HPE ProLiant DL380 G4 Server

Intel Xeon Processor 3.2 GHz/800MHz -1MB L2

Intel Xeon Processor 3.4 GHz/800MHz -1MB L2

Intel Xeon Processor 3.6 GHz/800MHz -1MB L2

PC2-3200R 400MHz DDR2

One external VHDCI connector

2MB L2 Cache
1 GB 2-way interleaved PC2-3200R 400MHz DDR2 SDRAM (Standard) up to 4 GB (Maximum)

Windows Storage Server 2003 Release 2, Standard Edition

NETWORK CONTROLLER: Embedded NC7782 Dual Port PCI-X 10/100/1000T Gigabit network adapter

STORAGE CONTROLLER: Smart Array 6i Controller with 128MB BBWC (integrated on system board)

Standard two (2) 36 GB Ultra320 15K 1" drives (for mirrored OS internal to server)

Diskette Drive: 1.44 MB Diskette Drive

Optical Drive: Slimline DVD-ROM Drive (8x24)

None

1.2 TB (4 x 300 GB Ultra320 1")

Standard one (1) Modular Smart Array 30 SB enclosure complete with dual power supply and four (4) 300 GB 1" Ultra320 10K RPM drives (1.2 TB).

Up to 56 TB max capacity with all SCSI HDDs

Up to 80TB max capacity with all SATA HDDs

Max capacity based on connection of up to 13 MSA30s (SCSI) enclosures fully populated with 300GB SCSI HDDs or 13 MSA20 (SATA) enclosures fully populated with 500GB SATA HDDs

Virtually Limitless on the SAN storage model (actual capacity varies based on storage capacity available in the HP-based SAN)

For ease of use making it possible to manage all NAS functions from a central location or anywhere with Internet access capabilities.

For environments that have a desire to consolidate storage and servers and get the best return on storage investment.
Snapshots

Incremental point in time copies that are flexibly scheduled throughout the day. An additional level of data availability that provides easy restoration of data without having the access tape, with limited utilization of time and space (Microsoft Shadow Copy).
