NVIDIA Spectrum SN2201 Ethernet Switch Specification and Datasheet
Form Factors: 48xRJ45 + 4x QSFP28
Max 100GbE ports: 4
Max 50GbE ports: 8
Max 40GbE ports: 4
Max 25GbE ports: 16
Max 10GbE ports: 16
Max 1GbE ports: 16
Max 1Gbase-T ports: 48
Max 100Mbase-T ports: 48
Max 10Mbase-T ports: 48
Throughput: 448Gb/s
Packet Rate: 667Mpps
Packet Buffer: 16 MB
CPU: Dual-core x86
System Memory: 8 GB
SSD Memory: 20 GB
10/100/1000 Ethernet management Port: Single RJ45
Serial Port: Single RJ45
Config and Backup: Single USB port
Power Supplies: 2 (1+1 redundant)
Fans: 4 (N+1 redundant)
Airflow Options: Forward/Reverse
Power Supplies: Frequency: 50-60Hz
Input range: 100-264 AC
Input current 4.5-2.9A
Typical Power (ATIS): 100W
Rack Mounting: 4-Post 19” rack, Tool-Less Railkit
Size (W x H x D): 1.72” x 16.84” x 17”
(43.9mm x 428mm x 432mm)
Weight: 7.41kg
