Lenovo ThinkSystem SR950 Mission Critical Servers
- Form Factor/Height: Rack/4U
- Processor (max): Up to 8 second-generation Intel® Xeon® Platinum processors, up to 28x cores per processor, up to 205W
- Memory (max): Up to 24TB in 96 slots, using 256GB DIMMs; 2666MHz / 2933MHz TruDDR4, supports Intel® Optane™ DC
- Expansion Slots: Up to 14x rear PCIe, (11x x16 +, 3x x8), 2x shared ML2 and PCIe x16) and 1x LOM; plus 2x front
- Internal Storage (Total/Hot-swap) Up to 24x 2.5" bays supporting SAS/SATA HDDs/SSDs, including 12x 2.5" NVMe SSDs
- Network Interface : Up to 2x (1/2/4-port) 1GbE, 10GbE, 25GbE, or InfiniBand ML2 adapters; plus 1x (2/4-port) 1GbE or 10GbE LOM card
- Power (std/max): Up to 4x shared 1100W, 1600W or 2000W AC 80 PLUS Platinum
- Security and Availability Features Lenovo ThinkShield, TPM 1.2/2.0; PFA; Hot-swap/redundant drives, fans, and PSUs; internal light path diagnostic LEDs; front-access diagnostics via dedicated USB port
- Hot-Swap/Redundant Components Power supplies, fans, SAS/SATA/NVMe storage
- RAID Support: Optional HW RAID; M.2 boot support with optional RAID
- Systems Management XClarity Controller embedded management, XClarity Administrator centralized infrastructure delivery, XClarity Integrator plugins, and XClarity Energy Manager centralized server power management
- OSes Supported
- Limited Warranty: 1- and 3-year customer replaceable unit and onsite service, next business day 9x5; optional service upgrades
