 All Flash Storage
• Maximum scale-out: 2–24 nodes (12 HA pairs)
• Maximum SSDs: 1,152
• Maximum effective capacity: 141PB
• Controller form factor: 4U
• PCIe expansion slots: 10
• FC target ports(32Gb autoranging): 24
• FC target ports(16Gb autoranging): 32
• 100GbE ports(40GbE autoranging): 16
• 40GbE ports(can be 4x 10GbE): n/a
• 25GbE ports(10GbE autoranging): 16
• 10GbE ports: 32
• 10GBASE-T(1GbE autoranging): 16
• Storage networking supported: NVMe/TCP, NVMe/FC, FC, iSCSI, NFS, pNFS, CIFS/SMB, S3
• Shelves and media: NS224 (2U, 24 drives, NVMe QLC SSDs)
• Power consumption(median): 1240W (with NS224)
• Host/client OS supported: Windows Server, Linux, Oracle Solaris, IBM AIX, HP-UX, macOS, VMware, ESX

NetApp AFF C800 NAS

NetApp AFF C800 NAS Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: NetApp
• Model No: NetApp AFF C800 All Flash Storage
• Maximum scale-out: 2–24 nodes (12 HA pairs)
• Maximum SSDs: 2,880
• Maximum effective capacity: 354PB
• Controller form factor: 4U with 48 SSD internal slots
• PCIe expansion slots: 8
• FC target ports(32Gb autoranging): 32
• FC target ports(16Gb autoranging): 32
• 100GbE ports(40GbE autoranging): 20
• 40GbE ports(can be 4x 10GbE): n/a
• 25GbE ports(10GbE autoranging): 16
• 10GbE ports: 32
• 10GBASE-T(1GbE autoranging): n/a
• Storage networking supported: NVMe/TCP, NVMe/FC, FC, iSCSI, NFS, pNFS, CIFS/SMB, S3
• Shelves and media: NS224 (2U, 24 drives, NVMe QLC SSDs)
• Power consumption(median): 1463W
• Host/client OS supported: Windows Server, Linux, Oracle Solaris, IBM AIX, HP-UX, macOS, VMware, ESX

Drobo 5D 5 Bay Direct Attached Storage

Drobo 5D 5 Bay Direct Attached Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Drobo
• Part Number: DRDR5A21
• Model No: Drobo 5D Direct Attached Storage
• Form Factor: Desktop
• Expansion Bays: 5 (total) / 5 (free) -3.5" - hot-swap
• Interfaces: 1 x USB 3.0 2 x Thunderbolt
• Capacity: 12 TB (4 x 3 TB)
• Installed Devices / Modules Qty: 0
• Supported Devices / Modules Qty: 5
• Supported Drives: SATA-600
• Total Array Capacity: 2 TB
• HDD Array External Interface: USB 3.0 Thunderbolt
• Type: SATA
• Interface Type: SATA 6Gb/s
• Data Transfer Rate: 600 MBps
• Voltage Required: AC 120/230 V (50/60 Hz)
• Power Provided: 150 Watt
• Dimensions: 7.3 x 5.9 x 10.3" / 150.3 x 185.4 x 262.3 mm
• Weight: 8.5 lb / 3.86 kg

Drobo 8D Thunderbolt 3 8 Bay Enclosure

Drobo 8D Thunderbolt 3 8 Bay Enclosure Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Drobo
• Model No: Drobo 8D Thunderbolt 3 Enclosure
• Number of Bays: 8x 3.5", 1x 2.5"
• Hard Drive: TB Mechanical Hard Disk
• Hard Disk Interface: ?Serial ATA-600
• Hard drive rotational speed: ?7200 RPM
• Batteries: ?1 Lithium Ion batteries required. (included)
• Inputs/Outputs: 2x USB-C Thunderbolt 3 (40 Gb/s)
• Media Card Slots: No
• Form Factor: Desktop
• Cooling: 2x Fans
• Dimensions (LxWxH): 16.9 x 15.6 x 11.5"
• Weight: 20.695 lb
• Warranty: 1 year Warranty

Drobo 5C Direct Attached Storage

Drobo 5C Direct Attached Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Drobo
• Model No: Drobo 5C Direct Attached Storage
• Form Factor: Desktop
• Capacity: 12 TB (4 x 3 TB)
• Connectivity: 1 x USB 3.0 Type-C Port
• Drives and Expansion: Up to five 3.5" SATA II/III hard disk drives or solid state drives, Expandable by adding drives or hot-swapping drives with larger ones
• Management: Drive bay indicator lights, capacity gauge, status lights, Drobo Dashboard version 2.8.3 or later
• Compatible Operating Systems: Apple Macintosh macOS 10.10 and higher, Microsoft Windows 10, 8, and 7
• File System Options: Apple macOS: HFS+, Microsoft Windows: NTFS
• Hardware Features: Carrier-less drive bays, Power fail protection with internal battery, Metal chassis and cover, Kensington Lock Port for security (lock not included)
• Additional Software Features: Drive Spin Down, Dim Lights, macOS Time Machine Support
• Power and Cooling: External Power Supply, AC Input: 100 to 240 VAC, 2 A, 50 to 60 Hz, DC Output: 12 V, 10 A, 120 W max, Fixed, 120 mm variable speed cooling fan
• Color: Black
• Dimensions: 10.3 x 5.9 x 7.3" / 26.2 x 15.0 x 18.5 cm
• Weight: 8.5 lb / 3.9 kg
• Warranty: 1 year Warranty

Zyxel NSA310 Storage

Zyxel NSA310 Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Zyxel
• Model No: Zyxel NSA310 1 Bay Storage
• Port: 1 x 3.5" SATA I/II hard disk interface supported, 1 x LAN 10/100/1000 Ethernet RJ-45 connector, 2 x USB 2.0, 1 x eSATA
• Button: Power, Copy/Sync, Reset
• Number of Drive Bays: 1
• LED Indicators: System/HDD/USB/eSATA/Copy
• Fan: Smart fan design
• Operating System: For Utility: Windows XP/Vista/7 (32 & 64-bit)
• Browser: IE 7.0+, Firefox 3.6+, Google Chrome 10+, Safari 5+
• Power Consumption: Access mode: 16.3 W, Hard disk hibernation mode: 10 W
• Power Supply: Input: 100~240 V AC, 50/60 Hz, Output: 19 V DC; 3.42 A
• Temperature: Operating: 32 to 104°F (0 to 40°C), Storage: -22 to 158°F (-30 to 70°C)
• Humidity: Operating: 0 to 95% non-condensing, Storage: 0 to 95% non-condensing
• Dimensions: 2.28 x 5.12 x 7.71" (57.91 x 130.04 x 195.83 mm)
• Weight: 23 oz (662 g)
• Warranty: 2 years Warranty

Zyxel NSA 2400 Network Storage

Zyxel NSA 2400 Network Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

Zyxel NAS520 Personal Cloud Storage

Zyxel NAS520 Personal Cloud Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Zyxel
• Model No: Zyxel NAS520 2 Bay Personal Cloud Storage
• Processor: 1.2 GHz FreeScale FS1024 dual-core
• Memory: 1 GB DDR3
• Drive Bays: 2 x 2.5"/3.5" SATA II
• Networking: 2 x Gigabit Ethernet
• Interfaces: 3 x USB 3.0
• Card Slot: SDXC
• Buttons: Power, Copy/Sync, Reset
• Power Consumption: 28.5 W (8.8 W spin down)
• Voltage Input: 100 to 240 VAC, 50/60 Hz
• Power Output: 12 VDC, 5 A
• Operating Temperature: 32 to 104°F / 0 to 40°C
• Storage Temperature: -22 to 158°F / -30 to 70°C
• Operating Humidity: 10 to 95%
• Storage Humidity: 10 to 95%
• Dimensions: 140 x 220 x 160 mm
• Weight: 1.5 kg
• Warranty: 2 years Warranty

Buffalo TeraStation 5820 NAS

Buffalo TeraStation 5820 NAS Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Buffalo
• Model No: Buffalo TeraStation 5820 NAS Storage
• Form Factor: Desktop
• CPU: Annapurna Labs Alpine Processor AL524 (2.04 GHz Quad-Core)
• Memory: 8 GB DDR4
• Number of Drive Bays: 8
• Number of Included Drives: 4 or 8
• Capacity Range: 32, 48, 64, 80. 96, 128, 160TB
• Drive Type: NAS-grade HDD (CMR)
• Supported RAID: 0/1/5/6/10/JBOD
• Standards Compliance: USB 3.0
• Connector Type: A type
• Number of Ports: 2x USB 3.0; 2x USB 2.0
• Power Consumption: Max 150W, Data Transfer 112W, Idling 97W
• Power Supply: Internal AC 100-240V, Universal 50/60Hz
• Operating Temperature: 32? - 104?F (0? - 40?C)
• Operating Humidity: 10 - 85% non-condensing
• Dimensions (L x W x H): 9.06 x 11.81 x 8.46 in
• Weight: 23.72 - 26.91 lbs
• Warranty: 3 Years Warranty

Buffalo TeraStation 5420 NAS

Buffalo TeraStation 5420 NAS Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Buffalo
• Model No: Buffalo TeraStation 5420 NAS Storage
• Form Factor: Desktop
• CPU: Annapurna Labs Alpine Processor AL524 (2.04 GHz Quad-Core)
• Memory: 8 GB DDR4
• Number of Drive Bays: 4
• Number of Included Drives: 2 or 4
• Capacity Range: 8, 16, 24, 32, 40, 48, 64, 80TB
• Drive Type: NAS-grade HDD (CMR)
• Supported RAID: 0/1/5/6/10/JBOD
• Standards Compliance: USB 3.0
• Connector Type: A type
• Number of Ports: 2x USB 3.0; 2x USB 2.0
• Power Consumption: Max 100W, Data Transfer 72W, Idling 56W
• Power Supply: Internal AC 100-240V, Universal 50/60Hz
• Operating Temperature: 32? - 104?F (0? - 40?C)
• Operating Humidity: 10 - 85% non-condensing
• Dimensions (L x W x H): 9.06 x 6.69 x 8.46 in
• Weight: 12.41 lbs
• Warranty: 3 Years Warranty

Buffalo TeraStation TS51220RH NAS

Buffalo TeraStation TS51220RH NAS Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Buffalo
• Model No: Buffalo TeraStation TS51220RH NAS Storage
• Form Factor: Rackmount
• Number of Drive Bays: 12
• Number of Included Drives: 4 or 12
• Capacity Range: 16, 32, 48, 64, 80, 96, 120, 144, 192, 240TB
• Drive Type: Enterprise-grade HDD (CMR)
• Supported RAID: 0/1/5/6/10/JBOD
• Standards Compliance: USB 3.0
• Connector Type:  A type
• Number of Ports: 2x USB 3.0; 2x USB 2.0
• CPU: Annapurna Labs Alpine Processor AL524 (2.04 GHz Quad-Core)
• Memory: 16 GB DDR4
• Power Consumption: Max 500W, Data Transfer 177W, Idling 135W
• Power Supply: Internal AC 100-240V, Universal 50/60Hz Optional dual power supply available
• Operating Temperature: 32? - 104?F (0? - 40?C)
• Operating Humidity: 10 - 85% non-condensing
• Dimensions (L x W x H): 29.0 x 18.9 x 3.4 in
• Weight: 55.37 lbs
• Warranty: 5 Years Warranty

Buffalo TeraStation 5420RN NAS

Buffalo TeraStation 5420RN NAS Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Buffalo
• Model No: Buffalo TeraStation 5420RN NAS Storage
• Form Factor: Rackmount
• Number of Drive Bays: 4
• Number of Included Drives: 4
• Capacity Range: 16, 32, 48, 64, 80TB
• Drive Type: NAS-grade HDD (CMR)
• Supported RAID: 0/1/5/6/10/JBOD
• Standards Compliance: USB 3.0
• Connector Type:  A type
• Number of Ports: 2x USB 3.0; 2x USB 2.0
• CPU: Annapurna Labs Alpine Processor AL524 (2.04 GHz Quad-Core)
• Memory: 8 GB DDR4
• Power Consumption: Max 100W, Data Transfer 72W, Idling 63W
• Power Supply: Internal AC 100-240V, Universal 50/60Hz
• Operating Temperature: 32? - 104?F (0? - 40?C)
• Operating Humidity: 10 - 85% non-condensing
• Dimensions (L x W x H): 16.93 x 16.93 x 1.74 in
• Weight: 18.69 lbs
• Warranty: 3 Years Warranty

Buffalo TeraStation 71210RH NAS

Buffalo TeraStation 71210RH NAS Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Buffalo
• Model No: Buffalo TeraStation 71210RH NAS Storage
• Form Factor: Rackmount
• Number of Included Drives: 12
• Capacity Range: 96, 144, 192, 240TB
• Drive Type: Enterprise-grade HDD (CMR)
• Supported RAID: 0/1/5/6/10/JBOD
• Hot Spares: Yes, with hot swapping supported
• Standards Compliance: USB 3.0
• Connector Type: A type
• Number of Ports: 2x USB 3.2 Gen 1, 2x USB 2.0
• CPU: Intel® Xeon® D-1713NT 2.2GHz Quad-core (Turbo boost up to 3.5GHz)
• Memory: DDR4 16GB ECC
• Memory Expansion: Expandable up to 64GB (16GB x4)
• Expansion Ports: 2x PCIe Gen 4x8
• SSD Caching: Yes
• 10GbE (SFP+): Yes
• 25GbE (SFP28): Yes
• 40GbE (QSFP): Yes
• Power Consumption: Max 500W, Data Transfer 251W, Idling 238W
• Power Supply: Internal AC 100-240V, Universal 50/60Hz
• Redundant Power Supply: Included
• Operating Temperature: 32? - 104?F (0? - 40?C)
• Operating Humidity: 10 - 85% non-condensing
• Dimensions (L x W x H) 29.0 x 18.9 x 3.5 in
• Weight: 54.2 lbs
• Warranty: 5 Years Warranty

TerraMaster F8 SSD NAS Storage Enclosure

TerraMaster F8 SSD NAS Storage Enclosure Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: TerraMaster
• Model No: TerraMaster F8 SSD 8 Bay NAS Storage
• Processor Model: Intel N95
• Processor Architecture: X.86 64-bit
• Processor Frequency: Max burst up to 3.4 GHz
• CPU Single-Core Score: Null
• Hardware Encryption Engine: Yes
• System Memory: 8 GB DDR5 non-ECC SODIMM
• Pre-installed Memory module: 8 GB DDR5 non-ECC SODIMM (1x 8 GB)
• Total Memory Slot Number: 1 (DDR5 SODIMM)
• Maximum Supported Memory: 32 GB DDR5 non-ECC SODIMM
• Maximum Internal Raw Storage Capacity: 64 TB (8 TB x8)
• Internal Drive: Btrfs, EXT4
• External Drive: EXT3, EXT4, NTFS, FAT32, HFS+, BTRFS
• RJ-45 10GbE Network Jack: 1
• USB3.2 Host Port: 3(10Gbps)
• M.2 2280 NVMe Slot: 8(PCIe 3.0 x1?
• System Fan: 50 x 50 x 10mm  2PCS
• Fan Mode: Smart, High speed, Middle speed, Low speed
• Noise Level: 19.0 dB(A)
• Power Supply: 72 W
• AC Input Voltage: 100V - 240V AC
• Current Frequency: 50/60 Hz, Single frequency
• Power Consumption: 45.0 W(Fully loaded Seagate 2TB M.2 SSDs in read/write state), 9.0 W (Fully loaded Seagate 2TB M.2 SSDs in hibernation)
• Size (H*W*D): 177 x 60 x 140 mm
• Weight: 0.7 Kg
• Warranty: 2 years Warranty

TerraMaster D4 SSD DAS Storage Enclosure

TerraMaster D4 SSD DAS Storage Enclosure Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: TerraMaster
• Model No: TerraMaster D4 SSD DAS Storage
• Disk Slot Number: 4
• Compatible Disk Types: PCIe NVMe M.2 2280 SSD
• File System: NTFS, APFS, Mac OS, FAT32, EXT4, exFAT
• Maximum Internal Raw Capacity: 32 TB (8TB SSD * 4)
• RAIDs Supported: SINGLE DISK
• USB: USB4 40Gbps
• Reading Speed (max.): 3257 MB/s
• Writing Speed (max.): 3192 MB/s
• System fan: 50 x 50 x 10mm 2PCS
• Fan mode: Smart
• Noise Level: 19.0 dB(A)
• Power Supply 24 W
• AC Input Voltage: 100V to 240V AC
• Current Frequency: 50/60 Hz, Single Phase
• Power Consumption: 15.0 W, 6.0 W
• Working Temperature: 0°C ~ 40°C (32°F ~ 104°F)
• Storage Temperature: -20°C ~ 60°C (-5°F ~ 140°F)
• Relative Humidity: 5% ~ 95% RH
• Supported OS: Mac OS?Windows 11(24H2 or later version)
• Size (H*W*D): 138 x 60 x 140 mm
• Weight: 392 g
• Warranty: 2 years Warranty

iXsystems TrueNAS F100 NAS Storage

iXsystems TrueNAS F100 NAS Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: NetApp
• Model No: iXsystems TrueNAS F100 storage
• Form Factor: 2U
• Features: NVMe Storage/All-Flash
• DRAM Per Controller: 512 GB
• Networking: Up to 6x 40/100 GbE (optical), 2x 10G Base-T
• Fiber Channel: 4 x 32 Gb
• Max Capacity: 10 PB
• Max Effective Capacity: 20 PB
• Max Throughput: 30 GByte/s
• Max Drives Supported: 24
• Max NVMe Expansion Shelves: 6
• Chassis Depth: 27”, 686mm
• Dual Controllers: Yes
• Warranty: 1 Year Warranty

iXsystems TrueNAS F60 NAS Storage

iXsystems TrueNAS F60 NAS Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: NetApp
• Model No: iXsystems TrueNAS F60 storage
• Form Factor: 2U
• Features: NVMe Storage/All-Flash
• DRAM Per Controller: 512 GB
• Networking: Up to 4x 40/100 GbE (optical), 2x 10G Base-T
• Fiber Channel: 4 x 32 Gb
• Max Capacity: 4 PB
• Max Effective Capacity: 8 PB
• Max Throughput: 20 GByte/s
• Max Drives Supported: 24
• Max NVMe Expansion Shelves: 2
• Chassis Depth: 27”, 686mm
• Dual Controllers: Yes
• Warranty: 1 Year Warranty

NetApp AFF A150 All Flash Storage Appliance

NetApp AFF A150 All Flash Storage Appliance Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: NetApp
• Model No: NetApp AFF A150 All Flash Data Storage
• Maximum scale-out: 2–24 nodes(12 HA pairs)
• Maximum SSD: 864
• Maximum effective capacity: 26PB
• Controller chassis form factor: 2U; 24 internal SSD slots
• Power consumption (median): 300W
• PCIe expansion slots: n/a
• FC target ports(64Gb autoranging): n/a
• FC target ports(32Gb autoranging): n/a
• FC target ports(16Gb autoranging): n/a
• FCoE target ports, UTA2: 8
• 200GbE ports(100GbE/40GbE autoranging): n/a
• 100GbE ports(40GbE autoranging): n/a
• 25GbE ports(10GbE autoranging): n/a
• 10GbE Ports: 4
• 10GBASE-T(1GbE autoranging): 4
• 12Gb/6Gb SAS ports: 4
• Storage networking supported: NVMe/TCP, NVMe/FC, FC, iSCSI, NFS, pNFS, CIFS/SMB, Amazon S3
• Host/client OS supported: Windows Server, Linux, Oracle Solaris, IBM AIX, HP-UX, macOS, VMware ESX

NetApp AFF A250 All Flash Storage Appliance

NetApp AFF A250 All Flash Storage Appliance Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: NetApp
• Model No: NetApp AFF A250 All Flash Data Storage
• Maximum scale-out: 2–24 nodes(12 HA pairs)
• Maximum SSD: 576
• Maximum effective capacity: 35.2PB
• Controller chassis form factor: 2U; 24 internal SSD slots
• Power consumption (median): 491W
• PCIe expansion slots: 4
• FC target ports(64Gb autoranging): n/a
• FC target ports(32Gb autoranging): 16
• FC target ports(16Gb autoranging): n/a
• FCoE target ports, UTA2: n/a
• 200GbE ports(100GbE/40GbE autoranging): n/a
• 100GbE ports(40GbE autoranging): 8
• 25GbE ports(10GbE autoranging): 16
• 10GbE Ports: n/a
• 10GBASE-T(1GbE autoranging): 4
• 12Gb/6Gb SAS ports: 4
• Storage networking supported: NVMe/TCP, NVMe/FC, FC, iSCSI, NFS, pNFS, CIFS/SMB, Amazon S3
• Host/client OS supported: Windows Server, Linux, Oracle Solaris, IBM AIX, HP-UX, macOS, VMware ESX

Qsan XF3212S 12 Bay All Flash Storage

Qsan XF3212S 12 Bay All Flash Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: QSAN
• Part No: XF3212S
• Model No: Qsan XF3212S All Flash Storage
• Architecture: Single-active controller
• Processor: Intel Xeon 4-core
• Memory: 8 GB DDR4 RDIMM
• Total Memory Slots: 4
• Total Expandable: 256 GB
• Drive Bays: 3.5" Slot x 12
• Drive Type: 2.5" single-port U.2 NVMe SSD
• Drive Interface: U.2 NVMe (PCIe Gen 4)
• Maximum Internal Capacity: 368 TB
• PCIe Expansion: (Gen 3x8 Slot) x 2
• USB Port: 1 (front) / 1 (rear)
• RAID: 0/1/3/5/6/10/50/60/5EE/6EE/50EE/60EE
• Data Protection: Snapshot, Asynchronous, Synchronous (option)
• Security: SSL/SSH/iSCSI CHAP/ISE & SED
• Protocols: iSCSI, FCP, NVMe-oF
• Management: Web UI, RESTful API, S.E.S., LCM
• Power Supply: 850 W x 2 (80 Plus Platinum)
• System fan: 4 pcs
• Dimensions: 88 x 438 x 515 mm
• Weight: 16.3 kg
• Warranty: 3 years Warranty

Qsan XF3212D 12 Bay All Flash Storage

Qsan XF3212D 12 Bay All Flash Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: QSAN
• Part No: XF3212D
• Model No: Qsan XF3212D All Flash Storage
• Architecture: Dual-active controller
• Processor: Intel Xeon 4-core x 2
• Memory: 16 GB DDR4 RDIMM
• Total Memory Slots: 8
• Total Expandable: 512 GB
• Drive Bays: 3.5" Slot x 12
• Drive Type: 2.5" dual-port U.2 NVMe SSD
• Drive Interface: U.2 NVMe (PCIe Gen 4)
• Maximum Internal Capacity: 368 TB
• PCIe Expansion: (Gen 3x8 Slot) x 4
• USB Port: 1 (front) / 2 (rear)
• RAID: 0/1/3/5/6/10/50/60/5EE/6EE/50EE/60EE
• Data Protection: Snapshot, Asynchronous, Synchronous (option)
• Security: SSL/SSH/iSCSI CHAP/ISE & SED
• Protocols: iSCSI, FCP, NVMe-oF
• Management: Web UI, RESTful API, S.E.S., LCM
• Power Supply: 850 W x 2 (80 Plus Platinum)
• System fan: 4 pcs
• Dimensions: 88 x 438 x 515 mm
• Weight: 16.3 kg
• Warranty: 3 years Warranty

Qsan XF4226S All Flash Array

Qsan XF4226S All Flash Array Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: QSAN
• Part No: XF4226S
• Model No: Qsan XF4226S Rackmount Storage
• Architecture: Single-upgradable controller
• Processor: Intel Xeon 8-core
• Memory: 16 GB DDR4 RDIMM
• Total Memory Slots: 8
• Total Expandable: 1,024 GB
• Drive Bays: 2.5" Slot x 26
• Maximum Drive Bays with Expansion Unit: 546
• Drive Type: 2.5" single-port U.2 / U.3 NVMe SSD, 2.5" SAS SSD, 3.5" SAS HDD
• Drive Interface: U.2 NVMe (PCIe Gen 4), SAS 12 Gb/s
• Maximum Internal Capacity: 798 TB
• Maximum Capacity with Expansion: 16,773 TB
• PCIe Expansion: (Gen 4x8 Slot) x 2
• 12 Gb/s SAS Wide Port: 2 (onboard)
• USB Port: 1 (front) / 1 (rear)
• RAID: 0/1/3/5/6/10/50/60/5EE/6EE/50EE/60EE
• Data Protection: Snapshot, Asynchronous, Synchronous (option)
• Security: SSL/SSH/iSCSI CHAP/ISE & SED
• Protocols: iSCSI, FCP, NVMe-oF
• Management: Web UI, RESTful API, S.E.S., LCM
• Power Supply: 850 W x 2 (80 Plus Platinum)
• System fan: 4 pcs
• Dimensions: 88 x 438 x 573 mm
• Weight: 16.5 kg
• Warranty: 3 years Warranty

Qsan XF4226D All Flash Array

Qsan XF4226D All Flash Array Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: QSAN
• Part No: XF4226D
• Model No: Qsan XF4226D Rackmount Storage
• Architecture: Dual-active controller
• Processor: Intel Xeon 8-core x 2
• Memory: 32 GB DDR4 RDIMM
• Total Memory Slots: 16
• Total Expandable: 2,048 GB
• Drive Bays: 2.5" Slot x 26
• Maximum Drive Bays with Expansion Unit: 546
• Drive Type: 2.5" dual-port U.2 / U.3 NVMe SSD, 2.5" SAS SSD, 3.5" SAS HDD
• Drive Interface: U.2 NVMe (PCIe Gen 4), SAS 12 Gb/s
• Maximum Internal Capacity: 798 TB
• Maximum Capacity with Expansion: 16,773 TB
• PCIe Expansion: (Gen 4x8 Slot) x 4
• 12 Gb/s SAS Wide Port: 4 (onboard)
• USB Port: 1 (front) / 2 (rear)
• RAID: 0/1/3/5/6/10/50/60/5EE/6EE/50EE/60EE
• Data Protection: Snapshot, Asynchronous, Synchronous (option)
• Security: SSL/SSH/iSCSI CHAP/ISE & SED
• Protocols: iSCSI, FCP, NVMe-oF
• Management: Web UI, RESTful API, S.E.S., LCM
• Power Supply: 850 W x 2 (80 Plus Platinum)
• System fan: 8 pcs
• Dimensions: 88 x 438 x 573 mm
• Weight: 19.6 kg
• Warranty: 3 years Warranty

Qsan XF5226S All Flash Array

Qsan XF5226S All Flash Array Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: QSAN
• Part No: XF5226S
• Model No: Qsan XF5226S All Flash Storage
• Architecture: Single-upgradable controller
• Processor: Intel Xeon 12-core processor
• Memory: 16 GB DDR4 RDIMM (per controller)
• Total Memory Slots: 8 (per controller)
• Total Expandable: Upto 1,024 GB (per controller)
• Drive Bays: 2.5" Slot x 26
• Maximum Drive Bays with Expansion Unit: 546
• Drive Type: 2.5" single-port U.2 NVMe SSD, 2.5" SAS/SED SSD, 3.5" SAS HDD
• Drive Interface: U.2 NVMe (PCIe Gen 4), SAS 12 Gb/s
• Maximum Internal Capacity: 798 TB
• Maximum Capacity with Expansion: 16,773 TB
• 12 Gb/s SAS Wide Port: 2 (onboard)
• USB Port: 1 (front) / 1 (rear)
• RAID: 0/1/3/5/6/10/50/60/5EE/6EE/50EE/60EE
• Data Protection: Snapshot, Asynchronous, Synchronous (option)
• Security: HTTPS, SSH, iSCSI CHAP, ISE & SED
• Protocols: iSCSI, FCP, NVMe-oF
• Management: Web UI, RESTful API, S.E.S., LCM
• Power Supply: 650W x 2 (80 Plus Platinum)
• Dimensions: 88 x 438 x 573 mm
• Weight: 16.5 kg
• Warranty: 3 years Warranty

Seagate Exos E 2U24 12 Bay Storage

Seagate Exos E 2U24 12 Bay Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Seagate
• Product: Seagate Exos E 2U24 Storage
• Controllers: Exos E IOM. 14.4 GB/s single I/O and 28.8 GB/s dual I/O.
• Host I/O Interface (defined by controller): Three x4 12 Gb/s mini-SAS HD connectors (SFF-8644) per I/O module
• Management Interface: 2 X 1GbE
• Exos X EBOD Expansion: 10 Enclosures Max (Controller Enclosure and up to 9 Expansion Enclosures) 240 Drives Max
• Max TB Per Chassis: 368 TB Using Qty 24, 15.36 TB 2.5” SAS SSD Drives
• SAS Controllers (Exos E IOM): Exos E IOM. 14.4 GB/s single I/O and 28.8 GB/s dual I/O.

Seagate Exos E 2U12 12 Bay Storage

Seagate Exos E 2U12 12 Bay Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Seagate
• Product: Seagate Exos E 2U12 Storage
• Controllers: Exos E IOM. 14.4 GB/s single I/O and 28.8 GB/s dual I/O.
• Host I/O Interface (defined by controller): Three x4 12 Gb/s mini-SAS HD connectors (SFF-8644) per I/O module
• Management Interface: 2 X 1GbE
• Exos X EBOD Expansion: 10 Enclosures Max (Controller Enclosure and up to 9 Expansion Enclosures) 120 Drives Max
• Max TB Per Chassis: 264 TB Using Qty 12, 22 TB 3.5” SAS Drives
• SAS Controllers (Exos E IOM): Exos E IOM. 14.4 GB/s single I/O and 28.8 GB/s dual I/O.

Seagate Exos X 5U84 84 Bay Storage

Seagate Exos X 5U84 84 Bay Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Seagate
• Product: Seagate Exos X 5U84 Storage
• Form factor: 5U rack mount
• Max Capacity Per Enclosure: 84 drives
• Expansion: 4 Enclosures Max (Controller Enclosure and up to 3 Expansion Enclosures) 336 Drives Max
• Host Port Options: 4 per controller 8 per system SFP+/SFP28 or mini-SAS HD
• Host Interface Options: 12 Gb SAS; 32/16 Gb FC; 25/10 GbE iSCSI 10GBASE-T Auto to 1Gb
• Data Protection Options: Improved ADAPT, NRAID RAID 0, 1, 5, 6, 10
• High Availability Features: ADR drive support, dual hot-swap controllers, drives, fans, power supplies, dual power cords, hot standby spare, automatic failover, multi-path support
• Advanced Features: Virtual pools, Thin provisioning, SSD read cache, Encryption, Auto-Tiering, Snapshots, Asynchronous replication

Seagate Exos X 2U24 24 Bay Storage

Seagate Exos X 2U24 24 Bay Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Seagate
• Product: Seagate Exos X 2U24 Storage
• Form factor: 2U rack mount
• Max Capacity Per Enclosure: 24 drives
• Expansion: 10 Enclosures Max (Controller Enclosure and up to 9 Expansion Enclosures) 240 Drives Max
• Host Port Options: 4 per controller 8 per system SFP+/SFP28 or mini-SAS HD
• Host Interface Options: 12 Gb SAS; 32/16 Gb FC; 25/10 GbE iSCSI 10GBASE-T Auto to 1Gb
• Data Protection Options: Improved ADAPT, NRAID RAID 0, 1, 5, 6, 10
• High Availability Features: Dual hot-swap controllers, drives, fans, power supplies, dual power cords, hot standby spare, automatic failover, multi-path support
• Advanced Features: Virtual pools, Thin provisioning, SSD read cache, Encryption, Auto-Tiering, Snapshots, Asynchronous replication

Seagate Exos X 2U12 12 Bay Storage

Seagate Exos X 2U12 12 Bay Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Seagate
• Product: Seagate Exos X 2U12 Storage
• Form factor: 2U rack mount
• Max Capacity Per Enclosure: 12 drives
• Expansion: 10 Enclosures Max (Controller Enclosure and up to 9 Expansion Enclosures) 120 Drives Max
• Host Port Options: 4 per controller 8 per system SFP+/SFP28 or mini-SAS HD
• Host Interface Options: 12 Gb SAS; 32/16 Gb FC; 25/10 GbE iSCSI 10GBASE-T Auto to 1Gb
• Data Protection Options: Improved ADAPT, NRAID RAID 0, 1, 5, 6, 10
• High Availability Features: ADR drive support, dual hot-swap controllers, drives, fans, power supplies, dual power cords, hot standby spare, automatic failover, multi-path support
• Advanced Features: Virtual pools, Thin provisioning, SSD read cache, Encryption, Auto-Tiering, Snapshots, Asynchronous replication

Drobo 5N2 5 Bay NAS

Drobo 5N2 5 Bay NAS Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Drobo
• Model No: Drobo 5N2 Network Attached Storage
• Hard Drive: 2 TB
• Hardware Platform: Mac
• connectivity: x2. Ethernet port bonding
• Flash Memory Size: 2 TB
• Voltage: 12 Volts
• Batteries: 1 Lithium Ion batteries required. (included)
• Series: DRDS5A21-2TB
• Power Consumption: Idle System (standby, drives off): 13 watts
• Operating Temperature: 10°C – 35°C (50° – 95°F)
• Non-Operating Temperature (storage): -10° – 60°C (14° – 140°F)
• Operating Humidity: 5% – 80%
• Hardware Features: Carrier-less Drive Bays, Power Fail Protection.
• Color: Charcoal Heather
• Dimensions: 5.9 x 7.3 x 10.3 inches
• Weight: 4.5 kg
• Warranty: 1 year Warranty

Drobo B810n NAS Array

Drobo B810n NAS Array Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Drobo
• Model No: Drobo B810n Network Attached Storage
• Connectivity: 2 x Gigabit Ethernet ports
• Drives and Expansion: Up to 8 Bay SATA or solid state drives (SSDs) or up to 3 SSD
• Ethernet Features: Connection failover
• Port bonding: Jumbo frames (up to 9000 bytes MTU)
• Hardware Features: Carrier-less Drive Bays, Power Fail Protection
• Internal Power Supply: AC Input – 100/240 VAC, 1.8/0.75 A, 50/60 Hz
• Power Consumption: Idle System (standby, drives off): 13 watts
• Operating Temperature: 10°C – 35°C (50° – 95°F)
• Non-Operating Temperature (storage): -10° – 60°C (14° – 140°F)
• Operating Humidity: 5% – 80%
• Environmental: RoHS, WEEE, REACH
• Box Contents: Drobo B810n, 2 x 6 ft (1.8 m) Ethernet cables, 6 ft (1.8 m) power cord, Quick Start Card
• Optional Accessories: Drobo 8-Bay Rack Mount Kit
• Dimensions (WxDxH): 5.9 in x 7.3 in x 10.3 in
• Weight: 3.9 kg
• Warranty: 1 year Warranty

Drobo 5D3 Thunderbolt 3 Array Storage

Drobo 5D3 Thunderbolt 3 Array Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Drobo
• Model No: Drobo 5D3 Thunderbolt 3 Storage
• Connectivity: 2 x Thunderbolt 3 ports; second port for daisy chain- ing Thunderbolt devices, including one 5K or two 4K displays (Mac OS X only), 1 x USB 3.0 Type-C port
• Drives and Expansion: Up to five (5) 3.5”SATA II/III hard disk drives or solid state drives (sold separately)
• RAID Features: Thin Provisioning, Instant Expansion, Mixed Drive Size Utilization, Automatic Protection Levels
• Management: Drive bay indicator lights, capacity gauge, status lights
• Operating System Support: Apple® macOS X 10.12 and higher – Microsoft® Windows® 10
• File Systems Supported: Mac OS X: HFS+
• Hardware Features: Carrier-less drive bays
• Power and Cooling- External Power Supply: AC Input – 100-240VAC~2A, 50-60Hz • DC Output – 12V, 10A, 120W max, Fixed, 120mm variable speed cooling fan, 15W of power to slow charge a Thunderbolt 3 laptop
• Box Contents – Drobo 5D3, 3.3 ft (1 m) Thunderbolt 3 cable (20 Gb/s), 6 ft (1.8 m) power cord with power supply, Quick Start Card
• Dimensions (WxDxH): 5.9 in x 7.3 in x 10.3 in
• Weight: 3.9 kg
• Warranty: 1 year Warranty

Zyxel NAS540 4 Bay Cloud Storage

Zyxel NAS540 4 Bay Cloud Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Zyxel
• Model No: Zyxel NAS540 4 Bay Personal Cloud Storage
• Processor Core: Dual-core (2 Core)
• Processor Speed: 1.20 GHz
• Standard Memory: 1 GB
• Memory Technology: DDR3 SDRAM
• Ethernet Technology: Gigabit Ethernet
• Number of Total Expansion Bays: 4
• Number of 2.5"/3.5" Bays: 4
• Controller Type: Serial ATA/300
• RAID Supported: Yes
• RAID Levels: 0, 1, 5, 6, 10, 5+Hot Spare, JBOD
• Total Number of USB Ports: 3
• Number of USB 3.0 Ports: 3
• Network (RJ-45): Yes
• Dimensions (WxDxH): 7.5" x 8.9" x 6.3"
• Weight: 4.41 lb
• Warranty: 2 years Warranty

Zyxel NAS326 Network Attached Storage

Zyxel NAS326 Network Attached Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Zyxel
• Model No: Zyxel NAS326 Network Attached Storage
• CPU: Marvell Armada 380 1.3 GHz
• Memory: DDR3 512 MB
• Two 2.5" or 3.5" SATA II hard disk interface supported up to 24 TB (12 TB x2)
• One Gigabit Ethernet RJ-45 connector
• Two USB 3.0 ports
• One USB 2.0 port
• Buttons: Power button, Copy/Sync button, Reset button
• Smart fan design
• Power consumption: Access mode: 28 watt (full loading: Internal HDD x2, External HDD x3), Hard disk spin-down mode: 5.5 watt
• Power: Input: 100 - 240 V AC, 50/60 Hz, Output: 12 V DC, 5A
• Temperature: 0°C to 40°C (32°F to 104°F)
• Humidity: 10% to 95% (Non-condensing)
• Dimensions (WxDxH): 207 x 164 x 123 mm (8.15" x 6.46" x 4.84")
• weight: 1,257 g (2.77 lb.)
• Warranty: 1 year Warranty

Zyxel NSA320 Network Attached Storage

Zyxel NSA320 Network Attached Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Zyxel
• Model No: Zyxel NSA320 2 Bay Network Attached Storage
• CPU: Marvell 88F6281 Kirkwood SoC @ 1.2 GHz
• RAM: 512 MB DDR3
• Flash: 128 MB
• Item model number: NSA320
• Ethernet: Marvell 88E1318
• USB 3.0: N/A
• Number of USB 2.0 Ports: 3
• Wattage: 32.2 Watts
• Are Batteries Included: No
• Item Height: 5.79 Inches
• Item Width: 4.25 Inches
• Product Dimensions: 20.5 x 10.8 x 14.71 cm
• Weight: 1.06 kg
• Warranty: 1 year Warranty

Buffalo LinkStation SoHo 200 Series NAS

Buffalo LinkStation SoHo 200 Series NAS Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Buffalo
• Model No: Buffalo LinkStation SoHo 200 Series NAS Storage
• Processor: Marvell Armada 370 (800MHz dual issue ARM)
• Memory: 256MB DDR3
• Number of drive bays: 2
• Capacity:12TB
• Drive interface: SATA 3 Gbps
• Supported RAID levels: 0/1/JBOD
• Data transfer rates: 10/100/1000 Mbps (auto sensing)
• Number of ports: 1
• Connector type: RJ-45
• Supported protocols: TCP/IP
• Network file services: SMB/CIFS, AFP, FTP/FTPS
• Standards compliance: USB 2.0
• Data transfer rates: 480 Mbps* (USB 2.0)
• Number of ports: 1
• Power consumption: 48W Max
• Power supply: Internal AC 100-240V Universal 50/60Hz
• Operating temperature: 41? - 95?F (5? - 35?C)
• Operating humidity: 20 - 80% non-condensing
• Dimensions (L x W x H): 8.1 x 3.4 x 5 in
• Weight: 5.5 lbs
• Warranty: 3 years Warranty

Buffalo TeraStation 3430DN Desktop NAS

Buffalo TeraStation 3430DN Desktop NAS Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Buffalo
• Model No: Buffalo TeraStation 3430DN Desktop NAS Storage
• Type Configuration: Desktop Storage
• Number of Drive Bays: 4
• Number of Included Drives: 2 or 4
• Capacity Range: 4, 8, 16, 32 TB
• Drive Interface: SATA 6 Gbps
• Supported RAID: 0/1/5/6/10/JBOD
• Hot Spares: Yes, with hot swapping supported
• CPU: Annapurna Labs Alpine Processor, AL-524 2.0GHz Quad-core
• Memory: 2 GB DDR4
• Power Consumption: Max 85W, Data Transfer 42W, Idling 33W
• Power Supply: Internal AC 100-240V, Universal 50/60Hz
• Operating Temperature: 32? - 104?F (0? - 40?C)
• Operating Humidity: 10 - 85% non-condensing
• Standards Compliance: USB 3.2 (Gen1)
• Connector Type: A type
• Number of Ports: 2x USB 3.2 (Gen1)
• Data Transfer Rates: 2.5Gbps / 1000 Mbps / 100 Mbps / 10 Mbps
• Supported Protocols: TCP/IP
• Network File Services: SMB/CIFS, AFP, FTP, SFTP, NFS, HTTP/HTTPS, SNMP
• Connector Type: RJ-45
• Data Transfer Rates: 5 Gbps
• Dimensions(L x W x H): 9.1 x 6.7 x 8.5 in
• Weight: 10.6 lbs (2 drives included), 13.7 lbs (4 drives included)
• Warranty: 3 years Warranty

Buffalo TeraStation 3230DN Desktop NAS

Buffalo TeraStation 3230DN Desktop NAS Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Buffalo
• Model No: Buffalo TeraStation 3230DN Desktop NAS Storage
• Type Configuration: Desktop Storage
• Number of Drive Bays: 2
• Number of Included Drives: 2
• Capacity Range: 4, 8, 16 TB
• Drive Interface: SATA 6 Gbps
• Supported RAID: 0/1/JBOD
• Hot Spares: Yes, with hot swapping supported
• CPU: Annapurna Labs Alpine Processor, AL-524 2.0GHz Quad-core
• Memory: 2 GB DDR4
• Power Consumption: Max 85W, Data Transfer 29W, Idling 20W
• Power Supply: Internal AC 100-240V, Universal 50/60Hz
• Operating Temperature: 32? - 104?F (0? - 40?C)
• Operating Humidity: 10 - 85% non-condensing
• Standards Compliance: USB 3.2 (Gen1)
• Connector Type: A type
• Number of Ports: 2x USB 3.2 (Gen1)
• Data Transfer Rates: 2.5Gbps / 1000 Mbps / 100 Mbps / 10 Mbps
• Supported Protocols: TCP/IP
• Network File Services: SMB/CIFS, AFP, FTP, SFTP, NFS, HTTP/HTTPS, SNMP
• Connector Type: RJ-45
• Data Transfer Rates: 5 Gbps
• Dimensions(L x W x H): 9.1 x 6.7 x 6.7 in
• Weight: 9.5 lbs
• Warranty: 3 years Warranty

TerraMaster F4 425 NAS NAS

TerraMaster F4 425 NAS NAS Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: TerraMaster
• Model No: TerraMaster F4 425 NAS Storage
• Processor Model: Intel N5095
• Processor Architecture: x86 64-bit
• Processor Frequency: Quad Core 2.0 GHz (Max burst up to 2.9 GHz)
• CPU Single-Core Score: Null
• Hardware Encryption Engine: Yes
• System Memory: 4 GB DDR4 non-ECC SODIMM
• Pre-installed Memory Module: 4 GB DDR4 non-ECC SODIMM (1x 4GB)
• Total Memory Slot Number: 1 DDR4 SODIMM
• Maximum Supported Memory: 16GB DDR4 non-ECC SODIMM
• Disk Slot Number: 4
• Compatible Drive types: 3.5" SATA HDD, 2.5" SATA HDD, 2.5" SATA SSD
• Maximum Internal Raw Storage Capacity: 120 TB (30TB x4) (Capacity may vary by RAID types)
• Drive Hot Swap: Yes
• Internal Drive: Btrfs, EXT4
• External Drive: EXT3, EXT4, NTFS, FAT32, HFS+, BTRFS
• RJ-45 5GbE Network Port: 1
• USB3.2 Host Port: 2 x 10 Gbps + 1 x 5 Gbps
• HDMI: 1 x HDMI
• System Fan: 120 x 120 x 25mm  1PCS
• Fan Mode: Smart, High speed, Middle speed, Low speed
• Noise Level: 21.0 dB(A) ?Using 2 SATA HDDs/SSDs in standby mode; Test environment noise: 17.3dB(A); Test distance: 1m?
• Power Supply: 90 W
• Redundancy Power Supply: Null
• AC Input Voltage: 100V - 240V AC
• Current Frequency: 50/60 Hz, Single frequency
• Power Consumption: 33.0 W(Fully loaded Seagate 4TB ST4000VN008 hard drive(s) in read/write state), 13.0 W (Fully loaded Seagate 4TB ST4000VN008 hard drive(s) in hibernation)
• Size (H*W*D): 222 x 179 x 154 mm
• Weight: 2.1 Kg
• Warranty: 2 years Warranty

TerraMaster F2 425 NAS

TerraMaster F2 425 NAS Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: TerraMaster
• Model No: TerraMaster F2 425 NAS Storage
• Processor Model: Intel N5095
• Processor Architecture: x86 64-bit
• Processor Frequency: Quad Core 2.0 GHz (Max burst up to 2.9 GHz)
• CPU Single-Core Score: Null
• Hardware Encryption Engine: Yes
• System Memory: 4 GB DDR4 non-ECC SODIMM
• Pre-installed Memory Module: 4 GB DDR4 non-ECC SODIMM (1x 4GB)
• Total Memory Slot Number: 1 DDR4 SODIMM
• Maximum Supported Memory: 16GB DDR4 non-ECC SODIMM
• Disk Slot Number: 2
• Compatible Drive types: 3.5" SATA HDD, 2.5" SATA HDD, 2.5" SATA SSD
• Maximum Internal Raw Storage Capacity: 60TB (30TB x2) (Capacity may vary by RAID types)
• Drive Hot Swap: Yes
• Internal Drive: Btrfs, EXT4
• External Drive: EXT3, EXT4, NTFS, FAT32, HFS+, BTRFS
• RJ-45 5GbE Network Port: 1
• USB3.2 Host Port: 2 x 10 Gbps + 1 x 5 Gbps
• HDMI: 1 x HDMI
• System Fan: 80 x 80 x 25mm, 1PCS
• Fan Mode: Smart, High speed, Middle speed, Low speed
• Noise Level: 19.0 dB(A) (Using M.2 SSDs in standby mode; Test environment noise: 17.3dB(A); Test distance: 1m)
• Power Supply: 48 W
• Redundancy Power Supply: Null
• AC Input Voltage: 100V - 240V AC
• Current Frequency: 50/60 Hz, Single frequency
• Power Consumption: 22.0 W(fully loaded Seagate 4TB ST4000VN008 hard drive(s) in read/write state), 11.0 W(fully loaded Seagate 4TB ST4000VN008 hard drive(s) in hibernation)
• Size (H*W*D): 222 x 119 x 154 mm
• Weight: 1.5 Kg
• Warranty: 2 years Warranty

TerraMaster F4 SSD NAS

TerraMaster F4 SSD NAS Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: TerraMaster
• Model No: TerraMaster F4 SSD NAS Storage
• Processor Model: Intel N95
• Processor Architecture: x86 64-bit
• Processor Frequency: Max burst up to 3.4 GHz
• CPU Single-Core Score: Null
• Hardware Encryption Engine: Yes
• System Memory: 8 GB DDR5 non-ECC SODIMM
• Pre-installed Memory Module: 8 GB DDR5 non-ECC SODIMM (1x 8 GB)
• Total Memory Slot Number: 1 × DDR5 SODIMM
• Maximum Supported Memory: 16 GB DDR5 non-ECC SODIMM
• Disk Slot Number: Null
• Compatible Drive types: Null
• Maximum Internal Raw Storage Capacity: 32 TB (8 TB x4) (Capacity may vary by RAID types)
• Drive Hot Swap: Null
• Internal Drive: Btrfs, EXT4
• External Drive: EXT3, EXT4, NTFS, FAT32, HFS+, BTRFS
• RJ-45 5GbE Network Port: 1
• System Fan: 50 x 50 x 10mm  2PCS
• Fan Mode: Smart, High speed, Middle speed, Low speed
• Noise Level: 19.0 dB(A) (Using M.2 SSDs in standby mode; Test environment noise: 17.3dB(A); Test distance: 1m)
• Power Supply: 48 W
• AC Input Voltage: 100V - 240V AC
• Current Frequency: 50/60 Hz, Single frequency
• Power Consumption: 32.0 W(Fully loaded Seagate 2TB M.2 SSDs in read/write state), 8.0 W (Fully loaded Seagate 2TB M.2 SSDs in hibernation)
• USB3.2 Host Port: 3  x 10 Gbps?Type A x2 + Type C x1)
• HDMI: 1 x HDMI 2.b
• M.2 2280 NVMe Slot: 2(PCIe 3.0 x2?+2(PCIe 3.0 x1)
• Size (H*W*D): 138 x 60 x 140 mm
• Weight: 0.6 Kg
• Warranty: 2 years Warranty

iXsystems TrueNAS Mini R Enterprise Storage

iXsystems TrueNAS Mini R Enterprise Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: iXsystems
• Model No: iXsystems TrueNAS Mini R Storage
• Chassis: 12 Bay Enclosure – Super Quiet Design
• Drive Bays: 12 x SATA 3.5” Hot-Swappable Drive Bays (Optional 3.5? to 2.5? adaptors available)
• Maximum Raw Capacity: Up to 216 TB
• CPU: Octa-core C3758 Intel CPU
• Memory: 32 GB DDR4 with ECC (Upgradeable to 64GB)
• RAID: OpenZFS – RAIDZ1 (RAID 5), RAIDZ2 (RAID 6), Multi-Disk Mirror (RAID 10), and RAID0 (stripe)
• Disk Management: Hot-Swappable Drives, Bad Block Scan + HDD S.M.A.R.T, ISO Mounting Support, Hardware-Accelerated Disk Encryption
• Network: Standard: 2 x RJ45 1/10GBaseT Ethernet LAN ports, Dedicated RJ45 IPMI Port (Remote Hardware Management), 2 x SFP+ 10G Add On Card (Optional)
• USB Ports: 1 x USB 3.0 Port (Rear), 2 x USB 2.0 Ports (Rear)
• Read/Write Cache: (Optional) Boost performance by adding a dedicated, high-performance read cache (L2ARC) or by adding a dedicated, high-performance write cache (ZIL/SLOG)
• PCIe Expansion: 1 x PCI Express 3.0 x 4
• Power Supply: 100V to 240V AC, 50/60 HZ, Single Phase
• Power Consumption (Maximum): Diskless: 63W With drives & 10G Add-on-card: 167W
• Power Management: Remote Power-On/Off (IPMI), UPS Signal Response and Alerts
• User Control Interface: Web Browser and Remote Hardware Management (IPMI)
• Accessories: Basic Setup Guide, 2 x bezel keys, bag of HDD screws, 2 x 7 ft cat6 copper cable, Bezel, 4 x Adhesive Rubber Feet, Short Rail Kit – 19? to 26.6? rackmount depth, Optional Long Rail Kit available – 26.5? to 36.4? rackmount depth
• Dimensions(W x D x H): 17.2? x 21? x 3.5? / 437 × 533 × 89mm
• Weight: 18.7lbs / 8.5Kg
• Warranty: 1 Year Warranty

iXsystems TrueNAS Mini X Plus Enterprise Storage

iXsystems TrueNAS Mini X Plus Enterprise Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: iXsystems
• Model No: iXsystems TrueNAS Mini X Plus Storage
• Chassis: 5+2 Bay Enclosure – Super Quiet Design
• Drive Bays: 5 x SATA 3.5” Hot-Swappable Drive Bays(Optional 3.5? to 2.5? adaptors available), 2 x SATA 2.5” Hot-Swappable SSD Bays
• Maximum Raw Capacity: Up to 105 TB
• CPU: Octa-core C3758 Intel CPU
• Memory: 32 GB DDR4 with ECC (Upgradeable to 64GB)
• RAID: OpenZFS – RAIDZ1 (RAID 5), RAIDZ2 (RAID 6), Multi-Disk Mirror (RAID 10), and RAID0 (stripe)
• Disk Management: Hot-Swappable Drives, Bad Block Scan + HDD S.M.A.R.T, ISO Mounting Support, Hardware-Accelerated Disk Encryption
• Network: Standard: 2 x RJ45 1/10GBaseT Ethernet LAN ports, Dedicated RJ45 IPMI Port (Remote Hardware Management), 2 x SFP+ 10G Add On Card (Optional)
• USB Ports: 1 x USB 3.0 Port (Front), 1 x USB 2.0 Port (Front), 2 x USB 2.0 Ports (Rear)
• Read/Write Cache: (Optional) Boost performance by adding a dedicated, high-performance read cache (L2ARC) or by adding a dedicated, high-performance write cache (ZIL/SLOG)
• PCIe Expansion: 1 x PCI Express 3.0 x 4
• Power Supply: 100V to 240V AC, 50/60 HZ, Single Phase
• Power Consumption (Maximum): Diskless: 40W With drives & 10G Add-on-card: 111W
• Power Management: Remote Power-On/Off (IPMI), UPS Signal Response and Alerts
• User Control Interface: Web Browser and Remote Hardware Management (IPMI)
• Accessories: Basic Setup Guide, 2 x Case Door Keys, bag of HDD screws, 2 x 7 ft cat6 copper cable
• Dimensions(W x D x H): 8.25? x 10.5? x 9.5? / 210 x 267 x 241mm
• Weight: 13lbs / 5.9Kg
• Warranty: 1 Year Warranty

iXsystems TrueNAS Mini X Enterprise Storage

iXsystems TrueNAS Mini X Enterprise Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: iXsystems
• Model No: iXsystems TrueNAS Mini X Storage
• Chassis: 5+2 Bay Enclosure – Super Quiet Design
• Drive Bays: 5 x SATA 3.5” Hot-Swappable Drive Bays(Optional 3.5? to 2.5? adaptors available), 2 x SATA 2.5” Hot-Swappable SSD Bays
• Maximum Raw Capacity: Up to 90 TB
• CPU: Quad-core C3558 Intel CPU
• Memory: 16 GB DDR4 with ECC (Upgradeable to 32GB)
• RAID: OpenZFS – RAIDZ1 (RAID 5), RAIDZ2 (RAID 6), Multi-Disk Mirror (RAID 10), and RAID0 (stripe)
• Disk Management: Hot-Swappable Drives, Bad Block Scan + HDD S.M.A.R.T, ISO Mounting Support, Hardware-Accelerated Disk Encryption
• Network: Standard: 4 x 1 Gigabit Ethernet LAN ports (10/100/1000), Dedicated RJ45 IPMI Port (Remote Hardware Management)
• USB Ports: 2 x USB 2.0 Ports (Front), 1 x USB 3.0 Port (Rear)
• Read/Write Cache: (Optional) Boost performance by adding a dedicated, high-performance read cache (L2ARC) or by adding a dedicated, high-performance write cache (ZIL/SLOG)
• PCIe Expansion: N/A
• Power Supply: 100V to 240V AC, 50/60 HZ, Single Phase
• Power Consumption (Maximum): Diskless-24W With drives: 84W
• Power Management: Remote Power-On/Off (IPMI), UPS Signal Response and Alerts
• User Control Interface: Web Browser and Remote Hardware Management (IPMI)
• Accessories: Basic Setup Guide, 2 x Case Door Keys, bag of HDD screws, 2 x 7 ft cat6 copper cable
• Dimensions(W x D x H): 8.25? x 10.5? x 9.5? / 210 x 267 x 241mm
• Weight: 13lbs / 5.9Kg
• Warranty: 1 Year Warranty

NetApp AFF A400 All Flash Data Array

NetApp AFF A400 All Flash Data Array Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: NetApp
• Model No: NetApp AFF A400 All Flash Data Storage
• Maximum scale-out: 2–24 nodes(12 HA pairs)
• Maximum SSD: 5760
• Maximum effective capacity: 702.7PB
• Controller chassis form factor: 4U
• Power consumption (median): 890W (with DS224C), 1240W (with NS224)
• PCIe expansion slots: 10
• FC target ports(64Gb autoranging): n/a
• FC target ports(32Gb autoranging): 24
• FC target ports(16Gb autoranging): 32 (with FC mezzanine card)
• FCoE target ports, UTA2: n/a
• 200GbE ports(100GbE/40GbE autoranging): n/a
• 100GbE ports(40GbE autoranging): 16
• 25GbE ports(10GbE autoranging): 16
• 10GbE Ports: 32
• 10GBASE-T(1GbE autoranging): 16
• 12Gb/6Gb SAS ports: 32
• Storage networking supported: NFSv4/RDMA, NVMe/TCP, NVMe/FC, FC, iSCSI, NFS, pNFS, CIFS/SMB, Amazon S3
• Host/client OS supported: Windows Server, Linux, Oracle Solaris, IBM AIX, HP-UX, macOS, VMware ESX

NetApp AFF A800 All Flash Data Array

NetApp AFF A800 All Flash Data Array Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: NetApp
• Model No: NetApp AFF A800 All Flash Data Storage
• Maximum scale-out: 2–24 nodes(12 HA pairs)
• Maximum SSD: 2880
• Maximum effective capacity: 185PB
• Controller chassis form factor: 4U; 48 internal SSD slots
• Power consumption (median): 1463W
• PCIe expansion slots: 8
• FC target ports(64Gb autoranging): n/a
• FC target ports(32Gb autoranging): 32
• FC target ports(16Gb autoranging): 32
• FCoE target ports, UTA2: n/a
• 200GbE ports(100GbE/40GbE autoranging): n/a
• 100GbE ports(40GbE autoranging): 20
• 25GbE ports(10GbE autoranging): 16
• 10GbE Ports: 32
• 10GBASE-T(1GbE autoranging): n/a
• 12Gb/6Gb SAS ports: n/a
• Storage networking supported: NFSv4/RDMA, NVMe/TCP, NVMe/FC, FC, iSCSI, NFS, pNFS, CIFS/SMB, Amazon S3
• Host/client OS supported: Windows Server, Linux, Oracle Solaris, IBM AIX, HP-UX, macOS, VMware ESX

NetApp AFF A900 All Flash Data Array

NetApp AFF A900 All Flash Data Array Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: NetApp
• Model No: NetApp AFF A900 All Flash Data Storage
• Maximum scale-out: 2–24 nodes(12 HA pairs)
• Maximum SSD: 5760
• Maximum effective capacity: 702.7PB
• Controller chassis form factor: 8U
• Power consumption (median): 2450W (with NS224)
• PCIe expansion slots: 20
• FC target ports(64Gb autoranging): n/a
• FC target ports(32Gb autoranging): 64
• FC target ports(16Gb autoranging): 64
• FCoE target ports, UTA2: 64
• 200GbE ports(100GbE/40GbE autoranging): n/a
• 100GbE ports(40GbE autoranging): 32
• 25GbE ports(10GbE autoranging): 64
• 10GbE Ports: 64
• 10GBASE-T(1GbE autoranging): 64
• 12Gb/6Gb SAS ports: 64
• Storage networking supported: NVMe/TCP, NVMe/FC, FC, iSCSI, NFS, pNFS, CIFS/SMB, Amazon S3
• Host/client OS supported: Windows Server, Linux, Oracle Solaris, IBM AIX, HP-UX, macOS, VMware ESX

Seagate Exos Corvault 5U84 Data Storage System

Seagate Exos Corvault 5U84 Data Storage System Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Seagate
• Model No: R5U84I1500S001
• Product: Seagate Exos Corvault 5U84 5U Storage
• Form Factor: 5U High × 1.0M Deep Rackmount
• Capacity: Up to 1.5PB
• Host Port: Mini-SAS HD 4 Ports on Each Controller 8 Ports per System
• Host Interface: 12 Gb SAS
• System Availability and Data Durability: 99.999%
• Watt per Terabyte Power Consumption: 0.8 W/TB
• Data Protection: Seagate ADAPT erasure coding
• Disk Drive Self healing technology: Autonomous Drive Regeneration (ADR)
• Warranty: 5 Years

Seagate Exos Corvault 4U106 Data Storage

Seagate Exos Corvault 4U106 Data Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Seagate
• Model No: R4106I212000001 | R4106I2000S002 (EU version)
• Product: Seagate Exos Corvault 4U106 2.1PB Storage
• Form Factor: 4U High × 1.2M Deep Rackmount
• Capacity: Up to 2.1PB
• Host Port: Mini-SAS HD 4 Ports on Each Controller 8 Ports per System
• Host Interface: 12 Gb SAS
• System Availability and Data Durability: 99.999%
• Watt per Terabyte Power Consumption: 0.48 W/TB
• Data Protection: Seagate ADAPT erasure coding
• Disk Drive Self healing technology: Autonomous Drive Regeneration (ADR)
• Warranty: 5 Years

Seagate Exos Corvault 4U106 2000TB Data Storage System

Seagate Exos Corvault 4U106 2000TB Data Storage System Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Seagate
• Model No: R4106I2000T002
• Product: Seagate Exos Corvault 4U106 2PB Storage
• Form Factor: 4U High × 1.2M Deep Rackmount
• Capacity: Up to 2PB
• Host Port: Mini-SAS HD 4 Ports on Each Controller 8 Ports per System
• Host Interface: 12 Gb SAS
• System Availability and Data Durability: 99.999%
• Watt per Terabyte Power Consumption: 0.48 W/TB
• Data Protection: Seagate ADAPT erasure coding
• Disk Drive Self healing technology: Autonomous Drive Regeneration (ADR)
• Warranty: 5 Years

Seagate Exos Corvault 4U106 Data Storage System

Seagate Exos Corvault 4U106 Data Storage System Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Seagate
• Model No: R4106I2500T002
• Product: Seagate Exos Corvault 4U106 2.5 PB Storage
• Form Factor: 4U High × 1.2M Deep Rackmount
• Capacity: Up to 2.5PB
• Host Port: Mini-SAS HD 4 Ports on Each Controller 8 Ports per System
• Host Interface: 12 Gb SAS
• System Availability and Data Durability: 99.999%
• Watt per Terabyte Power Consumption: 0.48 W/TB
• Data Protection: Seagate ADAPT erasure coding
• Disk Drive Self healing technology: Autonomous Drive Regeneration (ADR)
• Warranty: 5 Years

Qnap TL R1200PES RP JBOD Storage

Qnap TL R1200PES RP JBOD Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Qnap
• Model No: Qnap TL R1200PES RP 16 Bay JBOD Storage
• JBOD Connection Interface: PCIe
• Drive Bay: 12 x 3.5-inch
• Drive Compatibility: 3.5-inch bays: 3.5-inch SATA 6Gb/s, 3Gb/s hard disk drives, 2.5-inch SATA 6Gb/s, 3Gb/s solid state drives
• Hot-swappable: Yes
• Form Factor: 2U Short Depth Rackmount
• Host Interface: 2 x SFF-8644 1x2 (in, out)
• LED Indicators: Front panel: HDD 1-16, Power, Status, Link, Fan error, Rear panel: SAS connector, Enclosure ID
• Buttons: Power
• Dimensions (HxWxD): 88.65 × 432 × 370.65 mm
• Weight (Net): 9.22 kg
• Operating Temperature: 0 - 40 °C (32°F - 104°F)
• Storage Temperature: -20 - 70°C (-4°F - 158°F)
• Relative Humidity: 5-95% RH non-condensing, wet bulb: 27?C (80.6?F)
• Power Supply Unit: 300W (x2), 100 - 240V
• Power Consumption: HDD Sleep Mode: 43.4 W
• Power Consumption: Operating Mode, Typical: 78.2 W
• Fan: 2 x 80mm, 12VDC
• QTS/QuTS hero: Yes
• Supports JBOD cascading: Yes
• Supports expanding NAS storage pools: Yes
• Warranty: 5 Years Warranty

Qnap TL R1600PES RP JBOD Storage

Qnap TL R1600PES RP JBOD Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Qnap
• Model No: Qnap TL R1600PES RP 16 Bay JBOD Storage
• JBOD Connection Interface: PCIe
• Drive Bay: 16 x 3.5-inch
• Drive Compatibility: 3.5-inch bays: 3.5-inch SATA 6Gb/s, 3Gb/s hard disk drives, 2.5-inch SATA 6Gb/s, 3Gb/s solid state drives
• Hot-swappable: Yes
• Form Factor: 3U Short Depth Rackmount
• Host Interface: 2 x SFF-8644 1x2 (in, out)
• LED Indicators: Front panel: HDD 1-16, Power, Status, Link, Fan error, Rear panel: SAS connector, Enclosure ID
• Buttons: Power
• Dimensions (HxWxD): 131.3 × 432.4 × 370.85 mm
• Weight (Net): 11.56 kg
• Operating Temperature: 0 - 40 °C (32°F - 104°F)
• Storage Temperature: -20 - 70°C (-4°F - 158°F)
• Relative Humidity: 5-95% RH non-condensing, wet bulb: 27?C (80.6?F)
• Power Supply Unit: 550W(x2), 100-240V
• Power Consumption: HDD Sleep Mode: 52.3 W
• Power Consumption: Operating Mode, Typical: 95 W
• Fan: 3 x 80mm, 12VDC
• QTS/QuTS hero: Yes
• Supports JBOD cascading: Yes
• Supports expanding NAS storage pools: Yes
• Warranty: 5 Years Warranty

Qnap TL R1220Sep RP SAS 16 Bay JBOD Storage

Qnap TL R1220Sep RP SAS 16 Bay JBOD Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Qnap
• Model No: Qnap TL R1220Sep RP SAS JBOD Storage
• JBOD Connection Interface: SAS
• Drive Bay: 12 x 3.5-inch
• Drive Compatibility: 3.5-inch bays: 3.5-inch SAS 12Gb/s, 6Gb/s hard disk drives, 3.5-inch SATA 6Gb/s, 3Gb/s hard disk drives, 2.5-inch SATA 6Gb/s, 3Gb/s solid state drives
• Hot-swappable: Yes
• Form Factor: 2U Short Depth Rackmount
• Host Interface: 4 x 12Gb/s SAS 3.0 wide ports (4-wide port) Mini-SAS HD (SFF-8644)
• LED Indicators: Front panel: HDD 1-16, Power, Status, Link, Fan error, Rear panel: SAS connector, Enclosure ID
• Buttons: Power
• Dimensions (HxWxD): 88.65 × 482 × 370.65 mm
• Weight (Net): 10.66 kg
• Operating Temperature: 0 - 40 °C (32°F - 104°F)
• Storage Temperature: -20 - 70°C (-4°F - 158°F)
• Relative Humidity: 5-95% RH non-condensing, wet bulb: 27?C (80.6?F)
• Power Supply Unit: 300W (x2), 100 - 240V
• Power Consumption: Operating Mode, Typical: 163.38 W
• Fan: 2 x 80mm, 12VDC
• QTS / QuTS hero: Yes
• Windows: Yes
• Supports JBOD cascading: Yes
• Supports expanding NAS storage pools: Yes
• Supports Multi-path: Yes
• Warranty: 5 Years Warranty

Qnap TL R1620Sep RP SAS 16 Bay JBOD Storage

Qnap TL R1620Sep RP SAS 16 Bay JBOD Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Qnap
• Model No: Qnap TL R1620Sep RP SAS JBOD Storage
• JBOD Connection Interface: SAS
• Drive Bay: 16 x 3.5-inch
• Drive Compatibility: 3.5-inch bays: 3.5-inch SAS 12Gb/s, 6Gb/s hard disk drives, 3.5-inch SATA 6Gb/s, 3Gb/s hard disk drives, 2.5-inch SATA 6Gb/s, 3Gb/s solid state drives
• Hot-swappable: Yes
• Form Factor: 3U Short Depth Rackmount
• Host Interface: 4 x 12Gb/s SAS 3.0 wide ports (4-wide port) Mini-SAS HD (SFF-8644)
• LED Indicators: Front panel: HDD 1-16, Power, Status, Link, Fan error, Rear panel: SAS connector, Enclosure ID
• Buttons: Power
• Dimensions (HxWxD): 131.3 × 482.2 × 425.3 mm
• Weight (Net): 13.14 kg
• Operating Temperature: 0 - 40 °C (32°F - 104°F)
• Storage Temperature: -20 - 70°C (-4°F - 158°F)
• Relative Humidity: 5-95% RH non-condensing, wet bulb: 27?C (80.6?F)
• Power Supply Unit: 550W(x2), 100-240V
• Power Consumption: Operating Mode, Typical: 207.13 W
• Fan: 3 x 80mm, 12VDC
• QTS / QuTS hero: Yes
• Windows: Yes
• Supports JBOD cascading: Yes
• Supports expanding NAS storage pools: Yes
• Supports Multi-path: Yes
• Warranty: 5 Years Warranty

Qnap TS h1677AXU RP NAS Enclosure

Qnap TS h1677AXU RP NAS Enclosure Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Qnap
• Model No: Qnap TS h1677AXU RP 16 Bay NAS Storage
• CPU: AMD Ryzen 7 7000 series 8-core/16-thread processor, burst up to 5.3 GHz
• CPU Architecture: 64-bit x86
• Graphic Processors: AMD Radeon™ Graphics
• Floating Point Unit: Yes
• Encryption Engine: (AES-NI)
• Hardware-accelerated Transcoding: Yes
• System Memory: 32 GB UDIMM DDR5 (1x 32 GB)
• Maximum Memory: 192 GB (4 x 48 GB)
• Memory Slot: 4 x UDIMM DDR5, Support optional ECC memory
• Flash Memory: 5GB (Dual boot OS protection)
• Drive Bay: 16 x 3.5-inch SATA 6Gb/s, 3Gb/s
• Drive Compatibility: 3.5-inch SATA hard disk drives, 2.5-inch SATA solid state drives
• Hot-swappable: (Not supported M.2 SSD)
• M.2 Slot: 2 x M.2 2280 PCIe Gen 5 x2 slots
• SSD Cache Acceleration Support: Yes
• GPU pass-through: Yes
• 2.5 Gigabit Ethernet Port (2.5G/1G/100M): 2 (2.5G/1G/100M/10M)
• 10 Gigabit Ethernet Port: 2 x 10GBASE-T (10G/5G/2.5G/1G/100M)
• Wake on LAN (WOL): Yes
• Jumbo Frame: Yes
• PCIe Slot: 3 Slot 1: Gen 4 x 4, Slot 2: Gen 4 x 8 or Gen 4 x 4*, Slot 3: Gen 4 x 4
• USB 3.2 Gen 2 (10Gbps) Port: 2 x Type-A USB 3.2 Gen 2 10Gbps
• Form Factor: 3U Rackmount
• LED Indicators: Power Status, HDD 1-16, M.2 SSD 1-2, Status, LAN, storage expansion port status
• Buttons: Power, Reset
• Dimensions (HxWxD): 131.3 × 482.2 × 550.8 mm
• Weight (Net): 15.64 kg
• Operating Temperature: 0 - 40 °C (32°F - 104°F)
• Storage Temperature: -20 - 70°C (-4°F - 158°F)
• Relative Humidity: 5-95% RH non-condensing, wet bulb: 27?C (80.6?F)
• Power Supply Unit: 550W(x2), 100-240V
• Power Consumption: Disk Standby Mode: 99.99 W
• Power Consumption: Operating Mode, Typical: 349.96 W
• Fan: System fan: 3 x 60mm, 12VDC
• Max. Number of Concurrent Connections (CIFS) - with Max. Memory 5000
• Warranty: 5 Years Warranty

Asustor AS6004U NAS Storage

Asustor AS6004U NAS Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Asustor
• Part No: AS6004U
• Model No: Asustor AS6004U 4 Bay NAS Storage
• Flash Memory: 16MB Flash
• Expansion: USB3.2 Gen 1 Type B
• HDD: 4 x SATA3 6Gb/s; 3.5"/2.5" HDD/SSD
• Maximum Internal Raw Capacity: 88 TB (22 TB HDD X 4, Capacity may vary by RAID types)
• AS10, AS-20, AS-30 Maximum Single Volume Size: 16TB
• Supports Hot Swappable Drives
• System Fan: 120mm x1
• Power Supply Unit / Adapter: 90W x1
• Input Power Voltage: 100V to 240V AC
• Power Consumption: Operation: 23.6 W, Disk Hibernation: 9.7 W, Sleep Mode: 0.35 W
• Operation Temperature: 0°C~40°C (32°F~104°F)
• Humidity: 5% to 95% RH
• Dimensions (HxWxD): 185.5(H) x 170(W) x 230(D) mm
• Weight: 2.7 kg
• Warranty: 3 Years Warranty

Asustor Lockerstor 16R Pro Gen2 AS7216RDX 16 Bay NAS Storage

Asustor Lockerstor 16R Pro Gen2 AS7216RDX 16 Bay NAS Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Asustor
• Part No: AS7216RDX
• Model No: Asustor Lockerstor 16R Pro Gen2 AS7216RDX NAS Storage
• CPU Model: AMD Ryzen 7 Pro 7745
• CPU Architecture: x64 64-bit
• CPU Frequency: 3.8GHz up to 5.3GHz
• Memory: 16GB ECC DDR5-4800 UDIMM
• Memory Module Pre-installed: 16GB (1x 16GB)
• Total Memory Slots: 4
• Memory Expandable up to: 192GB (4x 48GB), Support mixed capacity
• Flash Memory: 32GB SATA DOM
• Drive Bays: 16
• M.2 Drive Slots: 1
• Compatible Drive Type: 3.5" SATA HDD, 2.5" SATA HDD, 2.5" SATA SSD, M.2 2280 NVMe
• M.2 PCIe Interface: PCIe 5.0 x4
• Maximum Drive Bays with Expansion Unit: 40
• Supports Hot Swappable Drives: Yes
• Expansion: 4x USB 3.2 Gen 2 (10Gbps) Type-A
• Network: 2 x Gigabit Ethernet (1G/100M, WOL), 2 x 10Gigabit Ethernet (10G/1G)
• PCIe Expansion Slots: 1 x Gen5 x8 slot (x8 link); 1 x Gen5 x4 slot (x4 link) for optional 10/25/40/50 GbE card and SAS card
• Multimedia Output: HDMI x1 (for service only)
• System Fan: 3x 60mm
• Power Supply Unit/Adapter: 550W x2
• Input Power Voltage: 100V to 240V AC
• Redundant power supply: Yes
• Service LED Indicator: Yes
• Power Consumption: 187W (Operation); 128W (Disk Hibernation)
• Noise Level: Null
• Operation Temperature: 0°C~40°C (32°F~104°F)
• Storage Temperature: -20°C~70°C (-4°F~158°F)
• Humidity: 5% to 95% RH
• Dimensions (HxWxD): 116(H) x 439(W) x 576(D) mm
• Weight: 15.3 kg
• Warranty: 5 Years Warranty

Asustor Lockerstor 12R Pro Gen2 AS7212RDX 12 Bay NAS Storage

Asustor Lockerstor 12R Pro Gen2 AS7212RDX 12 Bay NAS Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Asustor
• Part No: AS7112RDX
• Model No: Asustor Lockerstor 12R Pro AS7112RDX NAS Storage
• CPU Model: AMD Ryzen 7 Pro
• CPU Architecture: x64 64-bit
• CPU Frequency: 3.8GHz up to 5.3GHz
• Memory: 16GB ECC DDR5-4800 UDIMM
• Memory Module Pre-installed: 16GB (1x 16GB)
• Total Memory Slots: 4
• Memory Expandable up to: 192GB (4x 48GB), Support mixed capacity
• Flash Memory: 32GB SATA DOM
• Drive Bays: 12
• M.2 Drive Slots: 1
• Compatible Drive Type: 3.5" SATA HDD, 2.5" SATA HDD, 2.5" SATA SSD, M.2 2280 NVMe
• M.2 PCIe Interface: PCIe 5.0 x4
• Maximum Drive Bays with Expansion Unit: 36
• Supports Hot Swappable Drives: Yes
• Expansion: 4x USB 3.2 Gen 2 (10Gbps) Type-A
• Network: 2 x Gigabit Ethernet (1G/100M, WOL), 2 x 10Gigabit Ethernet (10G/1G)
• PCIe Expansion Slots: 1 x Gen5 x8 slot (x8 link); 1 x Gen5 x4 slot (x4 link) for optional 10/25/40/50 GbE card and SAS card
• Multimedia Output: HDMI x1 (for service only)
• System Fan: 3x 60mm
• Power Supply Unit/Adapter: 550W x2
• Input Power Voltage: 100V to 240V AC
• Redundant power supply: Yes
• Service LED Indicator: Yes
• Power Consumption: 102W (Operation); 99W (Disk Hibernation)
• Noise Level: Null
• Operation Temperature: 0°C~40°C (32°F~104°F)
• Storage Temperature: -20°C~70°C (-4°F~158°F)
• Humidity: 5% to 95% RH
• Dimensions (HxWxD): 88(H) x 439(W) x 576(D) mm
• Weight: 14 kg
• Warranty: 5 Years Warranty

Asustor Lockerstor 16R Pro AS7116RDX 16 Bay NAS Storage

Asustor Lockerstor 16R Pro AS7116RDX 16 Bay NAS Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Asustor
• Part No: AS7116RDX
• Model No: Asustor Lockerstor 16R Pro AS7116RDX NAS Storage
• CPU Model: Intel Xeon E-2224
• CPU Architecture: x64 64-bit
• CPU Frequency: Quad-Core 3.4GHz up to 4.6GHz
• Memory: 8GB DDR4-2666 ECC UDIMM
• Memory Module Pre-installed: 8GB (1x 8GB)
• Total Memory Slots: 4
• Memory Expandable up to: 128GB (4x 32GB), Support mixed capacity
• Flash Memory: 8GB USB DOM
• Drive Bays: 16
• M.2 Drive Slots: 2
• Compatible Drive Type: 3.5" SATA HDD, 2.5" SATA HDD, 2.5" SATA SSD, M.2 22110 NVMe, M.2 2280 NVMe, M.2 2280 SATA 3, M.2 2260 SATA 3, M.2 2242 SATA 3
• M.2 PCIe Interface: PCIe 3.0 x4
• Maximum Drive Bays with Expansion Unit: 28
• Supports Hot Swappable Drives: Yes
• Expansion: 4x USB 3.2 Gen 2 (10Gbps) Type-A, 2x USB 3.2 Gen 2 (10Gbps) Type-C
• Network: 4x Gigabit Ethernet (1G/100M)
• PCIe Expansion Slots: 2x Gen3x4 slots (x4 link) ; 1x Gen3x8 slots (x8 link) for optional 10/25/40/50 GbE card and SAS card
• Multimedia Output: N/A
• System Fan: 3x 60mm
• Power Supply Unit/Adapter: 550W x2
• Input Power Voltage: 100V to 240V AC
• Redundant power supply: Yes
• Service LED Indicator: Yes
• Power Consumption: 121.7W (Operation); 51.5W (Disk Hibernation), 7.55 W (Sleep Mode)
• Noise Level: Null
• Operation Temperature: 0°C~40°C (32°F~104°F)
• Storage Temperature: -20°C~70°C (-4°F~158°F)
• Humidity: 5% to 95% RH
• Dimensions (HxWxD): 132(H) x 439(W) x 535(D) mm
• Weight: 15.3 kg
• Warranty: 5 Years Warranty

Asustor Lockerstor 12R Pro AS7112RDX 12 Bay NAS Storage

Asustor Lockerstor 12R Pro AS7112RDX 12 Bay NAS Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Asustor
• Part No: AS7112RDX
• Model No: Asustor Lockerstor 12R Pro AS7112RDX NAS Storage
• CPU Model: Intel Xeon E-2224
• CPU Architecture: x64 64-bit
• CPU Frequency: Quad-Core 3.4GHz up to 4.6GHz
• Memory: 8GB DDR4-2666 ECC UDIMM
• Memory Module Pre-installed: 8GB (1x 8GB)
• Total Memory Slots: 4
• Memory Expandable up to: 128GB (4x 32GB), Support mixed capacity
• Flash Memory: 8GB USB DOM
• Drive Bays: 12
• M.2 Drive Slots: 2
• Compatible Drive Type: 3.5" SATA HDD, 2.5" SATA HDD, 2.5" SATA SSD, M.2 22110 NVMe, M.2 2280 NVMe, M.2 2280 SATA 3, M.2 2260 SATA 3, M.2 2242 SATA 3
• M.2 PCIe Interface: PCIe 3.0 x4
• Maximum Drive Bays with Expansion Unit: 24
• Supports Hot Swappable Drives: Yes
• Expansion: 4x USB 3.2 Gen 2 (10Gbps) Type-A, 2x USB 3.2 Gen 2 (10Gbps) Type-C
• Network: 2x Gigabit Ethernet (1G/100M)
• PCIe Expansion Slots: 2x Gen3x4 slots (x4 link) ; 1x Gen3x8 slots (x8 link) for optional 10/25/40/50 GbE card and SAS card
• Multimedia Output: N/A
• System Fan: 3x 60mm
• Power Supply Unit/Adapter: 550W x2
• Input Power Voltage: 100V to 240V AC
• Redundant power supply: Yes
• Service LED Indicator: Yes
• Power Consumption: 92.4W (Operation); 45.5W (Disk Hibernation), 7.55 W (Sleep Mode)
• Noise Level: Null
• Operation Temperature: 0°C~40°C (32°F~104°F)
• Storage Temperature: -20°C~70°C (-4°F~158°F)
• Humidity: 5% to 95% RH
• Dimensions (HxWxD): 88(H) x 439(W) x 535(D) mm
• Weight: 13 kg
• Warranty: 5 Years Warranty

Asustor Lockerstor 10 Pro AS7110T 10 Bay NAS Storage

Asustor Lockerstor 10 Pro AS7110T 10 Bay NAS Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Asustor
• Part No: AS7110T
• Model No: Asustor Lockerstor 10 Pro AS7110T NAS Storage
• CPU Model: Intel Xeon E-2224
• CPU Architecture: x64 64-bit
• CPU Frequency: Quad-Core 3.4GHz up to 4.6GHz
• Memory: 8GB DDR4 ECC SO-DIMM
• Memory Module Pre-installed: 8GB (1x 8GB)
• Total Memory Slots: 2
• Memory Expandable up to: 64GB (2x 32GB), Support mixed capacity
• Flash Memory: 8GB USB DOM
• Drive Bays: 10
• Compatible Drive Type: 3.5" SATA HDD, 2.5" SATA HDD, 2.5" SATA SSD, M.2 2280 NVMe, M.2 2280 SATA 3, M.2 2260 SATA 3, M.2 2242 SATA 3
• M.2 PCIe Interface: PCIe 3.0 x2
• Maximum Drive Bays with Expansion Unit: 22
• Supports Hot Swappable Drives: Yes
• Expansion: 1x Front USB 3.2 Gen 1, 2x Rear USB 3.2 Gen 2 (10Gbps)
• Network: 1x 10 Gigabit Ethernet (10G/5G/2.5G/1G/100M), 3x 2.5 Gigabit Ethernet (2.5G/1G/100M)
• Multimedia Output: N/A
• System Fan: 2x 120mm
• LCD Panel: Yes
• Power Supply Unit/Adapter: 350W x1
• Input Power Voltage: 100V to 240V AC
• Power Consumption: 78.7W (Operation); 40.1W (Disk Hibernation); 5.8 W (Sleep Mode)
• Noise Level: 22dB (HDD idle)
• Operation Temperature: 0°C~40°C (32°F~104°F)
• Storage Temperature: -20°C~70°C (-4°F~158°F)
• Humidity: 5% to 95% RH
• Dimensions (HxWxD): 215.5(H) x 293(W) x 230(D) mm
• Weight: 7.1 kg
• Warranty: 3 Years Warranty

Asustor Lockerstor 12RD AS6512RD 12 Bay NAS Storage

Asustor Lockerstor 12RD AS6512RD 12 Bay NAS Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Asustor
• Part No: AS6512RD
• Model No: Asustor Lockerstor 12RD AS6512RD NAS Storage
• CPU Model: Intel ATOM C3538
• CPU Architecture: x64 64-bit
• CPU Frequency: Quad-Core 2.1GHz
• Memory: 8GB SO-DIMM DDR4
• Memory Module Pre-installed: 8GB (1x 8GB)
• Total Memory Slots: 4
• Memory Expandable up to: 128GB (4x 32GB), Support mixed capacity
• Flash Memory: 8GB eMMC
• M.2 Drive Slots: 12
• Compatible Drive Type: 3.5" SATA HDD, 2.5" SATA HDD, 2.5" SATA SSD
• Maximum Drive Bays with Expansion Unit: 28
• Supports Hot Swappable Drives: Yes
• Expansion: 4x USB 3.2 Gen 1
• Network: 2x Gigabit Ethernet (1G/100M), 2x 2.5 Gigabit Ethernet (2.5G/1G/100M)
• PCIe Expansion Slots: PCIe 3.0 x8 slot (black, x4 link)
• Multimedia Output: N/A
• System Fan: 2x 60mm
• Power Supply Unit/Adapter: 350W x2
• Input Power Voltage: 100V to 240V AC
• Redundant power supply: Yes
• Service LED Indicator: Yes
• Power Consumption: 115W (Operation), 67W (Disk Hibernation)
• Noise Level: Null
• Operation Temperature: 0°C~40°C (32°F~104°F)
• Storage Temperature: -20°C~70°C (-4°F~158°F)
• Humidity: 5% to 95% RH
• Dimensions (HxWxD): 88(H) x 439(W) x 535(D) mm
• Weight: 11.7 kg
• Warranty: 3 Years Warranty

Asustor Lockerstor 4RD AS6504RD 4 Bay NAS Storage

Asustor Lockerstor 4RD AS6504RD 4 Bay NAS Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Asustor
• Part No: AS6504RD
• Model No: Asustor Lockerstor 4RD AS6504RD NAS Storage
• CPU Model: Intel ATOM C3538
• CPU Architecture: x64 64-bit
• CPU Frequency: Quad-Core 2.1GHz
• Memory: 8GB SO-DIMM DDR4
• Memory Module Pre-installed: 8GB (1x 8GB)
• Total Memory Slots: 4
• Memory Expandable up to: 128GB (4x 32GB), Support mixed capacity
• Flash Memory: 8GB eMMC
• M.2 Drive Slots: 4
• Compatible Drive Type: 3.5" SATA HDD, 2.5" SATA HDD, 2.5" SATA SSD
• Maximum Drive Bays with Expansion Unit: 20
• Supports Hot Swappable Drives: Yes
• Expansion: 4x USB 3.2 Gen 1
• Network: 2x Gigabit Ethernet (1G/100M), 2x 2.5 Gigabit Ethernet (2.5G/1G/100M)
• PCIe Expansion Slots: PCIe 3.0 x8 slot (black, x4 link)
• Multimedia Output: N/A
• System Fan: 2x 40mm
• Power Supply Unit/Adapter: 250W x2
• Input Power Voltage: 100V to 240V AC
• Redundant power supply: Yes
• Service LED Indicator: Yes
• Power Consumption: 65W (Operation) 42.4W (Disk Hibernation)
• Noise Level: Null
• Operation Temperature: 0°C~40°C (32°F~104°F)
• Storage Temperature: -20°C~70°C (-4°F~158°F)
• Humidity: 5% to 95% RH
• Dimensions (HxWxD): 44(H) x 439(W) x 515(D) mm
• Weight: 9.3 kg
• Warranty: 3 Years Warranty

Asustor Lockerstor 4RS AS6504RS 4 Bay NAS Storage

Asustor Lockerstor 4RS AS6504RS 4 Bay NAS Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Asustor
• Part No: AS6504RS
• Model No: Asustor Lockerstor 4RS AS6504RS NAS Storage
• CPU Model: Intel ATOM C3538
• CPU Architecture: x64 64-bit
• CPU Frequency: Quad-Core 2.1GHz
• Memory: 8GB SO-DIMM DDR4
• Memory Module Pre-installed: 8GB (1x 8GB)
• Total Memory Slots: 4
• Memory Expandable up to: 128GB (4x 32GB), Support mixed capacity
• Flash Memory: 8GB eMMC
• M.2 Drive Slots: 4
• Compatible Drive Type: 3.5" SATA HDD, 2.5" SATA HDD, 2.5" SATA SSD
• Maximum Drive Bays with Expansion Unit: 20
• Supports Hot Swappable Drives: Yes
• Expansion: 4x USB 3.2 Gen 1
• Network: 2x Gigabit Ethernet (1G/100M), 2x 2.5 Gigabit Ethernet (2.5G/1G/100M)
• PCIe Expansion Slots: PCIe 3.0 x8 slot (black, x4 link)
• Multimedia Output: N/A
• System Fan: 2x 40mm
• Power Supply Unit/Adapter: 250W x1
• Input Power Voltage: 100V to 240V AC
• Redundant power supply: Yes
• Service LED Indicator: Yes
• Power Consumption: 47.7W (Operation) 28.4W (Disk Hibernation)
• Noise Level: Null
• Operation Temperature: 0°C~40°C (32°F~104°F)
• Storage Temperature: -20°C~70°C (-4°F~158°F)
• Humidity: 5% to 95% RH
• Dimensions (HxWxD): 44(H) x 439(W) x 515(D) mm
• Weight: 7.85 kg
• Warranty: 3 Years Warranty

Asustor Flashstor 12 Pro FS6712X 12 Bay NAS Storage

Asustor Flashstor 12 Pro FS6712X 12 Bay NAS Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Asustor
• Part No: FS6712X
• Model No: Asustor Flashstor 12 Pro FS6712X NAS Storage
• CPU Model: Intel Celeron N5105
• CPU Architecture: x64 64-bit
• CPU Frequency: Quad-Core 2.0GHz (burst up 2.90 GHz)
• Memory: 4GB SO-DIMM DDR4
• Memory Module Pre-installed: 4GB (1x 4GB)
• Total Memory Slots: 2
• Memory Expandable up to: 16GB (2x 8GB), Support mixed capacity
• Flash Memory: 8GB eMMC
• M.2 Drive Slots: 12
• Compatible Drive Type: M.2 2280 NVMe, Heatsinks for compatible NAS devices may be purchased separately if needed
• M.2 PCIe Interface: PCIe 3.0 x1
• Maximum Drive Bays with Expansion Unit: 8
• Expansion: 2x USB 3.2 Gen 2 (10Gbps); 2 x USB 2.0
• Network: 1 x 10 Gigabit Ethernet (10G/5G/2.5G/1G/100M/10M)
• Multimedia Output: 1x HDMI 2.0b, 1x S/PDIF
• System Fan: 1 x 80mm
• Power Supply Unit/Adapter: 90W x1
• Input Power Voltage: 100V to 240V AC
• Power Consumption: 26W
• Noise Level: 18.7dB
• Operation Temperature: 0°C~40°C (32°F~104°F)
• Storage Temperature: -20°C~70°C (-4°F~158°F)
• Humidity: 5% to 95% RH
• Dimensions (HxWxD): 48.3 (H) x 308.26 (W) x 193 (D) mm
• Weight: 1.37 kg
• Warranty: 3 Years Warranty

Asustor Flashstor 12 Pro Gen2 FS6812X 12 Bay NAS Storage

Asustor Flashstor 12 Pro Gen2 FS6812X 12 Bay NAS Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Asustor
• Part No: FS6812X
• Model No: Asustor Flashstor 12 Pro Gen2 FS6812X NAS Storage
• CPU Model: AMD Ryzen V3C14
• CPU Architecture: x64 64-bit
• CPU Frequency: Quad-Core 2.3GHz (burst up 3.80 GHz)
• Memory: 16GB ECC DDR5-4800 SO-DIMM
• Memory Module Pre-installed: 16GB (1x 16GB)
• Total Memory Slots: 2
• Memory Expandable up to: 64GB Support mixed capacity, Supports ECC memory, ECC functionality will be disabled if non-ECC memory is installed or mixed with ECC memory
• Flash Memory: 8GB eMMC
• Drive Bays: 12
• Compatible Drive Type: M.2 2280 NVMe
• M.2 PCIe Interface: 1x PCIe 4.0 x4, 3x PCIe 4.0 x2, 4x PCIe 4.0 x1, 1x PCIe 3.0 x4, 1x PCIe 3.0 x2, 2x PCIe 3.0 x1
• Maximum Drive Bays with Expansion Unit: 12
• Expansion: 3 x USB 3.2 Gen 2 ( 10Gbps ) Type-A; 2x USB4 ports (20Gbps per channel, 40Gbps per port), Host-to-Host connectivity is not supported, Backwards compatible with USB 3.2 Gen 1 and USB 3.2 Gen 1
• Network: 2 x 10 Gigabit Ethernet (10G/2.5G/1G/100M)
• Multimedia Output: N/A
• System Fan: 1 x 80mm
• Power Supply Unit/Adapter: 120W x1
• Input Power Voltage: 100V to 240V AC
• Power Consumption: 32.2 W (Operation); 2.8 W (Sleep Mode)
• Noise Level: 18.6dB
• Operation Temperature: 0°C~40°C (32°F~104°F)
• Storage Temperature: -20°C~70°C (-4°F~158°F)
• Humidity: 5% to 95% RH
• Dimensions (HxWxD): 48.3 (H) x 308.26 (W) x 193 (D) mm
• Weight: 1.45 kg
• Warranty: 3 Years Warranty

Asustor Flashstor 6 Gen2 FS6806X 6 Bay NAS Storage

Asustor Flashstor 6 Gen2 FS6806X 6 Bay NAS Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

Asustor Flashstor FS6706T NAS Storage

Asustor Flashstor FS6706T NAS Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Asustor
• Part No: FS6706T
• Model No: Asustor Flashstor 6 FS6706T NAS Storage
• CPU Model: Intel Celeron N5105
• CPU Architecture: x64 64-bit
• CPU Frequency: Quad-Core 2.0GHz (burst up 2.90 GHz)
• Memory: 4GB SO-DIMM DDR4
• Memory Module Pre-installed: 4GB (1x 4GB)
• Total Memory Slots: 2
• Memory Expandable up to: 16GB (2x 8GB) Support mixed capacity
• Flash Memory: 8GB eMMC
• Drive Bays: 6
• Compatible Drive Type: M.2 2280 NVMe, Heatsinks for compatible NAS devices may be purchased separately if needed
• M.2 PCIe Interface: PCIe 3.0 x1
• Maximum Drive Bays with Expansion Unit: 8
• Expansion: 2x USB 3.2 Gen 2 (10Gbps); 2 x USB 2.0
• Network: 2x 2.5 Gigabit Ethernet (2.5G/1G/100M)
• Multimedia Output: 1x HDMI 2.0b, 1x S/PDIF
• System Fan: 1 x 80mm
• Power Supply Unit/Adapter: 65W x1
• Input Power Voltage: 100V to 240V AC
• Power Consumption: 18.2 W (Operation); 0.83 W (Sleep Mode)
• Noise Level: 18.7dB
• Operation Temperature: 0°C~40°C (32°F~104°F)
• Storage Temperature: -20°C~70°C (-4°F~158°F)
• Humidity: 5% to 95% RH
• Dimensions (HxWxD): 48.3 (H) x 308.26 (W) x 193 (D) mm
• Weight: 1.35 kg
• Warranty: 3 Years Warranty

Asustor Lockerstor 10 Gen3 AS6810T 10 Bay NAS Storage

Asustor Lockerstor 10 Gen3 AS6810T 10 Bay NAS Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Asustor
• Part No: AS6810T
• Model No: Asustor Lockerstor 10 Gen3 AS6810T NAS Storage
• CPU Model: AMD Ryzen V3C14
• CPU Architecture: x64 64-bit
• CPU Frequency: Quad-Core 2.3GHz (burst up 3.8 GHz)
• Memory: 16GB ECC DDR5-4800 SO-DIMM
• Memory Module Pre-installed: 16GB (1x 16GB)
• Total Memory Slots: 2
• Memory Expandable up to: 64GB Support mixed capacity, Supports ECC memory, ECC functionality will be disabled if non-ECC memory is installed or mixed with ECC memory
• Flash Memory: 8GB eMMC
• Drive Bays: 10
• M.2 Drive Slots: 4
• Compatible Drive Type: 3.5" SATA HDD, 2.5" SATA HDD, 2.5" SATA SSD, M.2 2280 NVMe
• M.2 PCIe Interface: PCIe 4.0 x1
• Maximum Drive Bays with Expansion Unit: 22
• Supports Hot Swappable Drives: Yes
• Expansion: 3 x USB 3.2 Gen 2 ( 10Gbps ) Type-A, 2x USB4 ports (20Gbps per channel, 40Gbps per port), Host-to-Host connectivity is not supported, Backwards compatible with USB 3.2 Gen 1 and USB 3.2 Gen 1
• Network: 2x 5 Gigabit Ethernet (5G/2.5G/1G/100M), 2x 10 Gigabit Ethernet (10G/2.5G/1G/100M)
• PCIe Expansion Slots: 1x for optional expansion 10 GbE card (Removal of m.2 card necessary for expansion card installation)
• Multimedia Output: N/A
• System Fan: 2x 120mm
• LCD Panel: Yes
• Power Supply Unit/Adapter: 250W x1
• Input Power Voltage: 100V to 240V AC
• Power Consumption: 68 W (Operation); 2.4 W (Sleep Mode)
• Noise Level: 22dB (HDD idle)
• Operation Temperature: 0°C~40°C (32°F~104°F)
• Storage Temperature: -20°C~70°C (-4°F~158°F)
• Humidity: 5% to 95% RH
• Dimensions (HxWxD): 215.5(H) x 293(W) x 230(D) mm
• Weight: 6.55 kg
• Warranty: 3 Years Warranty

Asustor Lockerstor 8 AS6808T NAS Storage

Asustor Lockerstor 8 AS6808T NAS Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Asustor
• Part No: AS6808T
• Model No: Asustor Lockerstor 8 Gen3 AS6808T NAS Storage
• CPU Model: AMD Ryzen V3C14
• CPU Architecture: x64 64-bit
• CPU Frequency: Quad-Core 2.3GHz (burst up 3.8 GHz)
• Memory: 16GB ECC DDR5-4800 SO-DIMM
• Memory Module Pre-installed: 16GB (1x 16GB)
• Total Memory Slots: 2
• Memory Expandable up to: 64GB Support mixed capacity, Supports ECC memory, ECC functionality will be disabled if non-ECC memory is installed or mixed with ECC memory
• Flash Memory: 8GB eMMC
• Drive Bays: 8
• M.2 Drive Slots: 4
• Compatible Drive Type: 3.5" SATA HDD, 2.5" SATA HDD, 2.5" SATA SSD, M.2 2280 NVMe
• M.2 PCIe Interface: PCIe 4.0 x1
• Maximum Drive Bays with Expansion Unit: 20
• Supports Hot Swappable Drives: Yes
• Expansion: 3 x USB 3.2 Gen 2 ( 10Gbps ) Type-A, 2x USB4 ports (20Gbps per channel, 40Gbps per port), Host-to-Host connectivity is not supported, Backwards compatible with USB 3.2 Gen 1 and USB 3.2 Gen 1
• Network: 2x 5 Gigabit Ethernet (5G/2.5G/1G/100M), 2x 10 Gigabit Ethernet (10G/2.5G/1G/100M)
• PCIe Expansion Slots: 1x for optional expansion 10 GbE card (Removal of m.2 card necessary for expansion card installation)
• Multimedia Output: N/A
• System Fan: 2x 120mm
• LCD Panel: Yes
• Power Supply Unit/Adapter: 250W x1
• Input Power Voltage: 100V to 240V AC
• Power Consumption: 58.5 W (Operation); 2.4 W (Sleep Mode)
• Noise Level: 22dB (HDD idle)
• Operation Temperature: 0°C~40°C (32°F~104°F)
• Storage Temperature: -20°C~70°C (-4°F~158°F)
• Humidity: 5% to 95% RH
• Dimensions (HxWxD): 215.5(H) x 293(W) x 230(D) mm
• Weight: 6.45 kg
• Warranty: 3 Years Warranty

Asustor Lockerstor 6 Gen3 AS6806T 6 Bay NAS Storage

Asustor Lockerstor 6 Gen3 AS6806T 6 Bay NAS Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Asustor
• Part No: AS6806T
• Model No: Asustor Lockerstor 6 Gen3 AS6806T NAS Storage
• CPU Model: AMD Ryzen V3C14
• CPU Architecture: x64 64-bit
• CPU Frequency: Quad-Core 2.3GHz (burst up 3.8 GHz)
• Memory: 16GB ECC DDR5-4800 SO-DIMM
• Memory Module Pre-installed: 16GB (1x 16GB)
• Total Memory Slots: 2
• Memory Expandable up to: 64GB Support mixed capacity, Supports ECC memory, ECC functionality will be disabled if non-ECC memory is installed or mixed with ECC memory
• Flash Memory: 8GB eMMC
• Drive Bays: 6
• M.2 Drive Slots: 4
• Compatible Drive Type: 3.5" SATA HDD, 2.5" SATA HDD, 2.5" SATA SSD, M.2 2280 NVMe
• M.2 PCIe Interface: PCIe 3.0 x1
• Maximum Drive Bays with Expansion Unit: 18
• Supports Hot Swappable Drives: Yes
• Expansion: 3 x USB 3.2 Gen 2( 10Gbps ) Type-A, 2 x USB 4.0 (40Gbps) Type-C
• Network: 2x 5 Gigabit Ethernet (5G/2.5G/1G/100M), 2x 10 Gigabit Ethernet (10G/2.5G/1G/100M)
• PCIe Expansion Slots: 1x for optional expansion 10 GbE card (Removal of m.2 card necessary for expansion card installation)
• Multimedia Output: N/A
• System Fan: 1x 120mm
• LCD Panel: Yes
• Power Supply Unit/Adapter: 250W x1
• Input Power Voltage: 100V to 240V AC
• Power Consumption: 45 W (Operation); 2.3 W (Sleep Mode)
• Noise Level: 18.1dB (HDD idle)
• Operation Temperature: 0°C~40°C (32°F~104°F)
• Storage Temperature: -20°C~70°C (-4°F~158°F)
• Humidity: 5% to 95% RH
• Dimensions (HxWxD): 185.5 (H) x 233 (W) x 230 (D) mm
• Weight: 4.4 kg
• Warranty: 3 Years Warranty

Asustor Lockerstor 4 Gen3 AS6804T 4 Bay NAS Storage

Asustor Lockerstor 4 Gen3 AS6804T 4 Bay NAS Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Asustor
• Part No: AS6804T
• Model No: Asustor Lockerstor 4 Gen3 AS6804T NAS Storage
• CPU Model: AMD Ryzen V3C14
• CPU Architecture: x64 64-bit
• CPU Frequency: Quad-Core 2.3GHz (burst up 3.8 GHz)
• Memory: 16GB ECC DDR5-4800 SO-DIMM
• Memory Module Pre-installed: 16GB (1x 16GB)
• Total Memory Slots: 2
• Memory Expandable up to: 64GB Support mixed capacity, Supports ECC memory, ECC functionality will be disabled if non-ECC memory is installed or mixed with ECC memory
• Flash Memory: 8GB eMMC
• Drive Bays: 4
• M.2 Drive Slots: 4
• Compatible Drive Type: 3.5" SATA HDD, 2.5" SATA HDD, 2.5" SATA SSD, M.2 2280 NVMe
• M.2 PCIe Interface: PCIe 4.0 x1
• Maximum Drive Bays with Expansion Unit: 16
• Supports Hot Swappable Drives: Yes
• Expansion: 3 x USB 3.2 Gen 2 ( 10Gbps ) Type-A, 2x USB4 ports (20Gbps per channel, 40Gbps per port), Host-to-Host connectivity is not supported, Backwards compatible with USB 3.2 Gen 1 and USB 3.2 Gen 1
• Network: 2x 5 Gigabit Ethernet (5G/2.5G/1G/100M), 2x 10 Gigabit Ethernet (10G/2.5G/1G/100M)
• PCIe Expansion Slots: 1x for optional expansion 10 GbE card (Removal of m.2 card necessary for expansion card installation)
• Multimedia Output: N/A
• System Fan: 1x 120mm
• LCD Panel: Yes
• Power Supply Unit/Adapter: 90W x1
• Input Power Voltage: 100V to 240V AC
• Power Consumption: 34 W (Operation); 2.3 W (Sleep Mode)
• Noise Level: 17.6dB (HDD idle)
• Operation Temperature: 0°C~40°C (32°F~104°F)
• Storage Temperature: -20°C~70°C (-4°F~158°F)
• Humidity: 5% to 95% RH
• Dimensions (HxWxD): 185.5(H) x 170(W) x 230(D) mm
• Weight: 3.2 kg
• Warranty: 3 Years Warranty

Asustor Lockerstor 6 Gen2 AS6706T 6 Bay NAS Storage

Asustor Lockerstor 6 Gen2 AS6706T 6 Bay NAS Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Asustor
• Part No: AS6706T
• Model No: Asustor Lockerstor 6 Gen2 AS6706T NAS Storage
• CPU Model: Intel Celeron N5105
• CPU Architecture: x64 64-bit
• CPU Frequency: Quad-Core 2.0GHz (burst up 2.90 GHz)
• Memory: 8GB SO-DIMM DDR4
• Memory Module Pre-installed: 8GB (1x 4GB)
• Total Memory Slots: 2
• Memory Expandable up to: 16GB(2x 8GB) Support mixed capacity
• Flash Memory: 8GB eMMC
• Drive Bays: 6
• M.2 Drive Slots: 4
• Compatible Drive Type: 3.5" SATA HDD, 2.5" SATA HDD, 2.5" SATA SSD, M.2 2280 NVMe
• M.2 PCIe Interface: PCIe 3.0 x1
• Maximum Drive Bays with Expansion Unit: 14
• Supports Hot Swappable Drives: Yes
• Expansion: 2x USB 3.2 Gen 2(10Gbps)
• Network: 2x 2.5 Gigabit Ethernet (2.5G/1G/100M)
• PCIe Expansion Slots: 1x for optional expansion 10 GbE card (Removal of m.2 card necessary for expansion card installation)
• Multimedia Output: 1x HDMI 2.0b
• System Fan: 1x 120mm
• LCD Panel: Yes
• Infrared Receiver: Yes
• Power Supply Unit/Adapter: 250W x1
• Input Power Voltage: 100V to 240V AC
• Power Consumption: 48.5 W (Operation); 27.7 W (Disk Hibernation); 0.81 W (Sleep Mode)
• Noise Level: 18.1dB (HDD idle)
• Operation Temperature: 0°C~40°C (32°F~104°F)
• Storage Temperature: -20°C~70°C (-4°F~158°F)
• Humidity: 5% to 95% RH
• Dimensions (HxWxD): 185.5 (H) x 233 (W) x 230 (D) mm
• Weight: 4.4 kg
• Warranty: 3 Years Warranty

Asustor Lockerstor 4 AS6704T 4 Bay NAS Storage

Asustor Lockerstor 4 AS6704T 4 Bay NAS Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Asustor
• Part No: AS6704T
• Model No: Asustor Lockerstor 4 Gen2 AS6704T NAS Storage
• CPU Model: Intel Celeron N5105
• CPU Architecture: x64 64-bit
• CPU Frequency: Quad-Core 2.0GHz (burst up 2.90 GHz)
• Memory: 4GB SO-DIMM DDR4
• Memory Module Pre-installed: 4GB (1x 4GB)
• Total Memory Slots: 2
• Memory Expandable up to: 16GB(2x 8GB) Support mixed capacity
• Flash Memory: 8GB eMMC
• Drive Bays: 4
• M.2 Drive Slots: 4
• Compatible Drive Type: 3.5" SATA HDD, 2.5" SATA HDD, 2.5" SATA SSD, M.2 2280 NVMe
• M.2 PCIe Interface: PCIe 3.0 x1
• Maximum Drive Bays with Expansion Unit: 12
• Supports Hot Swappable Drives: Yes
• Expansion: 2x USB 3.2 Gen 2(10Gbps)
• Network: 2x 2.5 Gigabit Ethernet (2.5G/1G/100M)
• PCIe Expansion Slots: 1x for optional expansion 10 GbE card (Removal of m.2 card necessary for expansion card installation)
• Multimedia Output: 1x HDMI 2.0b
• System Fan: 1x 120mm
• LCD Panel: Yes
• Infrared Receiver: Yes
• Power Supply Unit/Adapter: 90W x1
• Input Power Voltage: 100V to 240V AC
• Power Consumption: 35 W (Operation); 17.3 W (Disk Hibernation); 0.88 W (Sleep Mode)
• Noise Level: 17.6dB (HDD idle)
• Operation Temperature: 0°C~40°C (32°F~104°F)
• Storage Temperature: -20°C~70°C (-4°F~158°F)
• Humidity: 5% to 95% RH
• Dimensions (HxWxD): 185.5(H) x 170(W) x 230(D) mm
• Weight: 2.94 kg
• Warranty: 3 Years Warranty

Asustor Lockerstor 2 AS6702T Gen2 NAS Storage

Asustor Lockerstor 2 AS6702T Gen2 NAS Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Asustor
• Part No: AS6702T
• Model No: Asustor Lockerstor 2 AS6702T NAS Storage
• CPU Model: Intel Celeron N5105
• CPU Architecture: x64 64-bit
• CPU Frequency: Quad-Core 2.0GHz(burst up 2.90 GHz)
• Memory: 4GB SO-DIMM DDR4
• Memory Module Pre-installed: 4GB (1x 4GB)
• Total Memory Slots: 2
• Memory Expandable up to: 16GB (2x 8GB) Support mixed capacity
• Flash Memory: 8GB eMMC
• Drive Bays: 2
• M.2 Drive Slots: 4
• Compatible Drive Type: 3.5" SATA HDD, 2.5" SATA HDD, 2.5" SATA SSD, M.2 2280 NVMe
• M.2 PCIe Interface: PCIe 3.0 x2
• Maximum Drive Bays with Expansion Unit: 10
• Supports Hot Swappable Drives: Yes
• Expansion: 2x USB 3.2 Gen 2(10Gbps)
• Network: 2x 2.5 Gigabit Ethernet (2.5G/1G/100M)
• Multimedia Output: 1x HDMI 2.0b
• System Fan: 1x 70mm
• LCD Panel: Yes
• Power Supply Unit/Adapter: 65W x1
• Input Power Voltage: 100V to 240V AC
• Power Consumption: 21 W (Operation); 13.5 W (Disk Hibernation); 0.79 W (Sleep Mode)
• Noise Level: 17.7dB (HDD idle)
• Operation Temperature: 0°C~40°C (32°F~104°F)
• Storage Temperature: -20°C~70°C (-4°F~158°F)
• Humidity: 5% to 95% RH
• Dimensions (HxWxD): 163.5 (H) x 108 (W) x 230 (D) mm
• Weight: 2 kg
• Warranty: 3 Years Warranty

Asustor Lockerstor 10 AS6510T NAS

Asustor Lockerstor 10 AS6510T NAS Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Asustor
• Part No: AS6510T
• Model No: Asustor Lockerstor 10 AS6510T Network Attached Storage
• CPU Model: Intel ATOM C3538
• CPU Architecture: x64 64-bit
• CPU Frequency: Quad-Core 2.1GHz
• Memory: 8GB SO-DIMM DDR4
• Memory Module Pre-installed: 8GB(1x 8GB)
• Total Memory Slots: 2
• Memory Expandable up to: 64GB (2x 32GB) Support mixed capacity
• Flash Memory: 4GB eMMC
• Drive Bays: 10
• Compatible Drive Type: 3.5" SATA HDD, 2.5" SATA HDD, 2.5" SATA SSD, M.2 2280 NVMe, M.2 2280 SATA 3, M.2 2260 SATA 3, M.2 2242 SATA 3
• M.2 PCIe Interface: PCIe 3.0 x2
• Maximum Drive Bays with Expansion Unit: 18
• Supports Hot Swappable Drives: Yes
• Expansion: 2x USB 3.2 Gen 1
• Network: 2x 10 Gigabit Ethernet(10G/1G), 2x 2.5 Gigabit Ethernet (2.5G/1G/100M)
• Multimedia Output: N/A
• System Fan: 2x 120mm
• LCD Panel: Yes
• Power Supply Unit/Adapter: 250W x1
• Input Power Voltage: 100V to 240V AC
• Power Consumption: 76.8W (Operation); 41.1W (Disk Hibernation)
• Noise Level: 22dB(HDD idle)
• Operation Temperature: 0°C~40°C (32°F~104°F)
• Storage Temperature: -20°C~70°C (-4°F~158°F)
• Humidity: 5% to 95% RH
• Dimensions (HxWxD): 215.5(H) x 293(W) x 230(D) mm
• Weight: 6.4 kg
• Warranty: 3 Years Warranty

Asustor Lockerstor 8 AS6508T NAS Storage

Asustor Lockerstor 8 AS6508T NAS Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Asustor
• Part No: AS6508T
• Model No: Asustor Lockerstor 8 AS6508T Network Attached Storage
• CPU Model: Intel ATOM C3538
• CPU Architecture: x64 64-bit
• CPU Frequency: Quad-Core 2.1GHz
• Memory: 8GB SO-DIMM DDR4
• Memory Module Pre-installed: 8GB (1x 8GB)
• Total Memory Slots: 2
• Memory Expandable up to: 64GB (2x 32GB) Support mixed capacity
• Flash Memory: 4GB eMMC
• Drive Bays: 8
• Compatible Drive Type: 3.5" SATA HDD, 2.5" SATA HDD, 2.5" SATA SSD, M.2 2280 NVMe, M.2 2280 SATA 3, M.2 2260 SATA 3, M.2 2242 SATA 3
• M.2 PCIe Interface: PCIe 3.0 x2
• Maximum Drive Bays with Expansion Unit: 16
• Supports Hot Swappable Drives: Yes
• Expansion: 2x USB 3.2 Gen 1
• Network: 2x 10 Gigabit Ethernet(10G/1G), 2x 2.5 Gigabit Ethernet (2.5G/1G/100M)
• Multimedia Output: N/A
• System Fan: 2x 120mm
• LCD Panel: Yes
• Power Supply Unit/Adapter: 250W x1
• Input Power Voltage: 100V to 240V AC
• Power Consumption: 66.9W (Operation); 37.2W (Disk Hibernation)
• Noise Level: 22dB(HDD idle)
• Operation Temperature: 0°C~40°C (32°F~104°F)
• Storage Temperature: -20°C~70°C (-4°F~158°F)
• Humidity: 5% to 95% RH
• Dimensions (HxWxD): 215.5(H) x 293(W) x 230(D) mm
• Weight: 6.2 kg
• Warranty: 3 Years Warranty

Asustor AS5404T Network Attached Storage

Asustor AS5404T Network Attached Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Asustor
• Part No: AS5404T
• Model No: Asustor AS5404T Network Attached Storage
• CPU Model: Intel Celeron N5105
• CPU Architecture: x64 64-bit
• CPU Frequency: Quad-Core 2.0GHz (burst up 2.90 GHz)
• Memory: 4GB SO-DIMM DDR4
• Memory Module Pre-installed: 4GB(1x 4GB)
• Total Memory Slots: 2
• Memory Expandable up to: 16GB (2x 8GB) Support mixed capacity
• Flash Memory: 8GB eMMC
• Drive Bays: 4
• M.2 Drive Slots: 4
• Compatible Drive Type: 3.5" SATA HDD, 2.5" SATA HDD, 2.5" SATA SSD, M.2 2280 NVMe
• M.2 PCIe Interface: PCIe 3.0 x1
• Maximum Drive Bays with Expansion Unit: 16
• Supports Hot Swappable Drives: Yes
• Expansion: 3x USB 3.2 Gen 2(10Gbps)
• Network: 2x 2.5 Gigabit Ethernet(2.5G/1G/100M)
• Multimedia Output: 1x HDMI 2.0b
• System Fan: 1x 120mm
• Infrared Receiver: Yes
• Power Supply Unit/Adapter: 90W x1
• Input Power Voltage: 100V to 240V AC
• Power Consumption: 38.3W (Operation), 17.7W (Disk Hibernation), 0.81W (Sleep Mode)
• Noise Level: 19.7dB (HDD idle)
• Operation Temperature: 0°C~40°C (32°F~104°F)
• Storage Temperature: -20°C~70°C (-4°F~158°F)
• Humidity: 5% to 95% RH
• Dimensions (HxWxD): 170(H) x 174(W) x 230(D) mm
• Weight: 2.26 kg
• Warranty: 3 Years Warranty

Asustor AS5402T Gen2 Network Attached Storage

Asustor AS5402T Gen2 Network Attached Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Asustor
• Part No: AS5402T
• Model No: Asustor AS5402T Network Attached Storage
• CPU Model: Intel Celeron N5105
• CPU Architecture: x64 64-bit
• CPU Frequency: Quad-Core 2.0GHz (burst up 2.90 GHz)
• Memory: 4GB SO-DIMM DDR4
• Memory Module Pre-installed: 4GB(1x 4GB)
• Total Memory Slots: 2
• Memory Expandable up to: 16GB (2x 8GB) Support mixed capacity
• Flash Memory: 8GB eMMC
• Drive Bays: 2
• Compatible Drive Type: 3.5" SATA HDD, 2.5" SATA HDD, 2.5" SATA SSD, M.2 2280 NVMe
• M.2 PCIe Interface: PCIe 3.0 x1
• Maximum Drive Bays with Expansion Unit: 14
• Supports Hot Swappable Drives: Yes
• Expansion: 3x USB 3.2 Gen 2(10Gbps)
• Network: 2x 2.5 Gigabit Ethernet (2.5G/1G/100M)
• Multimedia Output: 1x HDMI 2.0b
• System Fan: 1x 70mm
• Infrared Receiver: Yes
• Power Supply Unit/Adapter: 65W x1
• Input Power Voltage: 100V to 240V AC
• Power Consumption: 22.9 W (Operation); 12.7 W (Disk Hibernation); 0.71 W (Sleep Mode)
• Noise Level: 18.6dB (HDD idle)
• Operation Temperature: 0°C~40°C (32°F~104°F)
• Storage Temperature: -20°C~70°C (-4°F~158°F)
• Humidity: 5% to 95% RH
• Dimensions (HxWxD): 170(H) x 114(W) x 230(D) mm
• Weight: 1.71 kg
• Warranty: 3 Years Warranty

Asustor AS5304T 4 Bay Network Attached Storage

Asustor AS5304T 4 Bay Network Attached Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Asustor
• Part No: AS5304T
• Model No: Asustor AS5304T Network Attached Storage
• CPU Model: Intel Celeron J4105
• CPU Architecture: x64 64-bit
• CPU Frequency: Quad-Core
• AES-NI hardware encryption engine integrated: Yes
• Memory: 4GB SO-DIMM DDR4
• Memory Module Pre-installed: 4GB (1x 4GB)
• Total Memory Slots: 2
• Memory Expandable up to: 8GB (2x 4GB) Support mixed capacity
• Flash Memory: 4GB eMMC
• Drive Bays: 4
• Compatible Drive Type: 3.5" SATA HDD, 2.5" SATA HDD, 2.5" SATA SSD
• Maximum Drive Bays with Expansion Unit: 16
• Supports Hot Swappable Drives: Yes
• Expansion: 3x USB 3.2 Gen 1
• Network: 2x 2.5 Gigabit Ethernet (2.5G/1G/100M)
• Multimedia Output: 1x HDMI 2.0a
• System Fan: 1x 120mm
• Infrared Receiver: Yes
• Power Supply Unit/Adapter: 90W x1
• Input Power Voltage: 100V to 240V AC
• Power Consumption: 27 W (Operation); 12.6 W (Disk Hibernation); 1.4 W (Sleep Mode)
• Noise Level: 19.7dB (HDD idle)
• Operation Temperature: 0°C~40°C (32°F~104°F)
• Storage Temperature: -20°C~70°C (-4°F~158°F)
• Humidity: 5% to 95% RH
• Dimensions (HxWxD): 170(H) x 174(W) x 230(D) mm
• Weight: 2.2 kg
• Warranty: 3 Years Warranty

Asustor AS5202T 2 Bay 8GB Ram NAS Storage

Asustor AS5202T 2 Bay 8GB Ram NAS Storage Price Chennai, Datasheet, Specification, Dealers, Storages Chennai

• Brand: Asustor
• Part No: AS5202T
• Model No: Asustor AS5202T 2 Bay NAS Storage
• CPU Model: Intel Celeron J4005
• CPU Architecture: x64 64-bit
• CPU Frequency: Dual-Core
• AES-NI hardware encryption engine integrated: Yes
• Memory: 2GB SO-DIMM DDR4
• Memory Module Pre-installed: 2GB (1x 2GB)
• Total Memory Slots: 2
• Memory Expandable up to: 8GB (2x 4GB) Support mixed capacity
• Flash Memory: 4GB eMMC
• Drive Bays: 2
• Compatible Drive Type: 3.5" SATA HDD, 2.5" SATA HDD, 2.5" SATA SSD
• Maximum Drive Bays with Expansion Unit: 14
• Supports Hot Swappable Drives: Yes
• Expansion: 3x USB 3.2 Gen 1
• Network: 2x 2.5 Gigabit Ethernet (2.5G/1G/100M)
• Multimedia Output: 1x HDMI 2.0a
• System Fan: 1x 70mm
• Infrared Receiver: Yes
• Power Supply Unit/Adapter: 65W x1
• Input Power Voltage: 100V to 240V AC
• Power Consumption: 17 W (Operation); 10.5 W (Disk Hibernation); 1.3 W (Sleep Mode)
• Noise Level: 18.6dB (HDD idle)
• Operation Temperature: 0°C~40°C (32°F~104°F)
• Storage Temperature: -20°C~70°C (-4°F~158°F)
• Humidity: 5% to 95% RH
• Dimensions (HxWxD): 170(H) x 114(W) x 230(D) mm
• Weight: 1.6 kg
• Warranty: 3 Years Warranty
