Brand: Ubiquiti
Product: UniFi Usw Pro 24 Network Switch
Enclosure material: SGCC steel
Ethernet: PoE Speed/link/activity
Management interface: Ethernet In-Band
Networking interface: (24) GbE RJ45 ports; (2) 1/10G SFP+ ports
PoE interface: (16) PoE/PoE+ (Pins 1, 2+; 3, 6-); (8) 60W PoE++; PoE/PoE+ (Pins 1, 2+; 3, 6-) / PoE++ (Pair A 1, 2+; 3, 6-) (Pair B 4, 5+; 7, 8-)
Total non-blocking throughput: 44 Gbps
Switching capacity: 88 Gbps
Forwarding rate: 65.472 Mpps
Power method: (1) Universal input, 100—240V AC, 50/60 Hz; (1) USP-RPS DC input, 52V DC, 7.69A; 11.5V DC, 2.61A
Power supply: AC/DC, internal, 450W
Supported voltage range: 100—240V AC
Max. power consumption: 50W (Excluding PoE output)
Total available PoE: 400W
Max. PoE wattage per port by PSE: PoE+: 32W; PoE++: 64W
Voltage range PoE mode PoE: 44—57V; PoE+: 50—57V
ESD/EMP protection Air: ± 16kV, contact: ± 12kV
LCM display: (1) 1.3" touchscreen
Button: Factory reset
Shock and vibration: ETSI300-019-1.4 Standard
Ambient operating temperature: -5 to 40° C (23 to 104° F)
Ambient operating humidity: 10 to 90% noncondensing
Product Dimensions: 442 x 285 x 44 mm
Certifications: CE, FCC, IC
UniFi Network: Version 5.10.5 and later
