Latest Servers & Workstation

• Form Factor: 2U rack server
• Processors: Up to two (2) AMD EPYC™ 7002 Generation Processors, up to 64C, 225W
• Memory: 32x DDR4 memory slots; Maximum 4TB using 128GB RDIMMs; up to 1DPC at 3200MHz, 2DPC at 2933MHz
• Drive Bays: Up to 20x 3.5"or 40x 2.5" drives; Maximum of 32x NVMe drives with 1:1 connection
• Expansion Slots: Up to 8x PCIe 4.0 slots, 1x OCP 3.0 adapter slot
• GPU    Up to 8x single-width GPUs or 3x double-width GPUs*
• Network Interface: OCP 3.0 mezz adapter, PCIe adapters
• Power: Dual redundant PSUs (up to 1800W Platinum), 240V HVDC support
• Ports Front: 1x USB 3.0, 1x USB 2.0, 1x VGA (optional)
• Rear: 3x USB 3.1, 1x Serial port, 1x RJ-45 (management)
• Systems Management: Lenovo XClarity Controller
• OS Support    Microsoft Windows Server, SUSE Linux Enterprise Server, Red Hat Enterprise Linux, VMware ESXi*
• Limited Warranty: 1- and 3-year customer replaceable unit and onsite service, next business day 9x5, optional service upgrades

• Form Factor Full-width 2U enclosure
• Processors 2x second-generation Intel® Xeon® Scalable Processors (up to 205W) per node
• Memory Up to 1.5TB using 24x 64GB 2933MHz TruDDR4 3DS RDIMMs per node
• I/O Expansion Up to 3 PCIe adapters: 2x PCIe 3.0 x16 + 1x PCIe 3.0 x4 slots
• Acceleration Up to 4 double-wide, full-height, full-length GPUs (each PCIe 3.0 x16 slots), or up to 8 single-wide, fullheight, half-length GPUs (each PCIe 3.0 x8 slots)
• Management Network Interface 1x RJ-45 for dedicated 1GbE system management
• Internal Storage
• Up to 8x 2.5" hot-swap SSD or HDD SATA drives in rear bays
• Up to 2x non-hot-swap M.2 SSDs, 6Gbps SATA in internal bays
• RAID Support SW RAID standard; optional HBA or HW RAID with flash cache
• Power Management Rack-level power capping and management via Extreme Cloud Administration Toolkit (xCAT)
• Systems Management Remote management using Lenovo XClarity Controller; 1Gb dedicated management NIC
• OS Support Red Hat Enterprise Linux 7.5; Visit lenovopress.com/osig for more information.
• Limited Warranty 3-year customer replaceable unit and onsite limited warranty, next business day 9x5, service upgrades available

• Lenovo blade server
• Double-wide blade for Flex System Enterprise Chassis
• 2x or 4x Intel Xeon Platinum processors
• up to 165W
• Up to 4x PCIe x16 mezzanine adapters
• 4x 10GbE LOM with fabric connector
• Contained in the chassis
• 3-year customer replaceable unit and onsite service

• Form Factor: Standard width blade for Flex System Chassis
• Processor: Up to 2 second-generation Intel Xeon Processor Scalable family up to 165W
• Memory: Up to 3TB in 24x slots, using 128GB DIMMs; 2666MHz / 2933MHz TruDDR4; supports Intel Optane DC Persistent Memory
• Expansion Slots: Up to 2x PCIe x16 mezzanine adapters
• Internal Storage: Up to 2x 2.5 bays supporting SAS/SATA HDDs/SSDs, or NVMe/U.2 SSDs; plus 1x or 2x (mirrored) M.2 (SATA) fixed boot drives (optional RAID 1)
• Network Interface: 4x 10GbE LOM with fabric connector; or 2x 10GbE, 4x 10GbE, converged network mezzanine adapters, or 4x 25GbE or 2x 50GbE network mezzanine adapters
• Power Supply: Contained in the chassis
• Security and Availability Features: Lenovo ThinkShield, hot-swap 2.5" SAS/SATA/U.2 drives; operating temperature up to 40°C (with limitations)
• RAID Support: SW RAID standard. (6Gbps SATA); optional HW basic RAID (12Gbps SAS/SATA); optional HW advanced RAID (12Gbps SAS/SATA 2GB flash-backed cache)
• Systems Management: XClarity Controller, XClarity Administrator, XClarity Integrator plugins, and XClarity Energy Manager
• OSes Supported: Microsoft Windows Server, Red Hat, SUSE, VMware vSphere. Visit lenovopress.com/osig for details.
• Limited Warranty: 3-year customer replaceable unit and onsite service, next business day 9x5; optional service upgrades

Allows you to do more now in the data centre you own through outstanding performance, flexible networking and simple management Integrated tools such as IBM Systems Director Active Energy Managerâ„¢ and Blue Path Cooling blade design deliver outstanding power management Optional embedded hypervisor enables instant virtualisation IBM Integrated Management Module provides around-the-clock remote management capabilities Unified Extensible Firmware Interface delivers improved interface for more efficient boot of operating systems Predictive Failure Analysis and light path diagnostics help maximise availability by detecting component failure before the failure occurs

Innovative design with flexibility, performance and outstanding uptime Optimised for cost and performance, supports business-critical applications and cloud deployments Excellent RAS and outstanding uptime for an improved business environment Easy to deploy, integrate, service and manage Comprehensive systems management tools help increase uptime, reduce costs and improve productivity with advanced server management capabilities Support for GPUs, high-IOPS SSDs and 10 GbE for different types of workloads

• Single, integrated storage solution
• Built to leverage a strong IBM Spectrum Scale software market
• High-capacity, scalable building-block approach—performance and capacity increase as you add multiple building blocks
• Unique, innovative Spectrum Scale RAID capability providing extreme data integrity and reduced latency with faster rebuild times and enhanced data protection
• Cost competitive

• Operating Systems: Red Hat Enterprise Linux, SUSE Linux Enterprise Server, CentOS
• Lenovo Software: Lenovo intelligent Computing Orchestration (LiCO)
• OEM Software: IBM® Spectrum Scale, Excelero
• Open Source Software: xCat/Confluent, Antilles
• Scalability    Individual configuration based on the components above scaling from single to 10,000s of systems
• Warranty: 3-year parts, customer replaceable unit (CRU) or on-site labor, limited warranty, with individual nodes retaining the warranty and service upgrade offerings for that machine type; optional warranty service upgrades. Support is 9x5, next business day

• Form Factor/Height: 2U rack enclosure; 4 independent compute nodes
• Processor (max)/Cache (max): Up to 2x Intel® Xeon® Platinum processors, up to 165W
• Memory: Up to 1TB in 16x slots, using 64GB DIMMs; 2666MHz TruDDR4
• Expansion Slots: 1x shuttle per D2 enclosure: either x8 PCIe Shuttle with 8x PCIe 3.0 x8 slots (2 per node); or x16 PCIe Shuttle with 4x PCIe 3.0 x16 slots (1 per node). Up to 2x external 1U trays (with up to 2 GPUs per node each)
• Drive Bays (Total/Hot Swap)
• Up to 24x (6x per node) HS SFF SAS/SATA HDDs/SSDs; up to 8x (2x per node) HS SFF NVMe SSDs
• RAID Support: SW RAID supports JBOD; Entry RAID; opt. HW RAID 12Gb supports JBOD; plus M.2 boot support with optional RAID
• Security and Availability Features    TPM 1.2/2.0; PFA; HS/redundant drives, fans, and PSUs; 45°C continuous operation; light path diagnostic LEDs; front-access diagnostics via dedicated USB port
• Network Interface: Opt. 8-port EIOM 10Gb SFP+ (two ports per node); Opt. 8-port EIOM 10GbaseT RJ45 (two ports per node)
• Power Supply: 2x hot-swap/redundant 1+1 1600W/2000W; or 2x non-redundant 1100W
• Hot-Swap Components    Power supplies, fans, SAS/SATA/NVMe storage devices; compute nodes are warm-swap
• Systems Management: XClarity Controller embedded management, XClarity Administrator centralized infrastructure delivery, XClarity Integrator plugins, and XClarity Energy Manager centralized server power management
• Operating Systems Supported
• Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware vSphere. Visit lenovopress.com/osig for details.
• Limited Warranty: 1- and 3-year customer replaceable unit and onsite service, next business day 9x5, opt. service upgrades

• Form Factor: Full-wide 1U tray (six per n1200 Enclosure)
• Chassis    : NeXtScale n1200 Enclosure (6U)
• Processors: 2 second-generation Intel Xeon Scalable Processor Scalable family CPUs per node; 2x nodes per 1U tray
• Memory    Up to 1.5TB using 12x 2933MHz TruDDR4 DIMMs per node or up to 2TB (512GB x4) using Intel Optane DC Persistent Memory
• I/O Expansion: 1x 50mm width ML2 slot and 1x PCIe x16 slot for EDR InfiniBand or Intel Omni Path, per server node
• Internal Storage: Up to 2x 2.5” SATA SSDs (7mm height) or 1x 2.5” NVMe SSDs (15mm height) per node; up to 2x M.2 SATA SSDs
• RAID Support: Onboard SATA controller with SW RAID; optional Dual M.2 SSD adapter with HW RAID 1
• Network Interface: 2x 1GbE BaseT NIC per node; additional high-speed network adapters (InfiniBand or Omni Path) can be installed in available front-accessible PCIe x16 adapter slot
• Power Management: Rack-level power capping and management via Extreme Cloud Administration Toolkit (xCAT)
• Systems Management: Supported by LICO and XCC
• Limited Warranty: 3-year customer replaceable unit and onsite limited warranty, next business day 9x5, service upgrades available

• Form Factor/Height: 2U rack server
• Processor (max): 2 or 4 second-generation Intel® Xeon® Processor Scalable family CPUs, up to 165W
• Memory (max): Up to 6TB in 48x slots using 128GB DIMMs; 2666MHz / 2933MHz TruDDR4
• Expansion Slots: Up to 9x PCIe plus 1x LOM; optional 1x ML2 slot
• Internal Storage: Up to 16x 2.5" storage bays supporting SAS/SATA HDD and SSDs or up to 8x 2.5" NVMe SSD; plus up to 2x mirrored M.2 boot
• Network Interface: Multiple options with 1GbE, 10GbE, 25GbE, 32GbE, 40GbE or InfiniBand PCIe adapters; one (2-/4-port) 1GbE or 10GbE LOM card
• Power Supply (std/max): 2x hot-swap/redundant: 750W/1100W/1600W AC 80 PLUS Platinum
• Security and Availability Features: Lenovo ThinkShield, TPM 1.2/2.0; PFA; hot-swap/redundant drives, fans, and PSUs; internal light path diagnostic LEDs; front-access diagnostics via dedicated USB port; diagnostic LCD panel
• RAID Support: HW RAID (up to 16 ports) with flash cache; up to 16-port HBAs
• Limited Warranty: 1-year and 3-year customer replaceable unit and onsite service, next business day 9x5; optional service upgrades

• Form Factor: 2U
• Processors: Two or four 3rd-generation Intel Xeon Processor Scalable family CPUs, up to 250W; Mesh topology with 6x UPI links
• Memory: Up to 12TB of TruDDR4 memory in 48x slots; Memory speeds up to 3200MHz at 2 DIMMs per channel; Supports Intel Optane Persistent Memory 200 Series
• Expansion: Up to 7x PCIe 3.0 expansion slots
• Front: VGA, 1x USB 3.1, 1x USB 2.0
• Rear: 2x USB 3.1, Serial port, VGA port, 1GbE dedicated management port
• Internal Storage Up to 24x 2.5-inch drives; Supports up to 24x NVMe drives (16x with 1:1 connection); 2x 7mm drives for boot
• Network Interface Dedicated OCP 3.0 slot supporting 1GbE, 10GbE or 25GbE
• Power 2x Platinum or Titanium hot-swap power supplies; N+N redundancy supported
• High Availability TPM 2.0; PFA; hot-swap/redundant drives and power supplies; redundant fans; internal light path diagnostic LEDs; front-access diagnostics via dedicated USB port; optional diagnostic LCD panel
• RAID Support: Onboard SATA with SW RAID; Support for ThinkSystem PCIe RAID/HBA cards
• Management    Lenovo XClarity Controller; Redfish support
• OS Support    Microsoft, Red Hat, SUSE, VMware. Visit lenovopress.com/osig for more information.
• Limited Warranty: 1-year and 3-year customer replaceable unit and onsite service, next business day 9x5; optional service upgrades

• Form Factor: 2U
• Processors: Two or four 3rd-generation Intel® Xeon® Processor Scalable family CPUs, up to 250W; Mesh topology with 6x UPI links
• Memory: Up to 12TB of TruDDR4 memory in 48x slots; Memory speeds up to 3200MHz at 2 DIMMs per channel; Supports Intel Optane Persistent Memory 200 Series
• Expansion: Up to 7x PCIe 3.0 expansion slots
• Front: VGA, 1x USB 3.1, 1x USB 2.0
• Rear: 2x USB 3.1, Serial port, VGA port, 1GbE dedicated management port
• Internal Storage Up to 24x 2.5-inch drives; Supports up to 24x NVMe drives (16x with 1:1 connection); 2x 7mm drives for boot
• Network Interface Dedicated OCP 3.0 slot supporting 1GbE, 10GbE or 25GbE
• Power 2x Platinum or Titanium hot-swap power supplies; N+N redundancy supported
• High Availability TPM 2.0; PFA; hot-swap/redundant drives and power supplies; redundant fans; internal light path diagnostic LEDs; front-access diagnostics via dedicated USB port; optional diagnostic LCD panel
• RAID Support: Onboard SATA with SW RAID; Support for ThinkSystem PCIe RAID/HBA cards
• Management    Lenovo XClarity Controller; Redfish support
• OS Support    Microsoft, Red Hat, SUSE, VMware. Visit lenovopress.com/osig for more information.
• Limited Warranty: 1-year and 3-year customer replaceable unit and onsite service, next business day 9x5; optional service upgrades

• Form Factor: 4U
• Processors: Two or four 3rd-generation Intel® Xeon® Processor Scalable family CPUs, up to 250W; Mesh topology with 6x UPI links
• Memory: Up to 12TB of TruDDR4 memory in 48x slots; Memory speeds up to 3200MHz at 2 DIMMs per channel; Supports Intel Optane Persistent Memory 200 Series
• enternal Storage: Up to 48x 2.5-inch drives; Supports up to 24x NVMe drives (16x with 1:1 connection); 2x 7mm or 2x
• GPU Support    Up to 4x double-wide 300W GPUs (NVIDIA V100S) or 8x single-wide 70W GPUs (NVIDIA T4)
• Network Interface: Dedicated OCP 3.0 slot supporting 1GbE, 10GbE or 25GbE
• Power Up to 4x Platinum or Titanium hot-swap power supplies; N+N and N+1 redundancy supported
• High Availability: TPM 2.0; PFA; hot-swap/redundant drives and power supplies; redundant fans; internal light path diagnostic LEDs; front-access diagnostics via dedicated USB port; optional integrated diagnostic LCD panel
• RAID Support: Onboard SATA with SW RAID, Support for ThinkSystem PCIe RAID/HBA cards
• Management: Lenovo XClarity Controller; Redfish support
• OS Support Microsoft, Red Hat, SUSE, VMware. Visit lenovopress.com/osig for more information.
• Limited Warranty: 1-year and 3-year customer replaceable unit and onsite service, next business day 9x5; optional service upgrades

• Form Factor/Height: Rack/4U
• Processor (max): Up to 8 second-generation Intel® Xeon® Platinum processors, up to 28x cores per processor, up to 205W
• Memory (max): Up to 24TB in 96 slots, using 256GB DIMMs; 2666MHz / 2933MHz TruDDR4, supports Intel® Optane™ DC
• Expansion Slots: Up to 14x rear PCIe, (11x x16 +, 3x x8), 2x shared ML2 and PCIe x16) and 1x LOM; plus 2x front
• Internal Storage (Total/Hot-swap) Up to 24x 2.5" bays supporting SAS/SATA HDDs/SSDs, including 12x 2.5" NVMe SSDs
• Network Interface : Up to 2x (1/2/4-port) 1GbE, 10GbE, 25GbE, or InfiniBand ML2 adapters; plus 1x (2/4-port) 1GbE or 10GbE LOM card
• Power (std/max): Up to 4x shared 1100W, 1600W or 2000W AC 80 PLUS Platinum
• Security and Availability Features    Lenovo ThinkShield, TPM 1.2/2.0; PFA; Hot-swap/redundant drives, fans, and PSUs; internal light path diagnostic LEDs; front-access diagnostics via dedicated USB port
• Hot-Swap/Redundant Components    Power supplies, fans, SAS/SATA/NVMe storage
• RAID Support: Optional HW RAID; M.2 boot support with optional RAID
• Systems Management    XClarity Controller embedded management, XClarity Administrator centralized infrastructure delivery, XClarity Integrator plugins, and XClarity Energy Manager centralized server power management
• OSes Supported
• Limited Warranty: 1- and 3-year customer replaceable unit and onsite service, next business day 9x5; optional service upgrades

• Model Number: D7S27AAE
• Standard Features
• Up to 32 SSD Cache volumes
• Up to 64 total number of HDD volumes and cache volumes
• Maximum logical drive size is 281 TB
• 1 TB maximum SSD SmartCache capacity per controller
• Supported with all ProLiant Gen8, Gen9, and Gen10 supported SSDs
• Warranty: 1 year Warranty


• Model Number: D7S27A
• Standard Features
• Up to 32 SSD Cache volumes
• Up to 64 total number of HDD volumes and cache volumes
• Maximum logical drive size is 281 TB
• 1 TB maximum SSD SmartCache capacity per controller
• Supported with all ProLiant Gen8, Gen9, and Gen10 supported SSDs
• Warranty: 1 year Warranty

• Model Number: D7S26A
• Standard Features
• Up to 32 SSD Cache volumes
• Up to 64 total number of HDD volumes and cache volumes
• Maximum logical drive size is 281 TB
• 1 TB maximum SSD SmartCache capacity per controller
• Supported with all ProLiant Gen8, Gen9, and Gen10 supported SSDs
• Warranty: 1 year Warranty


• Model Number: Q2F26AAE
• Encryption supported on logical volumes only
• Automatic key management
• Broad encryption coverage
• Encrypts SAS/SATA drive and controller cache memory
• Compliance with regulations such as HIPAA and Sarbanes-Oxley
• FIPS 140-2 Level 1validated (see list of validated controllers below)
• High Availability and Scalability:
• Local Key Management Mode
• Remote Key Management Mode
• Instant volume erase
• Security reset function
• Simplified Deployment and Management
• Warranty: 1 year Warranty

• Model Number: 804331 B21
• Standard Features
• Storage interface (SAS/SATA)
• 8 SAS lanes across 2 x4 internal Mini SAS ports
• 12Gb/s SAS, 6Gb/s SATA technology
• Mix-and-match SAS and SATA drives to the same controller
• Support for SAS tape drives
• 2 GB Flash-Backed Write Cache (FBWC)
• PCI Express 3.0 x8 link
• RAID 0, 1, 5, 6, 10, 50, 60, 1 ADM, 10 ADM (Advanced Data Mirroring)
• Mixed Mode (RAID logic drives and HBA physical drives simultaneously)
• Windows Storage Spaces Direct validated
• VMware Virtual SAN certified
• Legacy and UEFI boot operation
• UEFI System Utilities (storage configuration)
• Up to 238 physical drives
• Up to 64 logical drives
• HPE Smart Array SR SmartCache (optional license)
• HPE Smart Array SR Secure Encryption (optional license)
• HPE SSD Smart Path
• Rapid Parity Initialization (RPI)
• Rapid rebuild
• Drive Sanitize
• Performance Optimization Degraded Reads and Read Coalescing
• Power efficiency
• Seamless upgrades from HPE Smart Array S-class and E-class controllers
• FIPS 140 2 Level 1 Implementation Under Test (expected validation complete in 2018)
• Ports
• Internal: 8 SAS/SATA lanes across 2 x4 Mini SAS ports
• Form Factor: Type a Flexible/Modular Controller (does not occupy a PCIe Expansion Slot)
• Performance
• 12Gb/s SAS (1200 MB/s theoretical bandwidth per SAS lane)
• 6Gb/s SATA (600 MB/s theoretical bandwidth per SAS lane)
• PCI Express 3.0 x8 link width
• 2 GB 72 bit wide DDR4-2100 Flash-Backed Write Cache provides up to 16.8 GB/s maximum cache bandwidth
• Read ahead caching
• Write back caching
• Warranty: The warranty for this device is 3 years parts only

• Model Number: 870658 B21
• Form factor: PCIe Plug in Controller
• Ports: Internal: 24 SAS lanes across six x4 mini-SAS HD ports
• Cache: 4 GB Flash Backed Write Cache
• RAID levels; 0, 1, 5, 6, 10, 50, 60
• Minimum dimensions ( H x W x D): 19.05 x 24.13 x 5.71 cm
• Weight: 0.34 kg
• Warranty: The warranty for this device is 3 years parts only


• Model Number: 869081 B21
• Form factor: Type a modular controller
• Ports: Internal: 8 SAS lanes across 2 x4 Mini SAS ports
• Cache: 2 GB Flash Backed Write Cache
• Transfer rate:
• 12Gb/s SAS per lane
• 6Gb/s SATA per lane
• PCI Express 3.0 x8 lane width
• SATA speed: 0, 1, 5, 6, 10, 50, 60, 1 ADM, 10 ADM
• Warranty: The warranty for this device is 3 years parts only

• Model Number: 869083 B21
• Storage interface (SAS/SATA)
• 16 SAS lanes across 4 x4 internal mini-SAS ports
• 12 Gb/s SAS, 6 Gb/s SATA technology
• Mix and match SAS and SATA drives to the same controller
• Support for SAS tape drives
• 4GB FBWC
• PCI express 3.0 x8 link
• RAID 0, 1, 5, 6, 10, 50, 60, 1 ADM, 10 Advanced Data Mirroring (ADM)
• Mixed mode (RAID logic drives and HBA physical drives simultaneously)
• Legacy and UEFI boot operation
• UEFI system utilities (Storage configuration)
• Up to 238 physical drives
• Up to 64 logical drives
• HPE Smart Array SR SmartCache (License included)
• HPE Smart Array SR secure encryption (Optional license)
• HPE SSD smart path
• HPE SSD smart path
• Rapid rebuild
• Drive sanitize
• Performance optimization - Degraded reads and read coalescing
• Power efficiency
• Seamless upgrades from HPE Smart Array S-class and E-class controllers
• FIPS 140-2 Level 1 implementation under test (Expected validation complete in 2018)
• Ports
• Internal: 16 SAS/SATA lanes across 4 x4 mini-SAS ports
• Form factor: Type a Flexible/Modular controller (Does not occupy a PCIe expansion slot)
• Performance
• 12 Gb/s SAS (1200 Mb/s theoretical bandwidth per SAS lane)
• 6 Gb/s SATA (600 MB/s theoretical bandwidth per SAS lane)
• PCI express 3.0 x8 link width
• 4GB 72 bit wide DDR4-2100 flash-backed write cache provides up to 16.8 Gb/s maximum cache bandwidth
• Read ahead caching
• Write back caching
• Warranty: 1 year Warranty

• Model Number: 804326 B21
• Standard Features
• Storage interface (SAS/SATA)
• 8 SAS lanes across 2 x4 internal Mini SAS ports
• 12Gb/s SAS, 6Gb/s SATA technology
• Mix and match SAS and SATA drives to the same controller
• Support for SAS tape drives
• PCI Express 3.0 x8 link
• RAID 0, 1, 5, 10
• Mixed Mode (RAID logic drives and HBA physical drives simultaneously)
• Windows Storage Spaces Direct validated
• VMware Virtual SAN certified
• Legacy and UEFI boot operation
• UEFI System Utilities (storage configuration)
• Up to 238 physical drives
• Up to 64 logical drives
• HPE Smart Array SR Secure Encryption (optional license)
• HPE SSD Smart Path
• Rapid Parity Initialization (RPI)
• Rapid rebuild
• Drive Sanitize
• Performance Optimization-Degraded Reads and Read Coalescing
• Power efficiency
• Seamless upgrades from HPE Smart Array Software RAID
• Seamless upgrades to HPE Smart Array P-class Controllers
• Ports
• Internal: 8 SAS/SATA lanes across 2 x4 internal Mini SAS ports
• Form Factor
• Type a Flexible/Modular Controller (does not occupy a PCIe Expansion Slot)
• Performance 12Gb/s SAS (1200 MB/s theoretical bandwidth per physical lane)
• 6Gb/s SATA (600 MB/s theoretical bandwidth per physical lane)
• PCI Express 3.0 x8 link width
• Warranty: The warranty for this device is 3 years parts only

• Model Number: 804394 B21
• Features:
• Storage interface (SAS/SATA)
• 8 SAS lanes across 2 x4 internal mini SAS ports
• 12 Gb/s SAS, 6 Gb/s SATA technology
• Mix and match SAS and SATA drives to the same controller
• Support for SAS tape drives
• PCI express 3.0 x8 link
• RAID 0, 1, 5, 10
• Mixed mode (RAID logic drives and HBA physical drives simultaneously)
• Legacy and UEFI boot operation
• UEFI system utilities (Storage configuration)
• Up to 238 physical drives
• Up to 64 logical drives
• HPE Smart Array SR secure encryption (Optional license)
• HPE Solid State Disk (SSD) smart path
• Rapid Parity Initialization (RPI)
• Rapid rebuild
• Drive sanitize
• Performance optimization-degraded reads and read coalescing
• Power efficiency
• Seamless upgrades from HPE Smart Array software RAID
• Seamless upgrades to HPE Smart Array P-class controllers
• Ports
• Internal: 8 SAS/SATA lanes across 2 x4 internal mini SAS ports
• Performance
• 12 Gb/s SAS (1200 MB/s theoretical bandwidth per physical lane)
• 6 Gb/s SATA (600 MB/s theoretical bandwidth per physical lane)
• PCI express 3.0 x8 link width
• Warranty: 1 year Warranty

• Model Number: 804338 B21
• Features:
• Storage interface (SAS/SATA)
• 16 SAS lanes across 4 x4 internal mini SAS ports
• 12 Gb/s SAS, 6 Gb/s SATA technology
• Mix and match SAS and SATA drives to the same controller
• Support for SAS tape drives
• 4GB FBWC
• PCI express 3.0 x8 link
• RAID 0, 1, 5, 6, 10, 50, 60, 1 ADM, 10 Advanced Data Mirroring (ADM)
• Mixed mode (RAID logic drives and HBA physical drives simultaneously)
• Legacy and UEFI boot operation
• UEFI system utilities (Storage configuration)
• Up to 238 physical drives
• Up to 64 logical drives
• HPE Smart Array SR SmartCache (License included)
• HPE Smart Array SR secure encryption (Optional license)
• HPE SSD smart path
• HPE SSD smart path
• Rapid rebuild
• Drive sanitize
• Performance optimization - Degraded reads and read coalescing
• Power efficiency
• Seamless upgrades from HPE Smart Array S-class and E-class controllers
• FIPS 140-2 Level 1 implementation under test (Expected validation complete in 2018)
• Ports
• Internal: 16 SAS/SATA lanes across 4 x4 mini SAS ports
• Form factor: Type a Flexible/Modular controller (Does not occupy a PCIe expansion slot)
• Performance
• 12 Gb/s SAS (1200 Mb/s theoretical bandwidth per SAS lane)
• 6 Gb/s SATA (600 MB/s theoretical bandwidth per SAS lane)
• PCI express 3.0 x8 link width
• 4GB 72-bit wide DDR4-2100 flash-backed write cache provides up to 16.8 Gb/s maximum cache bandwidth
• Read ahead caching
• Write back caching
• Warranty: 1 year Warranty

• Model Number: 726907 B21
• Performance:
• 12 Gb/s SAS (bandwidth per physical link)
• 96 Gb/s total available bandwidth (8 physical links x 12 Gb/s)
• Features:
• SAS technology delivers high performance and data bandwidth up to 12 Gb/s per physical link
• Mix and match SAS and SATA hard drives; deploy drive technology as needed
• PCIe 3.0 x8 ( 8GB/s bandwidth)
• RAID 0, 1, 5, 10 or HBA mode
• Ports: Eight (8) SAS physical links distributed across 2 x4 internal Mini-SAS connectors
• Capacity
• Eight 12 Gb/s SAS physical links supporting up to 2 simultaneous x4 SAS Ports
• Capacity up to 144TB of SAS or 144TB SATA
• Form factor: Either high profile or low-profile PCIe 3.0 slots (parts included with option)
• Warranty: 1 year Warranty

• Model Number: 869079 B21
• Storage interface (SAS/SATA)
• 8 SAS lanes across 2 x 4 internal mini SAS ports
• 12 Gb/s SAS, 6 Gb/s SATA technology
• Mix and match SAS and SATA drives to the same controller
• Support for SAS tape drives
• PCI Express 3.0 x 8 link
• RAID 0, 1, 5, 10
• Mixed mode (RAID logic drives and HBA physical drives simultaneously)
• Legacy and UEFI boot operation
• UEFI System utilities (Storage configuration)
• Up to 238 physical drives
• Up to 64 logical drives
• HPE Smart Array SR secure encryption (Optional license)
• HPE Solid State Disk (SSD) smart path
• Rapid Parity Initialization (RPI)
• Rapid rebuild
• Drive sanitize
• Performance optimization Degraded reads and read coalescing
• Power efficiency
• Seamless upgrades from HPE Smart Array Software RAID
• Seamless upgrades to HPE Smart Array P class controllers
• Ports (Internal): 8 SAS/SATA lanes across 2 x 4 internal mini SAS ports
• Form factor: Type a Flexible/Modular controller (Does not occupy a PCIe Expansion slot)
• Performance
• 12 Gb/s SAS (1200 Mb/s Theoretical bandwidth per physical lane)
• 6 Gb/s SATA (600 Mb/s Theoretical bandwidth per physical lane)
• PCI Express 3.0 x 8 link width
• Warranty: 1 year Warranty

• Model Number: 804398 B21
• Standard Features :
• Storage interface (SAS/SATA):
• 8 SAS lanes across 2 x4 external MiniSAS HD ports
• 12Gb/s SAS, 6Gb/s SATA technology
• Mix and match SAS and SATA drives to the same controller
• Support for SAS tape drives
• PCI Express 3.0 x8 link
• RAID 0, 1, 5, 10
• Mixed Mode (RAID logic drives and HBA physical drives simultaneously)
• Legacy and UEFI boot operation
• UEFI System Utilities (storage configuration)
• Up to 238 physical drives
• Up to 64 logical drives
• Supports up to 8 daisy chained HPE D3610 Disk Enclosure and HPE D3710 Disk Enclosure in dual
• domain configuration
• HPE Smart Array SR Secure Encryption (optional license)
• HPE SSD Smart Path
• Rapid Parity Initialization (RPI)
• Rapid rebuild
• Drive Sanitize
• Performance Optimization-Degraded Reads and Read Coalescing
• Power efficiency
• Seamless upgrades from HPE Smart Array Software RAID
• Seamless upgrades to HPE Smart Array P-class Controllers
• Ports
• External: 8 SAS/SATA lanes across 2 x4 external Mini SAS HD ports
• Form Factor: PCIe Plug in Controller (occupies a PCIe expansion slot)
• Performance:
• 12Gb/s SAS (1200 MB/s theoretical bandwidth per physical lane)
• 6Gb/s SATA (600 MB/s theoretical bandwidth per physical lane)
• PCI Express 3.0 x8 link width
• Warranty: The warranty for this device is 3 years parts only

• Model Number: 830824 B21
• Features:
• Storage interface (SAS/SATA)
• 8 SAS lanes across 2 x 4 internal Mini SAS ports
• 12 Gb/s SAS, 6 Gb/s SATA technology
• Mix-and-Match SAS and SATA drives to the same controller
• Support for SAS tape drives
• 2GB FBWC
• PCI express 3.0 x 8 link
• RAID 0, 1, 5, 6, 10, 50, 60, 1 Advanced Data Mirroring (ADM), 10 ADM
• Mixed mode (RAID logic drives and HBA physical drives simultaneously)
• Legacy and UEFI boot operation
• UEFI system utilities (Storage configuration)
• Up to 238 physical drives
• Up to 64 logical drives
• HPE Smart Array SR SmartCache (Optional license)
• HPE Smart Array SR secure encryption (Optional license)
• HPE Solid State Disk (SSD) smart path
• Rapid Parity Initialization (RPI)
• Rapid rebuild
• Drive sanitize
• Performance Optimization Degraded reads and read coalescing
• Power efficiency
• Seamless upgrades from HPE Smart Array S class and E class controllers
• FIPS 140 2 level 1 implementation under test (Expected validation complete in 2018)
• Ports
• Internal: 8 SAS/SATA lanes across 2 x 4 Mini-SAS ports
• Form factor
• PCIe Plug In controller (Occupies a PCIe expansion slot)
• Performance
• 12 Gb/s SAS (1200 MB/s theoretical bandwidth per SAS lane)
• 6 Gb/s SATA (600 MB/s theoretical bandwidth per SAS lane)
• PCI express 3.0 x 8 link width
• 2GB 72 bit wide DDR4 2100 FBWC provides up to 16.8 GB/s maximum cache bandwidth
• Read ahead caching
• Write Back caching
• Warranty: 1 year Warranty
