Processor

1x Intel® Xeon® E-2200 processor, up to 6 cores at 95W

Form Factor/Height

Tower; Optional 4U rack-mount kit; Height: 375mm (16.9 inches), Width: 175mm (6.9 inches), Depth 431mm (17 inches)

Expansion Slots

Up to 6x PCIe 3.0 (with 2x processors)

memory

Up to 64GB in 4x UDIMM slots using 16GB DIMMs; 2666MHz TruDDR4

Drive Bays

4x; either 3x 3.5-inch + 1x 5.25-inch fixed, or 4x 3.5-inch fixed (the 4th requires the 5.25-inch to 3.5-inch optical drive conversion kit); support a mixed configuration with HDDs and SSDs; 5.25-inch bay supports optical or tape dirve (unless converted to 3.5-inch); single SD card (32GB) or dual-redundant SD cards (32GB / 64GB)

HBA/RAID Support

Intel VROC software RAID support; multiple hardware RAID configurations supported

Security/Availability

Lenovo ThinkShield, lockable security bezel, Kensington lock slot, chassis intrusion switch, TPM 1.2/2.0, Predict Failure Analysis, hot-swap/redundant drives, redundant PSUs

Network Interface

2x 1GbE ports standard; See ST550 product guide for more options

Power

1x fixed 80 PLUS power supply up to Platinum efficiency; 250W or 400W

Systems Management

XClarity Controller embedded management, XClarity Administrator centralized infrastructure delivery, XClarity Integrator plugins, and XClarity Energy Manager centralized server power management

Operating Systems Supported

Microsoft Windows Server, SUSE, Red Hat, VMware vSphere

warranty

1-year and 3-year customer replaceable unit and onsite service, next business day 9x5
