Huawei OceanStor Pacific 9920 Storage

Brand: Huawei

Model No: Huawei OceanStor Pacific 9920 Storage

System Architecture: Fully symmetric scale-out architecture

Storage Access Protocol: NFS, SMB, POSIX, MPI-IO, HDFS, Amazon S3, and FTP

Raw Capacity per Chassis: 23.04 TB ~ 1536TB

Height per Chassis: 2 U

Number of Nodes per Chassis: 1

Max. Number of Main Storage Disks per Node: 25

Primary Storage Disk Type: Palm-sized NVMe SSDs

Number of Processors per Node: 2 x Kunpeng 920 processors

Max. Memory per Node: 512 GB

Number of System Disks per Node: 2 x 480 GB SATA SSDs

Front-End Service Network Types: 25GE or 100GE TCP/IP, 100GE RoCE, 100Gb/s or 200Gb/s InfiniBand

Storage Network Types: 100GE TCP/IP, 25GE or 100GE RoCE, 100Gb/s or 200Gb/s InfiniBand

Data Redundancy Protection Mechanism: EC: N + M (M is 2, 3, or 4)

Data Self-Healing: Automatic concurrent data reconstruction at 2 TB per hour

Storage Management Software: DeviceManager and eService

Chassis Dimensions (H x W x D): 86.1 mm x 447 mm x 830 mm

Max. Weight per Chassis (with Disks): ? 35 kg

Operating Temperature: 5°C to 35°C

Operating Humidity: 8% RH to 90% RH (non-condensing)

Warranty: 1 Year Warranty
